WIRELESSIP 5000 User's Manual
Hitachi Cable, Ltd.

Advertisement

   Also See for Hitachi TD61-2472

   Summary of Contents for Hitachi TD61-2472

  • Page 1

    TD61-2472 WIRELESSIP 5000 User's Manual Hitachi Cable, Ltd.

  • Page 3: Table Of Contents

    ...35 RESENCE 1.10.1User list...35 1.10.2User Registration...36 1.10.3Block list...37 1.10.4Block register...37 1.10.5Status...39 1.11.B ...40 ASIC SETTINGS MENU 1.11.1Ringer/vibration...40 1.11.1.1Distinctive Ringtones...41 1.11.1.2Ringtones...41 1.11.1.3Mode...42 1.11.1.4LED...42 1.11.1.5Volume adjustment...43 1.11.2Caller ID...44 1.11.3Service LED...44 1.11.4Brightness adjustment...45 1.11.5Security...46 1.11.6Information display...47 1.11.7Error Msg...49 1.11.8Font size...49 Hitachi Cable -iii-i...

  • Page 4

    1.24.W ARNING ABOUT EXPLOSIVE GAS 1.25.W ARNING ABOUT THE IMPACT OF ELECTROMAGNETIC SIGNALS 1.26.W ARNING ABOUT BATTERY HANDLING 1.27.B ...65 ATTERY SAFETY ITEMS ... 65 APPENDIX SPECIFICATIONS ... 66 ... 68 Hitachi Cable -iii-ii ...63 ...64 ...65 ...65 ...65 ...65...

  • Page 5: Names & Functions Of Device Parts

    Shows that the alarm is On. Displayed when the Alarm clock function is on. Displayed when there is an unread message. Shows that the keys are locked. When this mode is On, key operation is disabled. Shows the remaining battery capacity. The more lines, the more capacity remains. Hitachi Cable...

  • Page 6

    User's Manual VolUp VolDn Lock LeftSoft RightSoft Clear Send 1 , … Hitachi Cable Table 1. Key Operation Names and functions Headphone jack Volume Up: Increases the headphone/earpiece/ringer volume. Volume Down: Decreases the headphone/earpiece/ringer volume. Key lock LeftSoft key RightSoft key...

  • Page 7: Number Pad Input Table

    Example: For an item for which only numbers and English letters can be input Example: For an item for which numbers and English letters and Japanese characters can be input Hitachi Cable Text input mode Character assignments 1 / ,...

  • Page 8

    When hiragana syllabic letters are selected, after input you can convert to kanji ideograms with the Press the key to confirm the character. To delete the input character, press the Clear key. Hitachi Cable keys. keys.

  • Page 9: Application

    With the power On, if you hold down the End key for at least 1 second, a screen like that in the figure on the right is displayed and the power goes Off. Note! After you switch off the power, you can not switch it back on again for 3 seconds. Hitachi Cable...

  • Page 10: Call

    1.6. Receive Receiving a call. If a set telephone number is displayed on the screen, you can receive a call. Note! If the telephone number is not set correctly, "NotRegister" or "Network Fail" is displayed. Hitachi Cable...

  • Page 11: Contact List

    The screen in the figure on the right (second line) is displayed. Either press the "1" on the number pad or select "1. Contact list" with the keys, then press the key. 1.7.1 New registration 1.7.1.1 Registration from telephone number Hitachi Cable...

  • Page 12: 2registration From Contact List Menu

    1.7.1.2 Registration from contact list menu Registering information into the contact list from the new registration menu From the contact list menu, select "2. New". Hitachi Cable...

  • Page 13

    If you press the key without inputting a telephone number, the <Warning> message in the figure on the right is displayed. Hitachi Cable...

  • Page 14: 3registration From Search Results

    Select the number you want to register, press the LeftSoft key to select the sub-menu, and select "1. Add". Input the information. Input the necessary information (name, kana syllabic letters for name pronunciation, telephone number, group, speed dialing number), then press to save this information. Hitachi Cable...

  • Page 15: 4registration From A Call Log

    Select the number you want to register, press the LeftSoft key to select the sub-menu, and select "1. Save". Input the information. Input the necessary information (name, kana syllabic letters for name pronunciation, telephone number, group, speed dialing number), then press to save this information. Hitachi Cable...

  • Page 16: 5registration From Im

    After selecting the message to register from, press the LeftSoft key to select the sub-menu, then select "1. Save". Input the information. Input the necessary information (name, kana syllabic letters for name pronunciation, telephone number, group, speed dialing number), then press to save this information. Hitachi Cable...

  • Page 17: 6registration From Presence

    After selecting the user you wish to register, press the LeftSoft key to select the sub-menu, then select "1. Save". Input the information. Input the necessary information (name, kana syllabic letters for name pronunciation, telephone number, group, speed dialing number), then press to save this information. Hitachi Cable...

