Creative Inspire 6.1 6600 Quick Start Manual

MMS6200 CLI QSG 9/26/02 10:21 AM
English
LIMITED HARDWARE WARRANTY
Creative Technology Ltd ("Creative") warrants the product enclosed
herein to be free of defects for a period of twelve (12) months from
date of purchase. In the event of a defect in material or workmanship
during the warranty period, Creative, at its sole discretion, will either
repair or replace the defective product when the defective product is
returned to Creative by the owner as further outlined herein. The
remedy for this breach of warranty is limited to servicing or
replacement only and shall not cover any other damages, whatsoever.
CREATIVE SPECIFICALLY DISCLAIMS ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY,
NON-INFRINGEMENT AND FITNESS FOR A PARTICULAR
PURPOSE. WITH RESPECT TO THE USE OF THIS PRODUCT, IN
NO EVENT SHALL CREATIVE BE LIABLE FOR ANY LOSS OF
PROFIT OR ANY COMMERCIAL DAMAGE, INCLUDING BUT NOT
LIMITED TO SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR
OTHER DAMAGES. Some states/countries do not allow exclusion of
limitation of liability for consequential or incidental damages, in which
case the above limitation may not apply to you.
Creative makes final determination whether such product is defective.
You must deliver the product with a return material authorization
(RMA) number and a dated proof of purchase.
To receive an RMA number, contact Creative's Technical Support. If
Creative's Technical Support verifies the product is defective, the Return
Material Authorization Department will issue an RMA number to note
on the outer package of the product being returned. Creative cannot
accept any product that does not include an RMA number on the package.
You must use the original container (or the equivalent), pay any
shipping charges, and assume the risk of damage or loss in transit.
Creative may use new or reconditioned parts, and any replaced parts
or product become the property of Creative. Creative warrants the
repaired or replacement product to be free from defects in material
and workmanship for the remainder of the initial warranty period.
CUSTOMER SERVICE / TECHNICAL SUPPORT
Enjoy a host of benefits by registering your product at
www.creative.com/register
Benefits include:
• Service and Technical Support
• Exclusive updates on promotions and events
Inside U. S. A., Canada and Latin America
Visit our online help websites for help with installation, answers to frequently
asked questions, or troubleshooting tips. Our websites hold a wealth
of information as well as up-to-the-minute software and driver upgrades.
http://www.americas.creative.com/support/
For comments or questions regarding our technical support, you can
also contact us at the following address:
Creative Labs Inc.
Technical Support
1523 Cimarron Plaza
Stillwater, OK 74075
Inside Asia
Creative Technology Ltd.
To reach Technical Support via the Internet, visit our web site at
http://asia.creative.com/support
Technical Support
31 International Business Park
Creative Resource
Singapore 609921
Tel: 65-6895-4100
Operating hours (Singapore Time):
Mon-Fri 9:00 a.m.-6:00 p.m.
Sat-Sun & Public Holidays closed
English Français
Important Safety Instructions
Instructions importantes
concernant la sécurité
Read and Follow
Instructions Lire et suivre les instructions
All safety and operating Lisez et suivez attentivement
instructions should be read toutes les instructions de sécurité
and followed. et d'utilisation.
Cleaning Nettoyage
Unplug the power supply Débranchez l'adaptateur de la
adapter from the wall outlet or prise murale ou de toute autre
power source before source électrique avant de
cleaning. Do not use liquid procéder au nettoyage de
cleaners or aerosol l'appareil. N'utilisez pas de
cleaners.Use a damp cloth for nettoyants liquides ou en aérosol.
cleaning. Utilisez un chiffon humide.
Placement Positionnement des haut-
Do not place the speaker parleurs
system on an unstable cart, N'installez pas le système de
stand, tripod, bracket, or haut-parleurs sur une table
table. roulante, un trépied, une console
ou tout autre support instable.
The speaker may fall, causing
injury to a person, and Le système de haut-parleurs
serious damage to the risque de tomber et d'être
product. sérieusement endommagé mais
également de blesser une personne.
Power Sources
This speaker system is Sources d'alimentation
specifically designed for Ce système de haut-parleurs est
operation within the electrical spécialement conçu pour
range(s) specified on the fonctionner avec les tensions
provided power adapter and électriques indiquées sur la prise
use outside of this range shall d'alimentation fournie. L'utilisation
be at your own risk. de tensions non préconisées est à
votre propre risque.
