Audioplex LUMA-VR-1 Installation Manual

Power:
Connectors:
Dimensions:
The Luma Series of remote controlled video switchers are designed to offer convenient A/B video switching.
Multiple switchers can be used, allowing for up to six monitor locations controlled by a ProScan/RCA remote.
With power off, make connections to your Luma Series switcher following the wiring diagram on the back of this
sheet. Once all the connections have been made, plug in the power supply to start up the unit.
The rotary switch in the front of the switcher sets the ID number for the particular Luma Video Switcher. The
front rocker switch changes between Toggle and Discreet IR codes.
TOGGLE MODE: In Toggle mode, 6 individual Luma's may be controlled via the 6 source selector button
functions on ProScan/RCA remotes. The source buttons are: Video 1, Video 2, CD, Tape, TV, Tuner. If there is a
conflict with any other RCA equipment in the system, then the rotary switch can be moved to relieve the conflict.
In the Toggle mode, each press of a button will cause the Luma to change from "A" to "B" in a circular fashion.
Available rotary switch positions are: 1, 2, 3, 4, 5, and 6.
DISCRETE MODE: In Discrete Mode, only 3 individual Luma's may be controlled as the "A" and "B" input
sources are selected via an individual remote control code. Available rotary switch positions are: 1, 2, and 3.
Toggle Mode
Rotary Switch Position
Remote Button
Discrete Mode
Rotary Switch Position
Remote Button
Remote Button
INSTALLATION MANUAL
TECHNOLOGY
LUMA-VRS-1
Remote Controlled Component Video Switcher

SPECIFICATIONS:

12 vdc 500ma power supply included
RCA audio and video / RS-232 computer interface
1/8" mono jack for infrared emitter
1/8" stereo jack for optional "A" and "B" indicator
9.5"W x 2.5"H x 4.875"D

INSTALLATION

ProScan remote control codes
1
Vid 1
1
Vid 1
Vid 2

OPERATION

2 3
Vid 2 CD
2 3
CD TV
Tape Tuner
4 5
Tape TV
Video Input
A
B
6
Tuner
2004 - 12/27/04