  • Page 18: 2call From Contact List

    In this case, if you input "o", then press the "Ootani" are displayed. If you select a name then press the Press the Send key or the Hitachi Cable key, both "Ogawa" and key, detailed information is displayed. key to make the call.

  • Page 19: 3group Revision

    To add a group, press the LeftSoft key to select the sub-menu, then select "1. Add". The figure on the right shows the addition of a group named "WIP". To save the newly added group and return to the contact list menu, press the Hitachi Cable key.

  • Page 20

    To change a group (name), select the group to change, then press the Edit according to Step 3. After this, when you press the new group name, the display returns to the contact list menu. Hitachi Cable key. key and save the...

  • Page 21: 4erase One Item From Contact List

    Note! For Version 1.4.3, you can not delete through a search from "1. Speed dialing number" and "3. Telephone number". Select the telephone number to delete, then press the LeftSoft key to select the sub-menu, then select "3. Delete". Hitachi Cable...

  • Page 22: 5erase All

    1.7.5 Erase all Deleting all the data in the contact list. From the contact list menu, select "4. Delete all". A confirmation message is displayed. With the "Yes" or "No". Hitachi Cable keys select either keys, select either...

  • Page 23

    The "Deletion complete" message is displayed immediately, then the display returns to the contact list menu. 1.8. IM Displays the mail menu. Press the LeftSoft key to select the menu item. Select "2. IM". * With some connection equipment, this is not possible. Hitachi Cable...

  • Page 24: 1inbox

    If you do nothing with the display screen, the message is automatically scrolled vertically. You can also use the * The screen contents include the date, telephone number, and message contents. Hitachi Cable , the selected message automatically keys. key to check a message manually.

  • Page 25

    To edit a received message, select that message, press the LeftSoft key to select the sub-menu, then select "2. Edit". The screen becomes like the figure on the right, so with the keys move to the input column you want to edit and then edit it. Hitachi Cable...

  • Page 26

    To delete a message, select the message to delete, press the LeftSoft key to select the sub-menu, then select "3. Delete". The screen in the figure on the right (3rd line) is displayed. Select whether or not to delete with the keys, then press the to finalize the deletion. Hitachi Cable...

  • Page 27: 2new

    Input the message with the number keys and the LeftSoft key. Send the message with the RightSoft key.. The processing during sending is displayed as in the figure on the right. The "Message sent" message screen is immediately displayed. Hitachi Cable...

  • Page 28

    After the "Message sent" message screen is immediately displayed, a screen is displayed to confirm whether or not you want to save the message. To save the sent message, select "Yes" with the keys, then press the key… Hitachi Cable...

  • Page 29: 3drafts

    Alternatively, you can use the key to select the next message up or down. To check a message manually, use the Hitachi Cable keys, then press the keys.

  • Page 30

    "2. Edit". The screen becomes as in the figure on the right, so with the move to the input column you want to edit and edit it. Hitachi Cable key to check a message manually. keys,...

  • Page 31: 4outbox

    The screen in the figure on the right (3rd line) is displayed. Select whether or not to delete with the finalize the deletion. 1.8.4 Outbox Displaying, editing, deleting, and re-sending of sent messages From the IM menu, select "4. Outbox". Hitachi Cable keys, then press the key to...

  • Page 32

    "2. Edit". The screen becomes as in the figure on the right, so with the move to the input column you want to edit and edit it. Hitachi Cable key to select the next message up or keys.

  • Page 33: 5delete All

    Select whether or not to delete with the finalize the deletion. 1.8.5 Delete All Deleting all the messages from the Inbox, drafts, and Outbox. From the IM menu, select "5. Delete all". Hitachi Cable keys, then press the key to...

  • Page 34

    To delete them, select "Yes" with the When you select "Yes", the message deletion process starts. The "Deletion complete" message is displayed. Hitachi Cable key. key. key. keys, then press the key.

  • Page 35: Call Log

    The incoming call list is displayed. If a name is set for a telephone number, that is displayed. If not, the telephone number is displayed. * The date and time the call came in are displayed above the name/telephone number. Incoming call log Missed call log Hitachi Cable key.

  • Page 36: 1details

    1.9.2 Call log delete Deleting one call from a call log. Displays the call logs. To delete a call log, select the call log to delete, press the LeftSoft key to select the sub-menu, then select "2. Delete". Hitachi Cable...

  • Page 37: 3delete All Data

    The screen in the figure on the right is displayed. Select whether or not to delete with the finalize the deletion. 1.9.3 Delete all data Deleting the entire call logs. “3.Select "Delete all data". Hitachi Cable keys, then press the key to...

