American Standard One Single Control Vessel Faucet 2064.151 Specification Sheet

48mm
(1-7/8")

GENERAL DESCRIPTION:

Brass body. Washerless 35mm ceramic disc valve
cartridge with integral hot limit safety stop. Braided
flexible supply hoses with 3/8" compression connectors.
1.5 gpm/5.7L/min. maximum flow rate.
SUGGESTED SPECIFICATION:
Single control lavatory faucet shall feature a brass body and metal lever handle. Fitting shall be equipped with flexible
supplies with 3/8" compression connectors. Shall also feature washerless ceramic disc valve cartridge with an integral hot
limit safety stop. Fitting shall be American Standard Model # 2064_.
© 2008 AS America Inc.
173mm
238mm
(6-7/8")
(9-3/8")
233mm
(9-1/8")
76mm
(3" MAX.)

PRODUCT FEATURES:

Brass Construction:
prolonged contact with water.
Ceramic Disc Valve Cartridge:
smooth handle operation and drip-free performance.
Adjustable Hot Limit Safety Stop:
hot water allowed to mix with cold. Reduces the risk of
accidental scalding.
Low Lead:
requirements.
Choice of Finishes:
Nickel (PVD).
C3
SINGLE CONTROL VESSEL FAUCET
MODEL NUMBER:
2064.152 One Single Control Monobloc
Grid Drain
2064.151 One Single Control Monobloc
Less Drain
321mm
(12-5/8")
425mm
(16-3/4")
Durable. Easy to clean. Ideal for
Meets NSF Standard 61/Section 9 & Prop 65 lead
Available in Polished Chrome or Satin
ONE
Assures a lifetime of
Limits the amount of
