Thermos C34G Product Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

© 2013 Char-Broil, LLC Columbus, GA 31902
PRODUCT GUIDE
MODEL 461334813
Thermos C34G
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-800-241-7548.
Printed in China
See rating label on grill for serial number.
Assembly instructions © 2013
09/03/12 • G451-001-270801

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thermos C34G and is the answer not in the manual?

Questions and answers

Related Manuals for Thermos Thermos C34G

Summary of Contents for Thermos Thermos C34G

  • Page 1 PRODUCT GUIDE MODEL 461334813 Thermos C34G IMPORTANT: Fill out the product record information below. Serial Number See rating label on grill for serial number. Date Purchased For support and to register your grill, please visit us at www.charbroil.com If you have questions or need assistance during assembly, please call 1-800-241-7548.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DANGER For Your Safety ........2-3 If you smell gas: Grilling Guide.

  • Page 3: Grease Fires

    WARNING CAUTION Using pots larger than 6 quarts in capacity could CALIFORNIA PROPOSITION 65 exceed weight limit of the 1. Combustible by-products produced when using side burner shelf this product contains chemicals known to the State or side shelf, of California to cause cancer, birth defects, or resulting in failure other reproductive harm.

  • Page 4: Grilling Guide

    Temperature - Convective Grills ONLY. GRILLING GUIDE – Getting Started The temperature gauge in the hood of your new grill measures air temperature. The air temperature inside your grill will never First Time Use be as hot as the temperature at the cooking surface. Read your Assembly Manual and ensure the grill is put together properly.
  • Page 5 Rotisserie Cooking GRILLING GUIDE – Grilling 101 Rotisserie cooking is best for 'round' meat, such as large roasts, whole poultry, and pork. It generally requires an accessory motor Outdoor grilling is really quite simple. You'll succeed with and spit rod that allows the meat to be turned at a constant burgers, dogs, or steaks usually on your very first try.
  • Page 6 Wood Chips GRILLING GUIDE – Tips & Tricks For extra smoke flavor when grilling, try adding wood chips. Cooking on your new grill is a hands-on experience, and it is Soak the chips in water for approximately 30 minutes before recommended to remain outside with your grill while cooking.
  • Page 7 Gear Trax Painted surfaces: Wash with mild detergent or non-abrasive accessories. Please visit charbroil.com for a complete list cleaner and warm water. Wipe dry with a soft non-abrasive cloth. of Gear Trax accessories. *Available on most models.

  • Page 8: Use And Care

    LP Cylinder USE AND CARE •The LP cylinder used with your grill must meet the following requirements: DANGER •Use LP cylinders only with these required measurements: 12" (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum. •...
  • Page 9 LP Cylinder Exchange Connecting Regulator to the LP Cylinder •Many retailers that sell grills offer you the option of replacing 1.LP cylinder must be properly secured onto grill. (Refer to your empty LP cylinder through an exchange service. Use only assembly section.) those reputable exchange companies that inspect, precision fill, 2.Turn all control knobs to the OFF position.
  • Page 10 Leak Testing Valves, Hose and Regulator 1.Turn all grill control knobs to OFF. 2.Be sure regulator is tightly connected to LP cylinder. 3.Completely open LP cylinder valve by turning hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
  • Page 11 Safety Tips WARNING Before opening LP cylinder valve, check the coupling nut for ▲ tightness. When grill is not in use, turn off all control knobs and LP ▲ cylinder valve. For Safe Use of Your Grill and to Avoid Serious Never move grill while in operation or still hot.
  • Page 12 Burner Flame Check WARNING • Remove cooking grates and flame tamers. Light burners, rotate knobs from HIGH to LOW. You should see a smaller flame in LOW position than seen on HIGH. Perform burner flame check Turn controls and gas source or tank OFF when not on sideburner, also.

  • Page 13: Spider Alert

    3. Remove carryover tubes and burners. CAUTION Detach electrode from burner. NOTE: Removal/Detachment method will depend on the burner configuration. See different configurations in SPIDER ALERT! illustrations below. 5. Carefully lift each burner up and away from valve openings. We suggest three ways to clean the burner tubes. Use the one SPIDER AND WEBS easiest for you.

  • Page 14: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 15: Parts List

    PARTS LIST Qty Description NOT Pictured LEFT LEG ASSEMBLY … PRODUCT MANUAL, ENGLISH MATCH HOLDER … PRODUCT MANUAL, SPANISH … HARDWARE PACK RIGHT LEG ASSEMBLY BOTTOM SHELF TANK THUMBSCREW REAR CART BRACE AXLE ROD WHEEL LEG EXTENDER TANK EXCLUSION WIRE FRONT PANEL TOP LID TEMPERATURE GAUGE...

  • Page 16: Parts Diagram

    PARTS DIAGRAM...

  • Page 17: Assembly

    ASSEMBLY Place bottom shelf with cut out hole for LP tank next to legs with axle holes. Attach to right and left leg assemblies with 1/4-20x1-1/2" screws and 1/4-20 flange nuts. Left Leg Assembly Bottom Shelf Right Leg Assembly 1/4-20 1/4-20x1-1/2"...
  • Page 18 Attach the lower front panel to legs with #8x3/8" sheet metal screws. ASSEMBLY Attach the upper front panel to legs and lower front panel with #8x3/8" sheet metal screws. #8x3/8" Sheet Metal Screw Qty. 9 Lower Front Panel Upper Front Panel...
  • Page 19 Turn assembly upside down. Insert axle rod through wheel, axle spacer, legs and other axle spacer and wheel. Attach with (1) 8mm flat washer and hitch pin. Push leg extenders into right legs. Leg Extender 1” Hitch Pin Axle Rod Wheel Qty.
  • Page 20 This step requires two people to lift and position grill head onto cart. Carefully lower the grill head onto the cart. Make sure the regulator hose is hanging outside the cart. Attach with 1/4-20x1/2" machine screws. 1/4-20x1/2" Machine Screw Grill Head Qty 4 Regulator Hose...
  • Page 21 Install right side shelf onto the pre-installed screws located on the right side of firebox (A). Tighten the pre-installed screws securely. Attach side shelf with (2) 1/4-20x1/2" screws as shown (B). 1/4-20x1/2" Screw Tighten the screws 1/4-20x1/2" Machine Screw Qty. 2 Attach fascia to firebox with #8x3/8"...
  • Page 22 Install left side shelf onto the pre-installed screws located on the right side of firebox (A). Tighten the pre-installed screws securely. Attach side shelf with (2) 1/4-20x1/2" screws as shown (B). 1/4-20x1/2" Screw 1/4-20x1/2" Machine Screw Tighten the screws Qty. 2 Attach fascia to firebox with #8x3/8"...
  • Page 23 Place heat tents over burners by inserting tabs into slots in front of firebox. Note: Notch on the end of heat tents should fit over protrusions on the rear wall of firebox. Place cooking grates onto grate rests. Cooking Grate...
  • Page 24 Hang grease cup clip from bottom of firebox and place grease cup into grease cup clip. Grease Cup Clip Grease Cup CAUTION Failure to install grease cup clip and cup will cause hot grease to drip from bottom of grill with risk of fire or property damage. LP tank is sold separately.

  • Page 25: Troubleshooting

    DANGER: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from •Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
  • Page 26 Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light PIEZO PUSH-BUTTON AND ROTARY: using ignitor. •Push-button sticks at bottom. •Replace ignitor. •Rotary knob rotates without clicking. •Replace knob. •Sparking between ignitor and electrode. •Inspect wire insulation and proper connection. Replace wires if insulation is broken.