  • Page 38: 4calling From The Call Log

    With a call log displayed, you can make a call by pressing the Send key with the name/telephone number highlighted. If their name is registered in the contacts list, their name is displayed above the telephone number. Hitachi Cable keys, then press the key to...

  • Page 39: Presence

    "1.User list", then press the A list of the registered users is displayed. To add or delete a registered user, press the LeftSoft key to select the sub- menu, then select either "2. Add" or "3. Delete". Hitachi Cable key.

  • Page 40: 2user Registration

    Use the number pad and the LeftSoft key to enter the user's telephone number. If you try to input an Alias that is already registered, the "Already registered" message is displayed and the display returns to the input field. Hitachi Cable key.

  • Page 41: 3block List

    1.10.4 Block register Registering a user to whom your status will not be disclosed. To register a user for blocking, either press the "4" on the number pad or select "4. Block list", then press the Hitachi Cable key. key.

  • Page 42

    Use the number pad and the LeftSoft key to enter the user's telephone number. If you try to input an Alias that is already registered, the "Already registered" message is displayed and the display returns to the input field. Hitachi Cable...

  • Page 43: 5status

    You can set the status by using the There are seven status modes. : Online : Picking up : Briefly away from seat : Away from seat : On another call : Lunch break : Offline Hitachi Cable keys, then pressing the key.

  • Page 44: Basic Settings Menu

    A screen like that in the figure on the right (second row) is displayed. "5.Select "Setting". 1.11.1 Ringer/vibration Setting the ringer/vibration type. From the setting menu, select "1. Ringer/vibration". Setting "1. Telephone" or "2. IM". To set the telephone ringer, select "1. Telephone". To set the message ringer, select "2. IM". Hitachi Cable...

  • Page 45: 1distinctive Ringtones

    External 1" is enabled. 1.11.1.2 Ringtones Setting the inside line and outside line ringer tones. To change the ringer tone, select "1. Ringer tone". Use the keys to select the ringer tone, then press the Hitachi Cable key. key. Mode Bell Blue...

  • Page 46: 3mode

    Setting the LED color for calls coming in on internal lines and external lines. To change the LED color for incoming calls, select "3. LED". Use the keys to set the LED color, then finalize with the There are three LED colors. ・ RED ・ BLUE ・ (None) Hitachi Cable key. key.

  • Page 47: 5volume Adjustment

    1.11.1.5 Volume adjustment Setting the headphone/earpiece/ringer volume. From the telephone menu, select "5. Adjust volume". Use the keys to set the volume, then finalize with the Hitachi Cable key.

  • Page 48: 2caller Id

    ID on/off, then finalize with the 1.11.3 Service LED Setting the Service LED. From the setting menu, select "2. Service LED". Service LED information: The User Service LED, mode, and interval are displayed. Hitachi Cable key.

  • Page 49: 4brightness Adjustment

    1.11.4 Brightness adjustment Adjusting the display screen brightness. From the setting menu, select "4. Adjust brightness". Use the keys to adjust the contrast, then finalize with the Hitachi Cable key.

  • Page 50: 5security

    Please enter the correct password. The default value is 0000. If you input the wrong password, a screen like that on the right is displayed. When you input the correct password, the system asks you to input the new password. Hitachi Cable...

  • Page 51: 6information Display

    Displaying the network information, server information, MAC address, and version information. From the setting menu, select "6. Information display". From the information display menu, select "1. TCP/IP". Network information”: DHCP mode, IP address, Netmask, Gateway, DNS1, and DNS2 are displayed Hitachi Cable  ...

  • Page 52

    Server information: Primary URL, Primary Register Secondary URL、Secondary Registra、Outbound Proxy From the information display menu, select "3. MAC address". The MAC address is displayed. From the information display menu, select "4. Version". The boot ROM and software version are displayed. Hitachi Cable...

  • Page 53: 7error Msg

    Error Msg On/Off, then finalize with the key. 1.11.8 Font size Setting the font size. From the information display menu, select "8. Font size". Use the keys to select a font size of Large or Small, then finalize with key. Hitachi Cable...

  • Page 54: 9time Setting

    From the clock menu, select "2. NTP" and switch the NTP On/Off. Note! If no NTP server is set, when you reboot the time that has been set is initialized. Use the keys to set NTP On/Off, then finalize with the Hitachi Cable key.

  • Page 55

    Select "3. NTP server 1" or "4. NTP server 2". Use the number pad to input the NTP server IP address. Select "5. Time offset". Use the keys to select the time, then finalize with the Hitachi Cable key.

  • Page 56: 10language Setting

    Reference: The Admin menu is the menu for the network administrator. For details, refer to the "WIRELESSIP 5000 Administrator Guide". 1.11.11 Courtesy mode On/Off When courtesy mode is set, the ringer does not ring and all ringers go into vibration mode. Hitachi Cable key and save the setting. The key to select key.

