Page 1: Tape Drive Unit
4-679-683-13 (2) S-AIT Tape Drive Unit Operating Instructions Before operating the unit, please read this manual thoroughly and retain it for future reference. SAITe1300-S SAITe1300-F © 2003 Sony Corporation... -
Page 2: Safety Information
Owner’s Record The model and serial numbers are on a label on the bottom of the unit. Record the serial number in the space provided below. These numbers provide specific information about your S-AIT Tape Drive Unit and will be very helpful if you have to contact technical support. Model No. - Page 3 ) zu verwenden. ATTENTION According to the EU Directives related to product safety, EMC and R&TTE the manufacturer of this product is Sony Corporation, 6-7-35 Kitashinagawa Shinagawa-ku Tokyo, 141-0001 Japan. The Authorised Representative is Sony Deutschland GmbH, Hedelfinger Strasse 61,70327 Stuttgart, Germany. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.
- Page 4 The shielded interface cable recommended in this manual must be used with this equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules. If you have any questions about this product, please access Sony Support Center written in the warranty card. Declaration of Conformity...
-
Page 5: Table Of Contents
Setting the DIP Switches ..........19 If necessary, change the settings as follows....19 Setting the SCSI ID (SAITe1300-S only) ....22 Setting the Loop ID (SAITe1300-F only) ....23 Installing the S-AIT Tape Drive Unit......25 Connecting the Power Cable........26 Installing Device Drivers...........26 Connecting the SCSI Bus Cable (SAITe1300-S only) ..........27... - Page 6 © 2003 Sony Corporation. All rights reserved. Trademarks • Sony, Advanced Intelligent Tape, and Super Advanced Intelligent Tape are trademarks or registered trademarks of Sony Corporation in this country, other countries, or both. • Other product names are trademarks or registered trademarks of their respective owners in this country, other countries,...
-
Page 7: Overview
Advanced Metal Evaporated (AME) Tape S-AIT media is based on AME technology. This technology represents the culmination of over 50 years of Sony innovation and experience in magnetic tape technology. The AME tape formulation, with diamond-like carbon coating, offers an extraordinary durability and reliability, up to 30,000 media passes, and an estimated media archival life of up to 30 years. -
Page 8: Product Features
• Ultra 160 SCSI LVD/SE interface is fully supported for host computer access. • Burst data transfer rate of 160 MB per second, synchronous. • Supports SCSI disconnection and arbitration. Features of the SAITe1300-F (Fibre Channel Interface model) • 2 Gbps Fibre Channel interface. -
Page 9: Compatible Cartridges
Compatible Cartridges Data Cartridges Tape cartridges used with the S-AIT Tape Drive Unit must be marked with the SAIT-1 logo. SAIT-1 logo Caution Only use cartridges designed specifically for S-AIT. Cleaning Cartridges To clean the read/write heads, use the S-AIT Cleaning Cartridge SAIT1-CL supplied with the unit. -
Page 10: Components And Functions
Components and Functions Front OPEN TAPE DRIVE TAPE CLEANING MOTION ERROR ERROR REQUEST A Front Door Used to protect the front of the unit. Press the DOOR button to unlock and open the door when inserting or removing cartridges. Note Even when the front door is closed and a cartridge is ejected by software, the cartridge does not come in contact with the door. -
Page 11: Power Indicator
Lights green when the unit is on. When it flashes, the cooling fan of the unit may be malfunctioning. If this is the case, verify that the cooling fan on the rear is operating normally. If it is not, contact your Sony service center. C Cartridge Slot Used to insert and remove cartridges. - Page 12 Drive Status The indicators of the S-AIT Tape Drive Unit show the status of the unit. This status is indicated by a combination of colors (green, orange, or yellow), and whether the indicators are lit or flashing. Refer to the table below for explanations about the meaning of indicator activity.
