Audioplex SR-12 Installation Manual

Frequency Response:
Power Handling:
Size:
Mounting:
Your Slim Line switcher is designed to work as a multi location speaker switcher or as a
multi amplifier source selector. When used as a source selector it is advisable to use the version
with the lock out switch option. This will prevent two amplifiers from being connected together
at once. If used as a speaker selector keep in mind this unit does not offer impedance
protection. You are highly advised to use our Optimatch(tm) volume controls or another means
of impedance matching such as Match-It's(tm). This switcher can be rack mounted or free
standing allowing for flexible set up.
Wiring should be completed by following the wiring diagram on the back of this sheet.
Wires should all be stripped about 1/4", and tightly twisted to eliminate any chance of short
circuits caused by stray wires. Snug but do not overtighten the screw terminal. Also make sure
that the correct wire is in the proper terminals (note that the INPUT connector block is green
and the OUTPUT connector blocks are black).
If this unit is used in a free standing mode then consideration should be given to the
weight of the wires attached to the unit. Supporting the wires will prevent the Slim Line
switcher from falling backwards. The switcher can also be stacked under another heavier unit
for support. This should be done with care.
INSTALLATION MANUAL
TECHNOLOGY
SR SLIM LINE SERIES
Versatile switching units.

SPECIFICATIONS

20 Hz-20KHz +/- 0db
300 Watts RMS
17"W x 5.5"D x 1.5"H
Free standing or rack mountable (optional)

INSTALLATION

1999 - 4/29/99
