XENYX
CONTROL1USB

Front View

Studio Output
level control with
on/off switch

Rear View

USB socket
AC power Power On/Off
cable socket switch
Input Source
Select switches Mono switch
Phones 1 & 2 Phones/Studio
independent Source/Monitor
level controls assign switches
Stereo A, B & C Stereo 2-Track A,
Monitor Outputs B & DAW Outputs
(balanced/ (balanced/
unbalanced) with unbalanced) with
level controls level switches
12-LED Meter
with Clip indicator
and In/Out switch Mute switch
Really BIG Dim switch Talkback to
illuminated 2-Track assign
volume knob for switch
added precision
Stereo Monitor
Stereo Phones/ Mix Input
Studio Outputs (balanced/
(balanced/ unbalanced) with
unbalanced) level switch
Stereo Channel 3/
From USB Input
with level control
and switches
Built-in Talkback
Monitor Select Mic with
switches level control
Talkback to
Phones/Studio
assign switch
Stereo Inputs 1
& 2 with level
control and
switches
Stereo Inputs 1/4" TRS jack
4 with level for optional
control and Line/ Talkback
Phono switch Footswitch
