Dell KM714 Owner's Manual

Wireless keyboard and mouse.
Hide thumbs

Advertisement

Dell
KM714 Wireless Keyboard and Mouse
TM
Owner's Manual

Advertisement

   Related Manuals for Dell KM714

   Summary of Contents for Dell KM714

  • Page 1 Dell KM714 Wireless Keyboard and Mouse Owner's Manual...
  • Page 2 All statements or claims regarding the properties, capabilities, speeds or qualifications of the part referenced in this document are made by the supplier and not by Dell. Dell specifically disclaims knowledge of the accuracy, completeness or substantiation for any such statements.
  • Page 3: Table Of Contents

    Contents Setup Keyboard Features Troubleshooting Specifications Mouse Features Troubleshooting Specifications Statutory Information Warranty Regulatory Certifications...
  • Page 4: Setup

    NOTE: The documents that shipped with the keyboard and mouse may vary based on your region. NOTE: If the Caps Lock indicator does not appear on the screen or eject shortcut key does not function, download the software from www.dell.com/support/KM714...
  • Page 5: Setting Up

    Back to Contents Page Setting Up Your Dell KM714 Wireless Keyboard and Mouse 1. Install the two AAA batteries in your keyboard. 2. Install the two AA batteries in your mouse. 3. Connect the USB receiver to the computer. If your keyboard or mouse is not working, see the Troubleshooting section.
  • Page 6: Unifying Pairing Features

    Unifying-compatible wireless devices at the same time. To begin using your receiver, ensure your computer has the software installed. Unifying software may be pre-installed on your computer. The software can also be downloaded from www.dell.com/support/Unifying...
  • Page 7: Top View Features

    Back to Contents Page Features Top View 1. Multimedia Control Keys 2. Windows 8 shortcut keys 3. Optical-drive eject key 4. Battery status light – Indicates the status of the batteries installed on your keyboard solid white – Appears for about 15 seconds after the batteries are installed then turns off blinking amber –...
  • Page 8: Bottom View Features

    Back to Contents Page Features Bottom View 1. Power switch 2. Battery compartment...
  • Page 9: Function Keys

    Back to Contents Page Function Keys Mute the sound Decrease the volume level Increase the volume level Play or pause the media Search (Windows 8) Share (Windows 8) Devices (Windows 8) Settings (Windows 8) Recent Apps (Windows 8)
  • Page 10 Back to Contents Page Application Keys Key Combinations Function Win7 : Open the Start Menu Windows key Win8 : Start screen Open Windows Explorer Find a document Minimize all open windows Display the Run dialog box + F1 Display the Help menu + TAB Activate the next taskbar button + Ctrl + F...
  • Page 11: Troubleshooting

    Back to Contents Page Troubleshooting If you have problems with your keyboard: Check if the batteries are inserted in the correct orientation. Check if the keyboard’s power switch is set to “On”. Remove and reinstall the batteries. The power status light turns on (solid white) for about 15 seconds and then turns off.
  • Page 12: Specifications

    Back to Contents Page Specifications General Model number KM713 Connection type 2.4 GHz wireless technology Supported operating systems Microsoft Windows 8 Microsoft Windows 7 Microsoft Windows RT Rollover Pseudo N-key rollover capability Key mechanism Scissor Electrical Operating voltage 2.05V to 3.2V Battery life Approximately 12 months Battery required...
  • Page 13: Top View

    Back to Contents Page Features Top View 1. Left mouse button 2. Tilt wheel 3. Side button * 4. Battery status light Blinking amber - Battery charge is low. Replace the batteries. 5. Side button * 6. Right mouse button *Both side buttons perform the same function.
  • Page 14: Features

    Back to Contents Page Features Bottom View 1. Laser sensor 2. Power button...
  • Page 15 Back to Contents Page Shortcut Gestures Windows charms Press and hold side button, and slide the mouse towards left. (Windows 8 only) App switch Press and hold side button, and slide the mouse towards right. (Windows 8 only) Scroll and pan 4-way scroll (Windows 7 and 8) Zoom in/out...
  • Page 16 Back to Contents Page Increasing the Battery Life of your Mouse The mouse has three operating modes built in to conserve battery power: 1. Sleep mode: When the mouse has been inactive for 5 seconds. To wake the mouse: Move, click or scroll the tilt wheel. 2.
  • Page 17: Troubleshooting

    Back to Contents Page Troubleshooting If you have problems with your mouse: Check if the batteries are inserted in the correct orientation. Check if the mouse’s power button light is on. Remove and reinstall the batteries. Check to see if the power button light turns on (solid white).
  • Page 18: Specifications

    Back to Contents Page Specifications General Model Number WM514 Connection Type 2.4 GHz wireless technology Supported Operating Systems Microsoft Windows 8 Microsoft Windows 7 Microsoft Windows RT Electrical Operating Voltage 0.95 V to 1.8 V Battery Life Approximately 12 months Battery Requirements Two AA Alkaline Physical Characteristics...
  • Page 19: Warranty

    If purchased together with Dell system, it will follow the system warranty. For U.S. customers: This purchase and your use of this product are subject to Dell’s end user agreement, which you can find at www.dell.com/terms. This document contains a binding arbitration clause.
  • Page 20: Regulatory

    Back to Contents Page Regulatory Keyboard Regulatory Model: KM713 Mouse Regulatory Model: WM514 Dongle Regulatory Model: C-U0007 Regulatory Information These devices comply with Part 15 of the FCC Rules. Operation of the devices is subject to the following two conditions : (1) The devices may not cause harmful interference, and (2) The devices must accept any interference that may cause undesired operation.
  • Page 21 Back to Contents Page Certifications Microsoft WHQL Logo The Dell KM714 Wireless Keyboard and Mouse have passed WHQL logo testing by Microsoft Windows Hardware Quality Labs. WHQL Logo is a certification scheme operated by Microsoft Windows Hardware Quality Labs. In this case it ensures that hardware is compatible with Microsoft Operating Systems.