-
Page 13: Rear
Rear SAITe1300-S A SCSI ID Switch Used to set the SCSI ID of the S-AIT Tape Drive Unit. Upon shipment, the SCSI ID is 0. For details, see “Setting the SCSI ID (SAITe1300-S only)” on page 22. B RS-232C Connector For service use only. - Page 14 F Loop ID Jumpers These jumpers are functional when the topology is arbitrated loop. For details, see “Setting the Loop ID (SAITe1300-F only)” on page 23. G Fibre Channel Connector Connect the optical fiber cable for Fibre Channel. For details about connection, see “Connecting the Optical Fiber Cable for Fibre Channel (SAITe1300-F...
-
Page 15: Bottom
Bottom A Access Cover for Service Use Do not open this cover. For service use only. B Dip Switch Access Cover If you need to change the data compression settings, remove this cover to change the DIP switch settings. For details about setting the DIP switches, see “Setting the DIP Switches”... -
Page 16: About The Label
About the label A Model number The model number is located on the bottom of the unit, together with the serial number. Refer to the model and serial numbers on the label when seeking technical support. B Serial number The serial number is located on the bottom of the unit, together with the model number. -
Page 17: Overview
Installation Chapter Overview This chapter describes the general procedures for positioning the S-AIT Tape Drive Unit, connecting it to the host computer, and turning it on. This chapter also describes initial setup. Installation and setup procedures may vary slightly depending on your system. Unpacking Note You will need the box and packing materials if you wish to move or transport... -
Page 18: Package Contents
Package Contents After opening the package, make sure that all the following items are present. Contact your dealer if anything is missing. • S-AIT Tape Drive Unit (1) • Air filter unit (1) • Quick start guide (1) • CD-ROM (1) (containing this document, the quick start guide, and device drivers) •... -
Page 19: Setting The Dip Switches
Setting the DIP Switches By setting the DIP switches at the bottom of the S-AIT Tape Drive Unit, you can: • Choose whether to compress the data when recording. • Choose whether the host can control data compression. The default settings of the DIP switches is as follows. •... - Page 20 Block Size 1 2 3 4 5 6 7 8 Immediate WFM Custom-4 Reserved Reserved DC Control-1 DC Control-2 SWA settings (SAITe1300-F) SWA (SAITe1300-F) UA Control Block Size 1 2 3 4 5 6 7 8 Immediate WFM Custom-4 Reserved...
- Page 21 If you are using a SAITe1300-S (SCSI model), proceed to “Setting the SCSI ID (SAITe1300-S only)” on page 22. If you are using a SAITe1300-F (Fibre Channel interface model), proceed to “Setting the Loop ID (SAITe1300-F only)” on page 23.
-
Page 22: Setting The Scsi Id (Saite1300-S Only)
Setting the SCSI ID (SAITe1300-S only) The SCSI ID is a unique address that identifies the SAITe1300-S to the host. The default SCSI ID of the SAITe1300-S is 0. The unit can be configured to SCSI ID addresses ranging from 0 to 15 (or 0 to F) using the SCSI ID switch on the rear of the unit. -
Page 23: Setting The Loop Id (Saite1300-F Only)
Setting the Loop ID (SAITe1300-F only) You can set the Loop ID with the loop ID jumpers, if necessary. These jumpers are functional when the topology is arbitrated loop. When the jumpers are enabled, they acquire AL_PA through LIHA (Loop Initialization Hard Assigned). - Page 24 Arbitrated Loop Physical Addresses (AL_PA) and Loop IDs 8-bit 8-bit 8-bit 7-bit Loop ID 7-bit Loop ID 7-bit Loop ID AL_PA AL_PA AL_PA (Hex) (Decimal) (Hex) (Hex) (Decimal) (Hex) (Hex) (Decimal) (Hex) — — — — — — — — —...
