Unpacking:
DJ
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fixture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without first contact-
ing customer support.
Introduction:
pursuit for creating high quality affordable intelligent fixtures. The P64
LED WH is a DMX intelligent LED Par Can. This Par Can is light weight
and compact which makes it a great piece for mobile DJ's and clubs.
This unit can be used as a stand alone, or a sound-active mode. The
unit can also be controlled via DMX controller.
Customer Support:
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacific Standard Time.
To purchase parts online visit http://parts.americandj.com
Warning!
not expose this unit to rain or moisture.
Caution!
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ
PLEASE recycle the shipping carton when ever possible.
American DJ
®
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
P64 LED WH
Thank you for purchasing the P64 LED WH by American
. Every P64 LED WH has been thoroughly tested and has been
®
The P64 LED WH is part of American DJ's continuing
American DJ
Voice:
(800) 322-6337
Fax:
(323) 582-2610
E-mail:
support@americandj.com
To prevent or reduce the risk of electrical shock or fire, do
There are no user serviceable parts inside this unit. Do not
.
®
American DJ Supply
- www.americandj.com - P64 LED WH Instruction Manual Page 2
©
®
Introduction
provides a toll free customer sup-
®