Please contact your local
electric utility company if you Contactez votre compagnie
have any questions about the d'électricité pour toute question
electrical voltage at your concernant la tension électrique à
intended location of usage. l'endroit d'utilisation prévu.
Servicing Réparation
Do not attempt to service any N'essayez pas de réparer le
part of the speaker yourself système de haut-parleurs vous
as opening or removing même. Ouvrir ou retirer les parties
covers may expose you to protectrices de l'appareil peut vous
dangerous voltage or other exposer à des composants
électriques sous haute tension ou
hazards. Refer all servicing to
qualified service personnel. à d'autres risques. Toute
réparation doit être effectuée par
Compliance
un personnel qualifié.
This product conforms to the
following Council Directive: Conformité
Directive 89/336/EEC (EMC), Ce produit est conforme aux
92/31/EEC (EMC) Directives du Conseil suivantes:
73/23/EEC (LVD) directive 89/336/CEE (CEM),
92/31/CEE (CEM)
73/23/CEE (LVD)
Specifications
Creative Inspire 6.1 6600
Spécifications
7-Channel Amplifier
Creative Inspire 6.1 6600
Satellite speaker:
Amplificateur 7 canaux
8 watts RMS per channel
Haut-parleur satellite:
Center Satellite:
8 watts RMS par canal
20 watts RMS
Satellite central:
Subwoofer:
20 watts RMS
22 watts RMS
Caisson de basse:
These specifications apply to
22 watts RMS
Creative Inspire 6.1 6600
operating from the supplied Ces spécifications s'appliquent au
13.5V AC 5A power adapter.
modèle Creative Inspire 6.1 6600
fonctionnant avec la prise
d'alimentation 13.5 V c.a. 5A fournie.
Page 1
September
© 2002. Creative Technology Ltd. All rights reserved. The Creative logo, Sound Blaster
and the Sound Blaster logo, are registered trademarks and Inspire, Creative Inspire, the
EAX logo, Audigy, Sound Blaster Audigy and EAX ADVANCED HD are trademarks of
Creative Technology Ltd. in the United States and other countries. NOMAD is a
registered trademark of Aonix and is used by Creative Technology Ltd. and/or its
affiliates under license. All other logos, brand or product names are trademarks or
registered trademarks of their respective holders and are hereby recognized as such. All
specifications are subject to change without notice. Use of this product is subject to a
limited warranty. Actual contents may differ slightly from those pictured.
Safety and Regulatory Information
The following sections contain notices for various countries:
NOTICE FOR THE U.S.
FCC Part15: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However, this
notice is not guaranteed that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician.
CAUTION: To comply with the limits for the Class B digital
services, pursuant to Part 15 of the FCC Rules, this device
must be installed with computer equipment certified to
comply with the Class B limits.
Modifications
Any changes or modifications not expressly approved by the
grantee of this device could void the user's authority to
operate the device.
NOTICE FOR CANADA
This apparatus complies with the Class 'B' limits for radio
interference as specified in the Canadian Department of
Communications Radio Interference Regulations.
Important Notice
The serial number for your Creative Inspire 6.1 6600 is
located on the subwoofer. Please write this number down
and keep it in a secure place.
Español Português do Brasil
Instrucciones Instruções
importantes sobre importantes sobre
seguridad segurança
Lea y siga las instrucciones Leia e siga as instruções
Debe leer y seguir todas las Todas as instruções de
instrucciones sobre seguridad y segurança e de operação devem
funcionamiento. ser lidas e seguidas.
Limpieza Limpeza
Antes de efectuar la limpieza, Desconecte o adaptador de
desenchufe el adaptador de fonte de alimentação da tomada
alimentación de la toma o fuente elétrica ou fonte de energia
de alimentación. No utilice antes de limpar. Não use
limpiadores líquidos ni aerosoles. produtos de limpeza líquidos ou
Utilice un paño húmedo. em aerossol. Use uma flanela
umedecida para limpar.
