S
UPER
H8DMU+
USER'S MANUAL
Revision 1.0c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H8DMU+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Supero H8DMU+

  • Page 1 UPER H8DMU+ USER’S MANUAL Revision 1.0c...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
  • Page 3: About This Manual

    Preface Preface About This Manual This manual is written for system integrators, PC technicians and knowledgeable PC users. It provides information for the installation and use of the H8DMU+ serverboard. The H8DMU+ is based on the nVidia® MCP55 Pro chipset and supports single or dual AMD Opteron 2000 Series Socket F type processors and up to 64 GB of DDR2-667/533/400 registered ECC SDRAM.
  • Page 4: Table Of Contents

    H8DMU+ User’s Manual Table of Contents Preface About This Manual ...................... iii Manual Organization ....................iii Chapter 1: Introduction Overview ......................1-1 Checklist ....................1-1 Contacting Supermicro ................1-2 H8DMU+ Image ..................1-3 H8DMU+ Layout ..................1-4 H8DMU+ Quick Reference ..............1-5 Serverboard Features ................
  • Page 5 Table of Contents Power Button ..................2-11 USB Ports ....................2-11 USB Headers ..................2-12 Serial Ports ..................... 2-12 Fan Headers ..................2-12 LAN1/2 (Ethernet Ports) ................. 2-12 Power LED/Speaker ................2-13 ATX PS/2 Keyboard/Mouse Ports ............2-13 Overheat LED ..................2-13 Chassis Intrusion ..................
  • Page 6 H8DMU+ User’s Manual Chapter 3: Troubleshooting Troubleshooting Procedures ................3-1 Before Power On ..................3-1 No Power ....................3-1 No Video ....................3-1 Memory Errors ..................3-2 Losing the System’s Setup Confi guration ..........3-2 Technical Support Procedures ............... 3-2 Frequently Asked Questions ................
  • Page 7: Chapter 1: Introduction

    Chapter 1: Introduction Chapter 1 Introduction Overview Checklist Congratulations on purchasing your computer serverboard from an acknowledged leader in the industry. Our boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your serverboard.
  • Page 8: Contacting Supermicro

    H8DMU+ User’s Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 9: H8Dmu+ Image

    Chapter 1: Introduction Figure 1-1. H8DMU+ Image...
  • Page 10 H8DMU+ User’s Manual Figure 1-2. H8DMU+ Serverboard Layout (not drawn to scale) JPW2 JPW1 Kybd/ FAN8/CPU2FAN FAN6 FAN1 Mouse CPU1 / DIMM 1B USB0/1 CPU1 / DIMM 1A CPU1 / DIMM 2B CPU1 / DIMM 2A CPU2 CPU1 / DIMM 3B CPU1 / DIMM 3A CPU1 / DIMM 4B FAN2...
  • Page 11: H8Dmu+ Quick Reference

    Chapter 1: Introduction H8DMU+ Quick Reference Jumper Description Default Setting JBT1 CMOS Clear See Section 2-7 JCF1 Compact Flash Card Master/Slave Closed (Master) Onboard Speaker Pins 6-7 (Enabled JPG1 Onboard VGA Enable/Disable Pins 1-2 (Enabled) C1/JI C to PCI-Express Enable/Disable Closed (Enabled) Watch Dog Pins 1-2 (Reset)
  • Page 12: Serverboard Features

    H8DMU+ User’s Manual Serverboard Features • Single or dual AMD 64-bit Socket F, Opteron 2000 type processors Memory • Sixteen dual/single channel DIMM slots supporting up to 64 GB of DDR2- 667/533/400 registered ECC SDRAM Note: Memory capacities are halved for single CPU systems. Refer to Section 2-4 before installing. Chipset •...
  • Page 13 Chapter 1: Introduction ACPI Features • Microsoft OnNow • Slow blinking LED for suspend state indicator • BIOS support for USB keyboard • Main switch override mechanism • Internal/external modem ring-on Onboard I/O • UIO (Universal Input/Output) ready • On-chip SATA controller supporting six (6) SATA ports (RAID 0, 1, 0+1, 5 and JBOD supported) •...
  • Page 14: System Block Diagram