-
Page 25: Installing The S-Ait Tape Drive Unit
Installing the S-AIT Tape Drive Unit The S-AIT Tape Drive Unit weights about 7 kg (15.4 lb.) and has the following dimensions. Make sure that the surface where you will install the S-AIT Tape Drive Unit is appropriate before installing the unit. Note Install the S-AIT Tape Drive Unit on a horizontal surface near an AC power outlet. -
Page 26: Connecting The Power Cable
The latest device drivers and documentation for the S-AIT Tape Drive Units are available online. Contact your dealer for details or visit the Sony Web site (http://www.sony.net/Products/storagesolution/). If you are using a SAITe1300-S (SCSI model), proceed to “Connecting the SCSI Bus Cable (SAITe1300-S only)”... -
Page 27: Connecting The Scsi Bus Cable (Saite1300-S Only)
Connecting the SCSI Bus Cable (SAITe1300-S only) Connect the SAITe1300-S (SCSI model) and the host computer with a SCSI cable. This section describes how to do so. Use an Ultra 160/m SCSI LVD cable commonly sold in stores to connect the unit to the SCSI bus. The SAITe1300-S uses a 68-pin half pitch connector. - Page 28 When the SAITe1300-S is one of several devices on the SCSI bus Turn off all SCSI devices on the SCSI bus, including the SAITe1300-S. Caution When connecting or disconnecting a SCSI cable to SCSI devices (including the SAITe1300-S), turn off all the SCSI devices. Failing to do so may result in damage.
-
Page 29: Connecting The Optical Fiber Cable For Fibre Channel (Saite1300-F Only)
Connecting the Optical Fiber Cable for Fibre Channel (SAITe1300-F only) The SAITe1300-F is equipped with an interface that complies with the Fibre Channel standards with the following specifications. • Short-wave laser • 200 MB/sec • Duplex LC Fibre Channel connectors The equipment (HBA, hub, switch, etc.) to be connected to the SAITe1300-F... -
Page 30: Configuring The S-Ait Tape Drive Unit To The Host
Configuring the S-AIT Tape Drive Unit to the Host Configure the S-AIT Tape Drive Unit as follows. Turn on the S-AIT Tape Drive Unit. For details, see “Turning the Unit On or Off” on page 31. To configure the unit for use, refer to the documentation of the host computer and software. -
Page 31: Overview
Operation Chapter Overview This chapter describes how to turn the unit on and off, as well as how to insert and eject cartridges. Turning the Unit On or Off Turning On the Unit Press the DOOR button to unlock and open the front door. Chapter 3 Operation... - Page 32 If this is the case, verify that the cooling fan on the rear is operating normally. If it is not, contact your Sony service center. • If the status indicators do not behave as described above, see chapter 1.
-
Page 33: Turning Off The Unit
Turning Off the Unit Press the DOOR button to unlock and open the front door. Press the power switch on the front panel. Caution Do not turn off the S-AIT Tape Drive Unit when it is in use or there is a cartridge in the unit, as this could damage data. -
Page 34: Removing A Cartridge
Apply gentle pressure to the back of the cartridge until the unit takes the cartridge and loads it. Caution Do not apply force to the cartridge after the unit starts loading it. Otherwise, the cartridge may rush out of the unit when it is ejected. Close the front door to minimize any contamination from airborne particles. -
Page 35: Compatible Cartridges
Using the Media Chapter Compatible Cartridges S-AIT Tape Drive Unit uses: • S-AIT data cartridges • S-AIT cleaning cartridges Only use the cartridges above with your S-AIT Tape Drive Unit. Do not use other types of cartridges, such as LTO Ultrium, SDLT, or DLT. Data Cartridge S-AIT data cartridges contain a half inch AME (Advanced Metal Evaporated) tape. -
Page 36: Components And Functions
This switch is used to prevent data from being written to the tape. For details, see “Setting the Write-protect Switch” on page 38. Note The Sony S-AIT Data Cartridge SAIT1-500 write-protect switch is orange. The Sony S-AIT Cleaning Cartridge SAIT1-CL write-protect switch is blue. Chapter 4 Using the Media... - Page 37 Bottom E Recognition Holes Used by the unit to determine the type of cartridge. S-AIT data cartridge recognition holes are all closed. S-AIT cleaning cartridge holes are closed except hole Caution Do not open the recognition holes as this may prevent the unit from recognizing the type of cartridge correctly.
