Hitachi CP-X2010 series Specification Sheet

CP-X2010 series
Closed Captioning

Key Features

• 2,200 ANSI Lumens
• Native XGA Resolution
• 500:1 Contrast Ratio
• 7.7 lbs.
• 2 RGB Inputs / 1 RGB Output
• Component / Composite /
S-Video Inputs
• 16 Watt Audio Output
Screen Size 4:3
Diagonal* Width*
30 24
60 48
80 64
100 80
120 96
150 120
200 160
300 240
Throw Ratio: 1.5 - 1.8:1 (distance : width)
*Measured in inches
For sales information, please call 800.225.1741
Printed 04.09
• Approx. 6,000 Hours (Eco Mode)*
• Security Bar & Transition Detector
• 29 dB (Eco Mode)
• Easily Accessible Hybrid Filter
(approx., 5,000 between maintenance)
• Instant On/Off
• Audio Pass Through
• Template Function
• Power Saving Mode
Throw Distance
Min* Max*
34 41
70 83
94 112
118 140
142 168
177 211
237 281
356 422

Specifications

Model Name
Liquid Crystal Panel Structure
Number of Pixels
Resolution Video
RGB
Colors
Aspect Ratio
Lens
Throw Ratio (distance : width)
Lamp
Brightness
Expected lamp Life
Contrast Ratio
Speaker Output
Power Supply
Power Consumption
Operating Temperature
Input Signals RGB
Composite Video
Component Video
Acoustic Noise Level
H-Sync
V-Sync
Vertical Keystone
Approvals
RGB Input Analog RGB
RGB Output RGB
Video Input S-Video
Composite Video
Component Video
Audio Input
Output
Control Terminals
Other
Dimensions (W x D x H)
Weight
Closed Caption
Additional Features
Supplied Accessories
Lamp
Remote Control
Filter
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage.
Hours of average lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
CP-X2010 Series
0.63" Polysilicon Active-matrix TFT x 3
786,432 Pixels
540 TV lines
1024 dots x 768 lines
16.7 million colors
Native 4:3 / 16:9 compatible
manual zoom x 1.2
1.5 - 1.8 : 1
210W UHP
2,200 ANSI lumens
Approximately 3,000 hours (normal) 6,000 hours (Eco mode)*
500 : 1
16W (2 speakers)
AC100 - 120V / AC220 - 240V 50/60 Hz Power
330W
5˚C - 35˚C (41˚F - 95˚F)
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, MAC13", MAC16"
NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N
480i, 576i, 480p, 720p, 1080i, 1080p
35 dB (29 dB in Eco mode)
15 kHz - 106 kHz
50 kHz - 120 kHz
+ / - 30˚
UL, C-UL, FCC, CE, RoHS
15-pin D-sub connector x 2
15-pin D-sub connector x 1
Mini DIN 4-pin connector x 1
RCA jack x 1
RCA jack x 3
Stereo mini jack x 2, RCA (L/R) x 1 pair
RCA (L/R) x 1 pair
9-pin D-sub connector x 1 (RS-232 control)
USB connector (USB mouse) x 1
12.5" x 11.3" x 3.9"
7.7 lbs.
CC1, CC2, CC3, CC4, T1, T2, T3, T4
Kensington Slot, Digital Gamma Correction, Whiteboard /
Blackboard Mode, Input Source Naming, MyMemory /
MyScreen / MyButtons / MyText, Auto V Keystone,
Serial Number on Side
Remote Control, Batteries (AA), RGB cable, US Power Cord,
Multiple language operator / Safety Manual
CPX2010LAMP (DT01021)
HL02483
MU06481
All specifications subject to change without notice
