USER GUIDE
10/100 Ethernet
Fiber Link Card System
Environmentally hardened, substation grade
Description
The RLH 10/100 Ethernet Fiber Link Card system converts a
copper 10Base-T or 100Base-TX to a fiber optic 100Base-FX
transmission signal of either multimode or single-mode. The
cards transmit the data signals over fiber optic cable, allow for
network extension over long distances, and provide electrical
isolation between both ends of the network.
The Ethernet Fiber Link Card may be used as a complete
system, with a card at each end, or it may be connected
directly to any 100Base-FX device. The card includes Link
Fault Passthrough (LFP) mode with an LED indicator for link
loss failure that allows for rapid fault isolation.
This hardened, substation grade system is covered by our
Exclusive Unconditional Lifetime Warranty.
Note: The cards listed in this document replace all other
models. See the ordering section for part number information.
Key Features
•
Ideal for critical, high voltage, remote or un-manned
locations that must remain operating 24/7/365
•
Compatibility with IEEE 802.3 10 Base-T UTP, 100Base-TX,
and 100Base-FX Devices
•
RJ45 UTP port with 10//100 auto-negotiation
•
Extends network span up to 1.2 miles (2km) on multimode and
up to 74 miles (120km) on single-mode fiber
•
Convenient LED status indicators
•
Link alarm function for status monitoring
•
Dual and Single (bi-directional) fiber models available
•
Environmentally hardened to operate in -40°F to +158°F
(-40°C to +70°C) environments
•
Standard RLH fiber link card form factor
Covered by our Exclusive Unconditional Lifetime Warranty
•
RLH Industries, Inc.
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com
The leader in
rugged fiber optic
technology.
RLH 10/100 Ethernet Fiber Link Card
Contents
__________________________
__________________________
_________________
_________________________
___________________________
__________________________
____________________
______________________
_______________________
__________________
_________________________
___________________________
_____________________
Specifications subject to change without notice.
Unconditional
Lifetime Warranty
U-016 2013B-1002
1
1
2
3
4
4
5
6
6
7
8
9
9
Page 1
Advertisement
Table of Contents
Related Manuals for RLH Industries 10/100 Ethernet Fiber Link Card System
Summary of Contents for RLH Industries 10/100 Ethernet Fiber Link Card System
-
Page 1: Table Of Contents
(-40°C to +70°C) environments • Standard RLH fiber link card form factor Covered by our Exclusive Unconditional Lifetime Warranty • Specifications subject to change without notice. RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com Page 1... -
Page 2: General Safety Practices
The equipment discussed in this document may require tools designed for the purpose being described. RLH recommends that service personnel be familiar with the correct handling and use of any installation equipment used, and follow all safety precautions including the use of protective personal equipment as required. -
Page 3: Applications
Ethernet Ethernet Ethernet Device Device 24 - 56VDC Power Supply 24 - 56VDC Power Supply Typical Ethernet System Diagram FEFD Ethernet Fiber Link Card Front Panel RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com Page 3... -
Page 4: Acronyms
The TP (RJ-45) Ethernet port will auto-sense for 10Base-T or 100Base-TX connections. The port is auto MDI/MDIX, which means that the card can connect to another card, switch or workstation without changing straight through or crossover cabling. Page 4 RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com... -
Page 5: Dip Switch Settings
When operating in Manual mode, both mating ports must be set to the same data rate and duplex mode. RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com Page 5... -
Page 6: Troubleshooting
Blinking TP port link OK and activity is present TP port link not present If trouble persists, replace the unit and retest. If technical assistance is required, contact the RLH technical support department: 800-877-1672 (6 am to 6 pm- PST),... -
Page 7: Ordering Information
Bidirectional single fiber models require both an A Side and B Side unit for a complete system. Please contact your RLH sales representative for pricing and delivery information. RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com Page 7... -
Page 8: Specifications
-40˚F to +176˚F (-40˚C to +80˚C) -40˚F to +176˚F (-40˚C to +80˚C) Humidity 5~95% non-condensing 5~95% non-condensing 5~95% non-condensing 5~95% non-condensing 5~95% non-condensing Specifications subject to change without notice. Page 8 RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com... -
Page 9: Warranty
RLH products will reduce your costs and simplify your maintenance activities. To make a warranty claim, or schedule repair or replacement of your RLH product, contact us for an RMA number. You will be promptly assisted by one of our warranty specialists. An RMA number is required before we can receive any items. - Page 10 RLH INDUSTRIES, INC. FIBER OPTIC LINK products are warranted to be free of defects in materials and workmanship for the LIFE OF THE PRODUCT. This lifetime warranty is effective for RLH fiber optic link products sold since the date RLH was founded, February 2, 1988, with the exception of fiber cable products which are warranted to free of defects in manufacturing, and batteries which carry a 10-year unconditional replacement warranty.