  • Page 57

    Press and hold down the * key on the number pad. Silent mode and vibration mode are switched On. To end courtesy mode, press and hold down the * key on the number pad again. Hitachi Cable...

  • Page 58: 12keylock/keyunlock

    Press and hold down the Lock key on the side of the phone. Enter the password. Note! The default value for the password is "0000". You can change the password freely. (See the security section.) The keylock comes On. Hitachi Cable...

  • Page 59

    To unlock the keylock, press and hold down the Lock key on the side of the phone again. Enter the password. Hitachi Cable...

  • Page 60: Various Operation Methods

    <Screen for the terminal putting the call on hold> Telephone number: 2314 1.12.2 Hold release During a hold, you can end the hold by pressing the Send key. Hitachi Cable During call Telephone number: 2310 Holding Telephone number: 2310 <Screen for the terminal put on hold>...

  • Page 61: Calling Method

    You can call an outside number by dialing the <prefix> + <outside telephone number>, then pressing the Send key. Check the prefix and the outside number with the administrator. Inside number: 1111 number: number: 05011111111 Prefix: 0 Hitachi Cable Dial the inside number (2222) for B, then press the Send key. Calling Inside number: 2222...

  • Page 62: 3184/186 Call

    Inside number: Base number: Outside line number: 05011111111 Prefix: 0 Example: 186 call Inside number: Base number: Outside line number: 05011111111 Prefix: 0 Hitachi Cable Caller ID display Displayed Displayed No alert No alert Displayed No alert Calling Inside number: 1111...

  • Page 63: 4operation Methods Using Call Mode

    * Using the prefix + 184/186 gives the same results as the above operation. 1.13.5 Redial You can redial the last telephone number dialed. Press and hold down the Send key for at least 1 second. The last telephone number dialed is redialed. Hitachi Cable...

  • Page 64: 6speed Dialing

    A call is made to the telephone number corresponding to the speed dialing number input. 1.13.7 Timer between digits If you input the telephone number with the Send key held down, the call is made automatically after the telephone number is input. Press the Send key. Entering the telephone number. Hitachi Cable...

  • Page 65

    After a short time, a call is made automatically to the telephone number for the speed dialing number entered. Note! If call mode is used when inputting the telephone number, the timer between digits does not operate. Hitachi Cable...

  • Page 66: Accessories

    Keep accessories out of the reach of children.  Use only chargers, batteries, and accessories specifically manufactured for the Hitachi Cable WIRELESSIP5000.Using a charger, battery, or accessory not designed for the WIRELESSIP5000 would cause danger and would void the warranty for your telephone.

  • Page 67: Usb Cable

    Step 2 As Figure 4 shows, insert the WIRELESSIP5000 onto the charger until it clicks into place and the LED lights up blue. Note: As Figure 5 shows, you can also charge with the optional USB cable instead of with the AC adaptor. Hitachi Cable Figure 3 Figure 4...

  • Page 68: Charging Without The Desktop Charger

    Step 3: Install the AC adaptor's 24-pin connector to the bottom of the WIRELESSIP5000. Note: You can also charge with the optional USB cable instead of with the AC adaptor. 1.22.LED LED color Status Operating, Call underway Blue Charging (Goes out when the charging is complete) Hitachi Cable Figure 5 Table 1...

  • Page 69: Safety Information

    When disposing of a used battery pack, consult a local waste processing contractor and follow all laws concerning disposal and recycling.  To replace the battery, contact your local sales store. Use a battery specifically designed for the WIRELESSIP5000.  Use the AC adaptor manufactured specifically for the WIRELESSIP5000. Hitachi Cable ˚ ˚...

  • Page 70: Appendix Specifications

    Physical Main Unit dimensions Lithium ion battery Desktop charger Hardware Display Button Audio interface Case material Other Hitachi Cable Specifications 44(W)mm×23(D)mm×127(H)mm (Using lithium ion battery) 43(W)mm×11(D)mm×68.5(H)mm 64(W)mm×89(D)mm×80(H)mm Number of pixels 128×128 8 lines, 10 columns (double-byte characters) Dot size 0.18(W)mm×0.22(H)mm Dot pitch 0.19(W)mm×0.23(H)mm...

  • Page 71

    Firmware upgrade Battery Lithium ion battery *1 The communications distance can vary with the weather, temperature, etc. *2 L3 handover is also possible with the AP side specifications. Hitachi Cable IEEE802.11b (11Mbps wireless LAN) (wi-fi) CSMA/CA DBPSK (1Mbps) DQPSK (2Mbps) CCK (5.5&11Mbps)

  • Page 72

    *3 In power save mode. Hitachi Cable...