-
Page 38: Setting The Write-Protect Switch
(REC) Cleaning Cartridge Use a Sony S-AIT Cleaning Cartridge SAIT1-CL to clean the drive heads. The unit determines when heads need to be cleaned and alerts you accordingly. For details about how to use the cleaning cartridge, see “Head Cleaning” on page 41. -
Page 39: Handling Cartridges
Handling Cartridges Handling or storing S-AIT cartridges incorrectly can damage them or their tapes. Follow the guidelines below to avoid damaging your cartridges. Handling precautions • Before using cartridges, let them acclimate themselves to the normal operating environment for at least 24 hours. •... -
Page 40: Usage, Storage, And Transport Environmental Specifications
Usage, Storage, and Transport Environmental Specifications Before using cartridges, let them acclimate themselves to the operating environment for at least 24 hours. Operating environment Temperature 5 to 35°C (41 to 95°F) Relative humidity 20 to 80% (non-condensing) Wet bulb temperature 26°C (79°F) Storage environment Temperature 16 to 32°C (61 to 90°F) -
Page 41: Head Cleaning
Appendix Head Cleaning The S-AIT Tape Drive Unit is equipped with an automatic head cleaning system and was developed to require only a minimum of cleaning. Yet, to maintain the unit in peak condition, the unit determines when head cleaning using a cleaning cartridge is necessary. -
Page 42: Changing The Air Filter Unit
Changing the Air Filter Unit We recommend that you replace the air filter unit at least once a year. Consult your dealer to purchase air filter units. Note We recommend that you clean the air filter unit once a month with a vacuum cleaner. -
Page 43: Hardware Reset
You can update the S-AIT Tape Drive Unit firmware by downloading the new version of the firmware to your unit through the SCSI bus. To obtain up-to-date firmware and installation instructions, contact your dealer or visit the Sony Web site (http://www.sony.net/Products/storagesolution/). -
Page 44: Avoiding Damage
Abnormal Occurrences If the unit behaves abnormally, or it begins to smell or smoke, unplug it immediately from the power outlet and contact your Sony service center. Cleaning the Cabinet Wipe the cabinet with a soft, dry cloth. For heavy dirt, wipe with a soft cloth moistened with a gentle detergent, and then wipe it again with a soft, dry cloth. -
Page 45: Troubleshooting
Troubleshooting Before contacting a Sony service center, verify the following. If the problem persists, contact your Sony service center. The unit does not start (the POWER indicator does not light) • Verify that the power cable is connected correctly and that it is not damaged. - Page 46 • Verify that the optical fiber cable is of the appropriate type. For details, see “Connecting the Optical Fiber Cable for Fibre Channel (SAITe1300-F only)” on page 29. • Verify that the Loop ID is set correctly. For details, see “Setting the Loop ID (SAITe1300-F only)”...
-
Page 47: Specifications
Specifications Performance Storage capacity 500 GB (uncompressed with 600 m S-AIT Data Cartridge) 1.3 TB (2.6:1 compression ratio with 600 m S-AIT Data Cartridge) Data transfer rate 30 MB/sec (uncompressed Burst data transfer rate 160 MB/s (maximum, synchronous, SCSI) 200 MB/s (maximum, Fibre Channel) Bit error rate Less than 10 Initialize time... -
Page 48: Power Specifications/Miscellaneous
Vibrations Operating swept sine 5 to 500 Hz 0.25G peak 1 Octave/min. Non-operating swept sine 5 to 500 Hz 0.5G peak 1 Octave/min. Shock Operating half sine 5G peak 3 ms (no data loss) Non-operating half sine 90G peak 2 ms (no unit damage) Power Specifications/Miscellaneous Power 100 V - 240 V AC ±... -
Page 49: Index
Index Model number ......16 Operation ........31 Air filter unit ......... 42 Optical fiber cable ......29 Appendix ........41 Options ......... 48 Avoiding damage ......44 Package contents ......18 Cartridges ..... 9, 33, 35, 39 Performance ......... 47 Changing air filter unit .... - Page 50 For information about the S-AIT Tape Drive Unit, contact your reseller. Sony Corporation...
