AvaLAN AW58100HTP-PAIR User Manual

5.8 ghz outdoor 100 mbps wireless ethernet bridge
Hide thumbs
Table of Contents

Advertisement

Quick Links

AW58100HTP-PAIR
User's ManUal
5.8 GHz Outdoor 100 Mbps
Wireless Ethernet Bridge
AvaLAN
Industrial-grade, long-range wireless Ethernet systems
W
I
R
E
L
E
S
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW58100HTP-PAIR and is the answer not in the manual?

Questions and answers

Related Manuals for AvaLAN AW58100HTP-PAIR

Summary of Contents for AvaLAN AW58100HTP-PAIR

  • Page 1 AW58100HTP-PAIR User’s ManUal 5.8 GHz Outdoor 100 Mbps Wireless Ethernet Bridge AvaLAN Industrial-grade, long-range wireless Ethernet systems...

  • Page 2: Table Of Contents

    Warranty and FCC Information ......16 If you have any questions when configuring your AvaLAN system, the best place to get answers is to visit www.avalanwireless.com.

  • Page 3: Quick Start Guide

    AW58100HTP-PAIR Quick Start Guide The AW58100HTP-PAIR should be ready to function right out of the box. We recom- mend connecting and powering up the units on the bench before deploying in the field, because it is much easier to troubleshoot problems and to adjust the configu- ration if necessary without having to climb poles to do it.
  • Page 4 Re-position antennas if necessary to bring the sig- nal strength below -30 dBm. Utilizing state of the art MIMO technology, the AW58100HTP-PAIR achieves very high data rate through a combination of dual spacial streams and higher level OFDM modu- lation.

  • Page 5: Physical Setup

    The RJ-45 socket on the other end of the POE should be connected via your LAN cable to the AvaLAN radio. Then the power cords on the POEs may be plugged into a 120 VAC source. Each radio is provided with a cable clamping device that allows an RJ45 plug on the cable to pass through and can be tightened down around the cable to provide a weatherproof seal.

  • Page 6: Connecting To The Radio

    AW58100HTP-PAIR User’s Manual Connecting to the radio 1. Digital configuration is done by means of the radio’s built in browser interface. The unit should be powered on and connected at least temporarily to a network containing a computer that can run a conventional web browser.

  • Page 7: Changing The Configuration - Step By Step

    Recovery can be a time-consuming process and will require the help of AvaLAN Technical Support. If you are changing parameters over the RF link (we do not rec- ommend this), be sure to make the remote changes first because the link will be broken if the SSIDs or Security Pass Phrases do not agree.
  • Page 8 AW58100HTP-PAIR User’s Manual 3. Setting the SSID: • On the Main Menu at the left side of the browser window, click “Wireless.” Then click anywhere in the “Wireless_Radio” row to bring up the “Interface <Wireless_Radio>” page. • The third line down in the content table shows the current SSID and provides a text box to change it.
  • Page 9 User’s Manual AW58100HTP-PAIR • If you would rather eliminate encryption and use the “default” profile, you can change the choice of profile on the “Interface <Wireless_Radio>” page described earlier under setting the SSID. The Security Profile dropdown list may be found right under the SSID box on that page.

  • Page 10: Viewing Status Information

    User’s Manual Viewing Status Information After configuring your AvaLAN radios and establishing links among them, you can use the browser interface to view status and troubleshooting Information. Choose “Wireless” from the Main Menu at the left side of the window. The “Wireless” page leads to all of the useful status information.This page has three tabs, Interfaces,...
  • Page 11 Back on the “Wireless” page, you can click on the WDS process line to see simi- lar information about traffic with just that particular radio. Note that for the AW58100HTP-PAIR Bridge, this information is redundant because there is only one other radio.

  • Page 12: Advanced Diagnostic Tools

    Advanced Diagnostic Tools You may want to contact AvaLAN Technical Support for more guidance before using the additional tools described in this section. The radio’s browser interface unlocks some additional features if you login as an advanced user instead of the standard user described earlier in this manual.
  • Page 13 You may download this manual or other files by clicking the appropriate “Download” button. You are cautioned not to delete or alter these files without instructions from AvaLAN Technical Support. (It is very easy to render your radio inoperative by doing so.) 2.
  • Page 14 AW58100HTP-PAIR User’s Manual 3. Flood Ping: This tool can be used to generate a continuous string of ping com- mands to any IP address the radio can see on its subnet. Ping uses ICMP (Internet Control Message Protocol) to request a packet from the target device, waits for a return and then immediately sends another request.
  • Page 15 Linux or MAC OSX by using a Windows emulator such as Wine. By clicking the discovery button labeled “...”, any AvaLAN AW58100 family products on your LAN will be reported. (You may also see other devices as well if they respond to the CDP protocol used by the utility.) The popup window will show the IP address of each...

  • Page 16: Frequency Channels

    This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product.
