DeLonghi EO 3835.A Instructions For Use Manual

CONTENTS
CHAPTER 1 GENERAL
1.1 Specifications
1.2 Description of the oven and the accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.3 Summary of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
CHAPTER 2 USE OF THE OVEN AND REFERENCE COOKING TIMES
2.1 Use of the controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.2 Tips on use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
2.3 How to set the functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
• Keeping food warm
• Delicate cooking (if fitted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
• Oven cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
• Grilling and cooking au gratin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
• Grilling with the turnspit (if fitted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
CHAPTER 3 CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

1.1 - SPECIFICATIONS

Operating voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .see rating plate
Maximum power absorbed . . .
POWER CONSUMPTION (CENELEC STANDARD HD 376)
To reach 200°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.25 KWh
To maintain 200°C for one hour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.75 KWh
Total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 KWh
This appliance conforms to EC directive 2004/108/EC on Electromagnetic Compatibility and EC regulation
no. 1935/2004 of 27/10/2004 on materials intended for contact with food..
Important information for correct disposal of the product in accordance with EC Directive 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special
local authority differentiated waste collection centre or to a dealer providing this service. Disposing of a hou-
sehold appliance separately avoids possible negative consequences for the environment and health deri-
ving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant
savings in energy and resources.As a reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
Electrical connection (UK only)
A) If your appliance comes fitted with a plug, it will incorporate a 13
Amp fuse. If it does not fit your socket, the plug should be cut off
from the mains lead, and an appropriate plug fitted, as below.
WARNING: Very carefully dispose of the cut off plug after remo-
ving the fuse: do not insert in a 13 Amp socket elsewhere in the
house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must be
protected by a 15 Amp fuse. If the plug is a moulded-on type, the
fuse cover must be re-fitted when changing the fuse using a 13
IMPORTANT
The wires in the mains lead are coloured in accordance with the fol-
lowing code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
C H A P T E R 1 - G E N E R A L
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .see rating plate
B)
As the colours of the wires in the mains lead may not correspond
with the coloured markings identifying the terminals in your plug,
proceed as follows: The green and yellow wire must be connected to
the terminal in the plug marked with the letter E or the earth symbol
connected to the terminal marked with the letter N or coloured black.
The brown wire must be connected to the terminal marked with the
letter L or coloured red.
Amp Asta approved fuse to BS 1362. In the event of losing the
fuse cover, the plug must NOT be used until a replacement fuse
cover can be obtained from your nearest electrical dealer. The
colour of the correct replacement fuse cover is that as marked on
the base of the plug.
If your appliance is not fitted with a plug, please follow the instruc-
tions provided below:
WARNING - THIS APPLIANCE MUST BE EARTHED
or coloured green or green and yellow. The blue wire must be
13