    H8DMU+ User’s Manual DDR2-667/533/400 DDR2-667/533/400 128-bit data + 16-bit ECC 16 x 16 HT link (1 GHz) 128-bit data + 16-bit ECC DIMM 4B DIMM 4B DIMM 4A DIMM 4A DIMM 3B DIMM 3B AMD Socket F AMD Socket F DIMM 3A DIMM 3A Processor (CPU2)
  • Page 15: Chipset Overview

    Chapter 1: Introduction Chipset Overview The H8DMU+ serverboard is based on the nVidia MCP55 Pro chipset. The nVidia MCP55 Pro functions as Media and Communications Processor (MCP). Controllers for the system memory are integrated directly into the AMD Opteron processors. MCP55 Pro Media and Communications Processor The MCP55 Pro is a single-chip, high-performance HyperTransport peripheral con- troller.
  • Page 16: Pc Health Monitoring

    H8DMU+ User’s Manual PC Health Monitoring This section describes the PC health monitoring features of the H8DMU+. The serverboard has an onboard System Hardware Monitor chip that supports PC health monitoring. Onboard Voltage Monitors The onboard voltage monitor will scan these voltages continuously: CPU cores, Hyper Transport (1.2V), memory banks (1.8V), 1.5V, MCP55 Core, 3.3V, 12V, - 12V, 5V, VSB and battery voltage.
  • Page 17: Power Confi Guration Settings

    Chapter 1: Introduction Power Confi guration Settings This section describes the features of your serverboard that deal with power and power settings. Microsoft OnNow The OnNow design initiative is a comprehensive, system-wide approach to system and device power control. OnNow is a term for a PC that is always on but appears to be off and responds immediately to user or other requests.
  • Page 18: Power Supply

    H8DMU+ User’s Manual Wake-On-Ring Header (JWOR) Wake-up events can be triggered by a device such as the external modem ringing when the system is in the SoftOff state. Note that external modem ring-on can only be used with an ATX 2.01 (or above) compliant power supply. Power Supply As with all computer products, a stable power source is necessary for proper and reliable operation.
  • Page 19: Super I/O

    Chapter 1: Introduction Super I/O The disk drive adapter functions of the Super I/O chip include a fl oppy disk drive controller that is compatible with industry standard 82077/765, a data separator, write pre-compensation circuitry, decode logic, data rate selection, a clock genera- tor, drive interface control logic and interrupt and DMA logic.
  • Page 20: Uio

    H8DMU+ User’s Manual The H8DMU+ is a specially-designed serverboard that features Supermicro's UIO (Universal I/O) technology. UIO serverboards have a PCI-Express x4, x8 and x16 signals that can support PCI-E cards or any one of several types of UIO card types to add SAS ports, additional LAN ports, Infi...
  • Page 21: Chapter 2: Installation

    Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system board, it is important to handle it very carefully. The following measures are generally suffi cient to protect your equipment from ESD. Precautions •...
  • Page 22: Processor And Heatsink Installation

    H8DMU+ User's Manual Processor and Heatsink Installation Exercise extreme caution when handling and installing the proces- sor. Always connect the power cord last and always remove it be- fore adding, removing or changing any hardware components. CPU Backplates Two CPU backplates (BKT-0011L) have been preinstalled to the serverboard to prevent the CPU area of the serverboard from bending and to provide a base for attaching the heatsink retention modules.
  • Page 23 Chapter 2: Installation 3. Align pin 1 of the CPU with pin 1 of the socket. Once aligned, carefully place the CPU into the socket. Do not drop the CPU on the socket, move the CPU horizontally or vertically or rub the CPU against the socket or against any pins of the socket, which may damage the CPU and/or the socket.
  • Page 24 H8DMU+ User's Manual Installing the Heatsink Retention Modules Two heatsink retention modules (BKT-0012L) and four screws are included in the retail box. Once installed, these are used to help attach the heatsinks to the CPUs. To install, align the module with the standoffs of the preinstalled CPU backplate and with the four feet on the module contacting the serverboard.
  • Page 25: Mounting The Serverboard Into A Chassis

