- Page 1 MANUFACTURING NUMBERS: 9600200 9600202 9600210 9600212 9600214 9600215 9600217 9600218 CORN COOKER Models CCC-20 Series 9600200 P/N 1010634 Rev. I 03/06 Owner s Manual ’...
-
Page 2: Table Of Contents
CORN COOKER TABLE OF CONTENTS Equipment Setup ............6 Owner Information .............2 Operating Instructions ..........7 General ..............2 Unsold Corn ...............7 Warranty Information ..........2 Operation ..............7 Important Safety Information ........3 Technical Theory of Operation ........8 Service/Technical Assistance ........3 Cleaning Daily ............8 Dimensions ..............5 Maintenance ..............8 Electrical Ratings ............5 Troubleshooting ............9... -
Page 3: Important Safety Information
CORN COOKER OWNER INFORMATION (continued) Service/Technical Assistance Refer to the service agency directory included with your unit. If you experience any problems with the installation or operation of your unit, contact your local Roundup Authorized Service Agency Authorized Service Agency. Name: Fill in the information below and have it handy when Phone No.:... - Page 4 CORN COOKER IMPORTANT SAFETY INFORMATION (continued) In addition to the warnings and cautions in this manual, • The procedures in this chapter may include use the following guidelines for safe operation of the the use of chemical products. These chemical unit.
-
Page 5: Dimensions
CORN COOKER SPECIFICATIONS Electrical Ratings Electrical Cord & Plug Configurations Model & Voltage Watts Amps Hertz Letter Description Configuration Mfg. No. Code* CCC-20CF 1750 15.0 50/60 Commercial Cord 9600200 Harmonized Cord CCC-20HC 208, 220-240 2090 10.0, 50/60 9600202 9.5 - 9.0 (H)C** CEE 7/7, 16 Amp., 250 VAC... -
Page 6: Installation
CORN COOKER INSTALLATION Unpacking Head Safety Interlock Switch Assembly Beneath Head Assembly 1. Remove unit and all packing materials from ship- ping carton. 2. Open the large box. Remove all packing materi- als and protective coverings from the unit and parts. -
Page 7: Operating Instructions
CORN COOKER OPERATION Operating Instructions 1. Fill the Pan about half full of hot tap water. 2. Turn the Rocker Switch (power On/Off) ON. NOTE: If the light on the Rocker Switch does not light up, you must remove and reinstall the Head Assembly onto the pan (Figure 1) to ensure that the Safety Interlock Switch is properly engaged. -
Page 8: Technical Theory Of Operation
CORN COOKER MAINTENANCE 2. Empty the Pan of used water. Wash the Baskets WARNING and Pan in hot detergent water. Rinse in clear Turn the unit off, disconnect the power source water and dry. and allow the unit to cool down before performing any service or maintenance on the unit. -
Page 9: Troubleshooting
CORN COOKER TROUBLESHOOTING WARNING To avoid possible personal injury and/or damage to the unit, inspection, test and repair of electrical equip- ment should be performed by qualified service personnel. The unit should be unplugged when servicing, except when electrical tests are required. Use extreme care during electrical circuit tests. Live circuits will be exposed. -
Page 10: Replacement Parts
CORN COOKER REPLACEMENT PARTS Item Part No. Description Quantity Quantity Mfg. # 9600200, 202, Mfg. # 9600215, 210, 212, & 214 9600217, & 9600218 0800103 Basket, Corn 0800380 Basket, Corn 0500233 Clamp, Heater 0504108 Clamp, Heater 403K121 Thermostat Kit (Incl. #20) 0500230 Clamp 0504106... - Page 11 CORN COOKER REPLACEMENT PARTS (continued) Item Part No. Description Quantity Quantity Mfg. # 9600200, 202, Mfg. # 9600215, 210, 212, & 214 9600217, & 9600218 310P102* Lockwasher, #10 310P123* Screw, #10-24 x 1/2” 310P146* Nut, Hex, KEPS, #10-32 NS 0011046 Base Housing Assy.
- Page 12 CORN COOKER REPLACEMENT PARTS (continued) INSET 22,24 P/N 1010634 Rev. I 03/06...
-
Page 13: Wiring Diagram
CORN COOKER WIRING DIAGRAM POWER CORD NOTES: ALL WIRES TO BE 12 GA. TEW-105°C UNLESS OTHERWISE SPECIFIED. *18 GA. AWM-105°C #14 GA. AWM-105°C INDICATOR LIGHT TERMINAL BLOCK THERMOSTAT # GRN/YEL HEATER INTERLOCK SWITCH POWER SWITCH P/N 1010634 Rev. I 03/06... - Page 14 CORN COOKER NOTES P/N 1010634 Rev. I 03/06...
- Page 15 CORN COOKER NOTES P/N 1010634 Rev. I 03/06...
-
Page 16: Limited Warranty
LIMITED WARRANTY Equipment manufactured by Roundup Food Equipment Division of A.J. Antunes & Co. has been con- structed of the finest materials available and manufactured to high quality standards. These units are warranted to be free from mechanical and electrical defects for a period of one year from date of pur- chase or 18 months from shipment from factory, whichever occurs first, under normal use and service, and when installed in accordance with manufacturer’s recommendations.
