- Page 1 AW900x User’s ManUal Point-to-point Industrial-grade, ultra-long-range 900 MHz non-line-of-sight wireless Ethernet systems...
-
Page 2: Non-Line-Of-Sight
Operational summary The AW900x replaces costly wiring with a wireless Ethernet bridge that can enable remote Wi-Fi access points, Ethernet pan/tilt/zoom security cameras, VoIP phones, or Internet kiosks. AvaLAN’s product offers the ideal combination of price, range, data rate, security, interference avoidance, quality-of-service, and ease-of-use. -
Page 3: Quick Setup
Each AW900x radio automatically selects the best radio channel, encrypts the Ethernet traffic, and transports the data wirelessly to its mate. Any Ethernet device can be connected to the AW900x. The AW900x functions in place of an Ethernet cable and provides a trans- parent wireless point-to-point Ethernet cable replacement. -
Page 4: Led Display
User’s Manual LED display Troubleshooting see the online installation tutorial and FaQ at www.avalanwireless.com. no Power leD Check the power connections. no radio link leD The radio is looking for its matched partner. If both units are powered up and the Power LEDs are active, they may be too far away to create the radio connection. -
Page 5: Advanced Settings
Manual frequency selection mode To restrict the operation of the AW900x to a subset of the 902-928 band, the user may activate a manual selection mode that allows the radio to automatically choose the best channel within a grouped subset of the 12 available channels. This is enabled by the 8 position DIP switch on the master unit. -
Page 6: Technical Specifications
User’s Manual Technical specifications CHaraCTerIsTIC sPeCIFICaTIOn / DesCrIPTIOn rF transmission rate 1.536 Mb/s ethernet throughput 935 Kb/s Output power +21 dBm (4 Watts EIRP used with 15 dBi antenna) receive sensitivity -112 dBm at 10e-4 BER with 15 dBi antenna latency <... -
Page 7: Warranty
This product is warranted to the original purchaser for normal use for a period of 180 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product. - Page 8 ©2004 — 2007 AvaLAN Wireless Systems Incorporated. All rights reserved. AvaLAN Wireless and the AvaLAN Wireless logo are registered trademarks of AvaLAN Wireless Systems Incorporated. All other trademarks are property of their respective owners. AvaLAN Wireless makes no representations or warranties with respect to the accuracy, utility, or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any time without notice.