    Chapter 2: Installation Mounting the Serverboard into a Chassis All serverboards and motherboards have standard mounting holes to fi t different types of chassis. Make sure that the locations of all the mounting holes for both the serverboard and the chassis match. Although a chassis may have both plastic and metal mounting fasteners, metal ones are highly recommended because they ground the serverboard to the chassis.
  • Page 26 H8DMU+ User's Manual Support The H8DMU+ supports single or dual-channel, DDR2-667/533/400 registered ECC SDRAM. Both interleaved and non-interleaved memory are supported, so you may populate any number of DIMM slots (see note on previous page and chart on following page). The CPU2 DIMM slots can only be accessed when two CPUs are installed (however, the CPU2 DIMM slots are not required to be populated when two CPUs are installed).
  • Page 27 Chapter 2: Installation Populating Memory Banks for 128-bit Operation CPU1 CPU1 CPU1 CPU1 CPU2 CPU2 CPU2 CPU2 1A/1B 2A/2B 3A/3B 4A/4B 1A/1B 2A/2B 3A/3B 4A/4B Notes: X indicates a pair of populated DIMM slots. If adding at least four DIMMs (with two CPUs installed), the confi...
  • Page 28: I/O Port And Control Panel Connections

    H8DMU+ User's Manual I/O Port and Control Panel Connections The I/O ports are color coded in conformance with the PC99 specifi cation to make setting up your system easier. See Figure 2-3 below for the colors and locations of the various I/O ports. Figure 2-3.
  • Page 29: Connecting Cables

    Chapter 2: Installation Connecting Cables ATX Power 20-pin Connector Pin Defi nitions (JPW1) ATX Power Connector Pin# Defi nition Pin # Defi nition The primary ATX power supply con- +3.3V +3.3V nector (JPW1) meets the SSI (Super- -12V +3.3V set ATX) 20-pin specifi cation. Refer to the table on the right for the pin PS_ON defi...
  • Page 30: Hdd Led

    H8DMU+ User's Manual HDD LED HDD LED Pin Defi nitions (JF1) The HDD (IDE Hard Disk Drive) LED Pin# Defi nition connection is located on pins 13 and See below* 14 of JF1. Attach the IDE hard drive HDD Active LED cable to display disk activity.
  • Page 31: Power Fail Led

    Chapter 2: Installation Power Fail LED Power Fail LED The Power Fail LED connection is Pin Defi nitions (JF1) located on pins 5 and 6 of JF1. Refer Pin# Defi nition to the table on the right for pin defi ni- tions.
  • Page 32: Usb Headers

    H8DMU+ User's Manual USB Headers Universal Serial Bus Headers Pin Defi nitions (USB4/5/6/7) Four additional USB2.0 headers USB2 USB3/4 Pin # Defi nition Pin # Defi nition (USB4/5 and USB6/7) are included on the serverboard. These may be con- nected to provide front side access. A USB cable (not included) is needed Ground Ground...
  • Page 33: Power Led/Speaker

    Chapter 2: Installation Power LED/Speaker PWR LED Connector Pin Defi nitions (JD1) Pin# Defi nition On JD1, pins 1, 2, and 3 are for the +Vcc power LED and pins 4 through 7 are for the speaker. See the tables on the Control right for pin defi...
  • Page 34: Wake-On-Lan

    H8DMU+ User's Manual Wake-On-LAN Wake-On-LAN Pin Defi nitions The Wake-On-LAN header is desig- (JWOL) nated JWOL. See the table on the Pin# Defi nition right for pin defi nitions. You must +5V Standby have a LAN card with a Wake-On-LAN Ground connector and cable to use the Wake- Wake-up...
  • Page 35: Compact Flash Power

    Chapter 2: Installation Compact Flash Power Compact Flash Power Header Pin Defi nitions (JWF1) Compact Flash Card Power Pin# Defi nition Connector is located at JWF1. For the Compact Flash Card to work Ground properly, you will fi rst need to connect Signal the device's power cable to JWF1 and correctly set the Compact Flash...
  • Page 36: Jumper Settings

