USER GUIDE
2 Channel
4 Wire Data with E&M
DIN Fiber Link System
SYSTEM INSTALLATION
INFORMATION
This industrial fiber optic media converter is designed to extend two
4 Wire Voice Frequency signals over fiber optic cable. By extending
4 Wire signals over fiber cable you gain the advantage of sending
the signal long distances, up to 120km, as well as gain noise
immunity to RF and electromagnetic interference.
This system transports two circuits of 4 Wire Data and supports
E&M signaling. The 4 wire data supports constant transmission of
voice frequency ranging from 300Hz-3400Hz which is suitable for a
wide range of radio and SCADA applications. The devices can be
ordered with dual fiber or single fiber transceivers. This RLH Fiber
Link system is designed and made in the U.S.A. and covered by our
Limited Lifetime Warranty.
Key Features
• Hardened to operate in -40°F to +158°F (-40°C to +70°C)
• System power options: 24-48VDC and 125 VDC
• Multimode or single-mode fiber, and SC or ST connectors
• Single and dual fiber models available
• Built-in alarm relay to indicate system failure
• 4 wire voice frequency data systems
• Supports E&M
• Convenient LED status indicators
• Made in the USA covered by our Lifetime Warranty
RLH Industries, Inc.
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com
The leader in
rugged fiber optic
technology.
2 Channel 4 Wire Data with E&M DIN Fiber Link System
Contents
Introduction ______________________________1
General Safety Practices ___________________
Special Handling Requirements _____________2
Acronyms ________________________________3
Applications ______________________________3
Installation ________________________________4
Operation ________________________________7
Status and Activity LED's ___________________
Specifications _____________________________8
Ordering Information _______________________
U-147 2024A-1104
2
7
9