Colocación de los altovoces
No sitúe el altavoz en un Posicionamento do sistema de
carrito, estantería, trípode, caixas
soporte o mesa inestable. Não coloque o sistema de
caixas de som em um carro,
El altavoz se podría caer y
estante, tripé, suporte ou mesa
provocar graves lesiones a las
instável.
personas y quedar seriamente
dañado. As caixas podem cair,
machucando pessoas e causando
Fuentes de alimentación
danos graves ao produto.
Este sistema de altavoces está
especialmente diseñado para Fontes de Alimentação
funcionar dentro de las amplitudes Este sistema de som foi
eléctricas especificadas en el desenvolvido especificamente
adaptador de alimentación. El para operação dentro da faixa
empleo de otras potencias que elétrica especificada no adaptador
estén fuera de las mencionadas de alimentação fornecido e a
amplitudes queda a la entera utilização fora dessa faixa ficará
responsabilidad del usuario. por sua conta e risco.
Si tiene dudas con respecto al Entre em contato com sua
voltaje que le corresponde utilizar companhia elétrica se tiver
en su lugar de residencia, consulte dúvidas com relação à voltagem
a la compañía eléctrica local. do local de utilização desejado.
Reparaciones Manutenção
No intente reparar ninguna Não tente você mesmo fazer
parte del altavoz por su cuenta. manutenção em qualquer parte
Si abre o retira las cubiertas, se das caixas de som; a abertura
puede ver expuesto a ou remoção das tampas pode
descargas eléctricas u otros expô-lo a voltagens perigosas e
riesgos. Deje las reparaciones outros riscos. Qualquer
en manos del personal de manutenção deve ser feita por
servicio cualificado. pessoal qualificado.
Compatibilidad Conformidade
Este producto cumple con la Este produto está em
siguiente directiva: conformidade com a seguinte
Directiva 89/336/EEC (EMC), diretiva de conselho:
92/31/EEC (EMC) Diretiva 89/336/EEC (EMC),
73/23/EEC (LVD) 92/31/EEC (EMC)
73/23/EEC (LVD)
Especificaciones
Especificações
Creative Inspire 6.1 6600
Amplificador de 7 canales Creative Inspire 6.1 6600
Amplificador de sete canais
Altavoz auxiliar:
8 vatios de carga eficaz Alto-falante:
por canal RMS de 8 watts por canal
Auxiliar central: Alto-falante Central:
20 vatios de carga eficaz RMS de 20 watts
Altavoz de graves: Subwoofer:
22 vatios de carga eficaz RMS de 22 watts
Estas especificaciones se Estas especificações aplicam-se
aplican para el uso del Creative a Creative Inspire 6.1 6600
Inspire 6.1 6600 con el operando a partir do adaptador
adaptador de alimentación de de alimentação de 13.5V AC 5A
13.5V CA 5A suministrado. fornecido.
P/N 0300000000206 Rev. C
WARNING: To prevent fire
or shock hazard, do not
expose this appliance to
rain or moisture.
Türkçe
Creative Inspire™6.1
6 6 0 0
Multimedia Speaker System
Quick Start Guide
Démarrage rapide
Instalación rápida
Introdução Rápida
EAX ® technology delivers advanced audio functionality and
performance, adding sophisticated audio processing capabilities,
interactive and high-definition sound to digital entertainment.
EAX technologies are implemented across a range of audio
hardware solutions, system software, application software, and
application programming interfaces (APIs) from Creative. With
EAX technology-enabled products, you can shape and customize
your audio experience. Certain EAX features provide advanced
audio capabilities for music composition and sound design. EAX
technology is redefining the audio experience.
The Creative Inspire 6.1 6600 speaker system is equipped with
Creative Multi-Speaker System (CMSS) technology, an innovative
EAX multi-channel up-mixing functionality for an enveloping
surround environment. CMSS dramatically enhances the playback
of 5.1 audio soundtracks and music files across the full 6.1
speaker configuration. Simply enable the CMSS feature and you
will get full, immersive 6.1 surround when combined with a Sound
Blaster Audigy or Sound Blaster Live! 5.1 sound card. In addition,
when used with a Sound Blaster Audigy 2 sound card, you can
enjoy realistic playback of your Dolby Digital Surround EX titles
with your PC.
For more information on EAX, be sure to visit EAX.creative.com.