    H8DMU+ User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the Connector serverboard, jumpers can be used to Pins choose between optional settings. Jumpers create shorts between two pins to change the function of the Jumper connector. Pin 1 is identifi ed with a square solder pad on the printed circuit board.
  • Page 37: Vga Enable/Disable

    Chapter 2: Installation VGA Enable/Disable VGA Enable/Disable Jumper Settings (JPG1) JPG1 allows you to enable or disable the VGA port. The default position is Jumper Setting Defi nition on pins 1 and 2 to enable VGA. See Pins 1-2 Enabled the table on the right for jumper set- Pins 2-3 Disabled...
  • Page 38: Compact Flash Master/Slave

    H8DMU+ User's Manual Compact Flash Master/Slave Compact Flash Master/Slave Jumper Settings (JCF1) The JCF1 jumper allows you to assign Jumper Setting Defi nition either master or slave status a compact Closed Master fl ash card installed in IDE1. See the table on the right for jumper settings.
  • Page 39: Onboard Indicators

    Chapter 2: Installation Onboard Indicators LAN1/LAN2 LEDs LAN LED (Connection Speed Indicator) The Ethernet ports (located beside LED Color Defi nition the VGA port) have two LEDs. On 10/100 MHz each Gb LAN port, one LED indicates Amber 1 GHz activity when blinking while the other LED may be amber or off to indicate the speed of the connection.
  • Page 40: Floppy, Ide And Sata Drive Connections

    H8DMU+ User's Manual Floppy, IDE and SATA Drive Connections Use the following information to connect the fl oppy and hard disk drive cables. The fl oppy disk drive cable has seven twisted wires. A red mark on a wire typically designates the location of pin 1. A single fl...
  • Page 41: Ide Connector

    Chapter 2: Installation IDE Connector IDE Drive Connector Pin Defi nitions (IDE#1) Pin# Defi nition Pin # Defi nition There are no jumpers to con- fi gure the onboard IDE#1 con- Reset IDE Ground nector. See the table on the Host Data 7 Host Data 8 right for pin defi...
  • Page 42: 2-10 Enabling Sata Raid

    H8DMU+ User's Manual 2-10 Enabling SATA RAID Serial ATA (SATA) Serial ATA (SATA) is a physical storage interface that employs a single cable with a minimum of four wires to create a point-to-point connection between devices. This connection is a serial link. The serial cables used in SATA are thinner than the traditional cables used in Parallel ATA (PATA) and can extend up to one meter in length, compared to only 40 cm for PATA cables.
  • Page 43 Chapter 2: Installation 2. Use the arrow keys to move to Advanced > Floppy/IDE/SATA Confi guration > nVidia RAID Setup and press the <Enter> key. Once in the submenu, enable the "nVidia RAID Function" setting. 3. Hit the <F10> key to "Save Changes and Exit", then hit <Enter> to verify. 4.
  • Page 44 H8DMU+ User's Manual Figure 2-5. SATA RAID Utility: Main Screen Figure 2-6. SATA RAID Utility: Array List 2-24...
  • Page 45: 2-11 Installing Drivers

    Chapter 2: Installation 2-11 Installing Drivers After all the hardware and operating system have been installed, you need to install certain drivers. The necessary drivers are all included on the Supermicro CD that came packaged with your serverboard. After inserting this CD into your CD-ROM drive, the display shown in Figure 2-7 should appear.
  • Page 46 H8DMU+ User's Manual Notes 2-26...
  • Page 47: Chapter 3: Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any hardware components.
  • Page 48: Memory Errors

    H8DMU+ User's Manual NOTE If you are a system integrator, VAR or OEM, a POST diagnostics card is recommended. For I/O port 80h codes, refer to App. B. Memory Errors 1. Make sure that the DIMM modules are properly and fully installed. 2.
  • Page 49: Frequently Asked Questions

    Chapter 3: Troubleshooting 3. If you still cannot resolve the problem, include the following information when contacting us for technical support: Serverboard model and PCB revision number BIOS release date/version (this can be seen on the initial display when your system fi...
  • Page 50: Returning Merchandise For Service

