SECTION 14

UT-115 (OPTIONAL UNIT)

14-1 BOARD LAYOUT

• TOP VIEW
1
10
1 16
8 9
25 1
20
100
26
11
50 76
51 75
• BOTTOM VIEW
16 1
17 64
13
32 49
33 48
24
1 8
4 5
12
1
5 4
8 1
14 - 1
J301
1 PTTIN_C AGND 30
PTTOUT 5V
DMOD VCC_8V
AMODIN TXD
F_RXD 232_TX
BUSY_C 232_RX
RES RMUTE
NC FMDET
NC DAFOUT
NC REFMOD
NC NC
GND FLASH
GND RXD_2_C
P01 TXD_2_C
15 NC
NC 16
to the IC-2200H
LOGIC unit J4
