Back to Basics AUTOSERVE SMOOTHIE MAKER Instruction Manual page 7

1. Remove the valve from the blending jar by unscrewing the entire valve counter-
clockwise.
2. Remove the cap from the valve body by lifting the lever upwards from the back
of the valve body to a position above the cap. Then unscrew the cap by rotating
it counter-clockwise.
3. Squeeze the cap and stopper together and slide the lever off the stopper pin.
4. Remove the spring.
5. Remove the stopper and stopper pin by pulling the rubber rim off the stopper.
The stopper and pin are tightly fit and need not be separated.
6. Clean all parts in warm, soapy water, allow to dry thoroughly and reassemble in
the order shown.
Cap
Lever
CLEANING THE DISPENSING VALVE
7
Spring
Stopper Pin
Stopper
Valve Body