    H8DMU+ User's Manual Question: Why can't I turn off the power using the momentary power on/off switch? Answer: The instant power off function is controlled in BIOS by the Power But- ton Mode setting. When the On/Off feature is enabled, the serverboard will have instant off capabilities as long as the BIOS has control of the system.
  • Page 51: Chapter 4: Bios

    Chapter 4: BIOS Chapter 4 BIOS Introduction This chapter describes the AMIBIOS™ Setup utility for the H8DMU+. The AMI ROM BIOS is stored in a fl ash chip and can be easily upgraded using a fl oppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.
  • Page 52: Main Menu

    H8DMU+ User’s Manual Main Menu When you fi rst enter AMI BIOS Setup Utility, you will see the Main Menu screen. You can always return to the Main Menu by selecting the Main tab on the top of the screen with the arrow keys. The Main Menu screen provides you with a system overview, which includes the version, built date and ID of the AMIBIOS, the type, speed and number of the processors in the system and the amount of memory installed in the system.
  • Page 53 Chapter 4: BIOS Advanced ACPI Confi guration MCP55 ACPI HPET Table Use this setting to Enable or Disable the MCP55 ACPI HPET Table. ACPI Version Features Use this setting the determine which ACPI version to use. Options are ACPI v1.0, ACPI v2.0 and ACPI v3.0. ACPI APIC Support Determines whether to include the ACPI APIC table pointer in the RSDT pointer list.
  • Page 54 H8DMU+ User’s Manual MPS Revision This setting allows the user to select the MPS revision level. The options are MPS Revision 1.1 and 1.4. This setting allows the user to select the MPS revision level. The options are 1.1 and 1.4. POST Debugger Enable this setting to give the status of the AMI POST debugger in the next boot up.
  • Page 55 Chapter 4: BIOS Primary IDE Master/Slave Highlight one of the items above and press <Enter> to access the submenu for that item. Type Select the type of device connected to the system. The options are Not Installed, Auto, CDROM and ARMD. LBA/Large Mode LBA (Logical Block Addressing) is a method of addressing data on a disk drive.
  • Page 56 H8DMU+ User’s Manual DMA Mode Selects the DMA Mode. Options are Auto, SWDMA0, SWDMA1, SWDMA2, MWDMA0. MDWDMA1, MWDMA2, UDMA0. UDMA1, UDMA2, UDMA3, UDMA4 and UDMA5. (SWDMA=Single Word DMA, MWDMA=Multi Word DMA, UDMA=UltraDMA.) S.M.A.R.T. Self-Monitoring Analysis and Reporting Technology (SMART) can help predict impending drive failures.
  • Page 57 Chapter 4: BIOS decreases. The options are Auto, 0, 1, 2, 3, and 4. Select Auto to allow AMI BIOS to auto detect the PIO mode. Use this value if the IDE disk drive support cannot be determined. Select 0 to allow AMI BIOS to use PIO mode 0. It has a data transfer rate of 3.3 MBs.
  • Page 58 H8DMU+ User’s Manual PCI/PnP Confi guration Load Onboard LAN Option ROM Use this setting to Enable or Disable the onboard option ROM. Clear NVRAM Select Yes to clear NVRAM during boot-up. The options are Yes and No. Plug & Play OS Select Yes to allow the OS to confi...
  • Page 59: Advanced Chipset Control

    Chapter 4: BIOS Advanced Chipset Control NorthBridge Confi guration Memory Confi guration Memclock Mode This setting determines how the memory clock is set. Auto has the memory clock by code and Limit allows the user to set a standard value. MCT Timing Mode Sets the timing mode for memory.
  • Page 60 H8DMU+ User’s Manual ECC Confi guration DRAM ECC Enable DRAM ECC allows hardware to report and correct memory errors automati- cally. Options are Enabled and Disabled. 4-Bit ECC Mode Allows the user to enabled 4-bit ECC mode (also known as ECC Chipkill).
  • Page 61 Chapter 4: BIOS SouthBridge Confi guration USB 1.1 Controller Enable or disable the USB 1.1 controller. USB 2.0 Controller Enable or disable the USB 2.0 controller. MAC0 LAN0 Settings are Auto and Disabled for MAC0 LAN0. MAC0 LAN0 Bridge Settings are Enabled and Disabled for MAC0 LAN0 bridge. MAC1 LAN1 Settings are Auto and Disabled for MAC1 LAN1.
  • Page 62 H8DMU+ User’s Manual Processor & Clock Options This submenu lists CPU information and the following settings: MTRR Mapping This determines the method used for programming CPU MTRRs when 4 GB or more memory is present. The options are Continuous, which makes the PCI hole non- cacheable, and Discrete, which places the PCI hole below the 4 GB boundary.
  • Page 63: Console Redirection

    Chapter 4: BIOS Mark All Events as Read Highlight this item and press <Enter> to mark all events as read. Clear Event Log Select Yes and press <Enter> to clear all event logs. The options are Yes and No to verify. Console Redirection Remote Access Allows you to Enable or Disable remote access.
  • Page 64 H8DMU+ User’s Manual Sredir Memory Display Delay Use this setting to set the delay in seconds to display memory information. Op- tions are No Delay, 1 sec, 2 secs and 4 secs. System Health Monitor CPU Overheat Alarm Use the "+" and "-" keys to set the CPU temperature threshold to between 65 and 90 C.
  • Page 65 Chapter 4: BIOS IPMI Confi guration View BMC System Event Log Pressing the Enter key will open the following settings. Use the "+" and "-" keys to navigate through the system event log. Clear BMC System Event Log Selecting this and pressing the Enter key will clear the BMC system event log. Set LAN Confi...
  • Page 66: Boot Menu

    H8DMU+ User’s Manual Startup Delay Use this setting to Enable or Disable the startup delay. Event Message for PEF Action Use this setting to Enable or Disable event messages for a PEF action. BMC Watch Dog Timer Action This setting is used to set the Watch Dog function. The options are Disabled, Reset System, Power Down and Power Cycle.
  • Page 67: Security Menu

    Chapter 4: BIOS Security Menu AMI BIOS provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set fi rst. Change Supervisor Password Select this option and press <Enter> to access the sub menu, and then type in the password.
  • Page 68: Exit Menu

    H8DMU+ User’s Manual Exit Menu Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system confi guration changes, select this option to leave BIOS Setup and reboot the computer, so the new system confi guration parameters can take effect.
  • Page 69: Appendix A: Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 70 H8DMU+ User’s Manual Notes...
  • Page 71: Appendix B: Bios Post Checkpoint Codes

    Appendix B: BIOS POST Checkpoint Codes Appendix B BIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
  • Page 72 H8DMU+ User’s Manual Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard fl oppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next. Initializing the DMA and Interrupt controllers next.
  • Page 73 Appendix B: BIOS POST Checkpoint Codes Uncompressed Initialization Codes The following runtime checkpoint codes are listed in order of execution. These codes are uncompressed in F0000h shadow RAM. Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built.
  • Page 74 H8DMU+ User’s Manual Checkpoint Code Description Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete. Confi guring the mono- chrome mode and color mode settings next.
  • Page 75 Appendix B: BIOS POST Checkpoint Codes Checkpoint Code Description The memory below 1 MB has been cleared via a soft reset. Clearing the memory above 1 MB next. The memory above 1 MB has been cleared via a soft reset. Saving the memory size next.
  • Page 76 H8DMU+ User’s Manual Checkpoint Code Description The password was checked. Performing any required programming before WIN- BIOS Setup next. The programming before WINBIOS Setup has completed. Uncompressing the WINBIOS Setup code and executing the AMIBIOS Setup or WINBIOS Setup utility next.
  • Page 77 Appendix B: BIOS POST Checkpoint Codes Checkpoint Code Description Returned from adaptor ROM at E000h control. Performing any initialization required after the E000 option ROM had control next. Initialization after E000 option ROM control has completed. Displaying the system confi guration next. Uncompressing the DMI data and executing DMI POST initialization next.
  • Page 78 H8DMU+ User’s Manual Notes...
