N-Tron ESERV-11T User Manual

Ethernet to serial servers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ESERV-11T and ESERV-12T
Ethernet to Serial Servers
User Manual

Advertisement

Table of Contents
loading

Related Manuals for N-Tron ESERV-11T

Summary of Contents for N-Tron ESERV-11T

  • Page 1 ESERV-11T and ESERV-12T Ethernet to Serial Servers User Manual...

  • Page 2: Table Of Contents

    About ESERV-1xT Serial Servers ..........................1 ESERV-1xT Serial Server Model Numbering......................1 ESERV-1xT Serial Server Features ........................... 2 N-TRON Ethernet Serial Server Configuration Software ..................2 ESERV-1XT SERIAL SERVER HARDWARE ..................3 Package Checklist ..............................3 ESERV-1xT Serial Server Enclosures and Mounting ....................3 LED Indicators(ESERV-1xT) .............................
  • Page 3 Table of Contents ESERV-1xT Serial Server Operational Connections..................13 Using ESERV-1xT Serial Servers in Direct IP Mode ..................... 13 Using ESERV-1xT Serial Servers in Virtual COM Port Mode ................14 Using ESERV-1xT Serial Servers in Paired Mode ....................15 Initiating a Hardware Reset on the Serial Server ....................16 Reloading Factory Defaults ..........................
  • Page 4 Controls, Indicators and Connector Specifications .................... 34 Serial Interface Specifications ..........................35 Fiber Interface Specifications ..........................36 Network Specifications ............................37 APPENDIX C: DIMENSIONAL DIAGRAMS ................39 APPENDIX D: CONNECTOR PINOUTS..................41 ESERV-11T Serial Port Pinouts ..........................41 ESERV-1xT (Rev. 1210)
  • Page 5 Table of Contents ESERV-12T Serial Port Pinouts ..........................43 Standard Ethernet Cable RJ-45 Pin-out ........................ 44 N-TRON LIMITED WARRANTY ......................49 ESERV-1xT (Rev. 1210)

  • Page 6: Introduction

    Introduction ESERV-1xT Serial Servers INTRODUCTION Thank you for purchasing an N-TRON product! This product has been manufactured to the highest standards of quality and performance to ensure your complete satisfaction. Figure 1. An ESERV-12T Serial Server ABOUT ESERV-1XT SERIAL SERVERS ESERV-1xT Serial Servers connect serial devices (RS-232, RS-422 or RS-485) to Ethernet networks, allowing the serial device to become a node on the network.

  • Page 7: Eserv-1Xt Serial Server Features

    Configuration of Ethernet and serial port settings using N-TRON Serial Server Configuration Software. N-TRON ETHERNET SERIAL SERVER CONFIG URATION SOFTWARE N-TRON Ethernet Serial Server configuration software enables you to find connected serial servers, configure them, upgrade serial server firmware, and save/load configuration files. It features a graphical user interface (GUI) that is convenient and easy to use.

  • Page 8: Eserv-1Xt Serial Server Hardware

    Hardware ESERV-1xT Serial Servers ESERV-1XT SERIAL SERVER HARDWARE ESERV-1xT Serial Servers are enclosed in DIN rail mountable enclosures and feature LED indicators, power, Ethernet and serial connectors and a recessed Mode switch. PACKAGE CHECKLIST ESERV-1xT Serial Servers are shipped with the following items included: ESERV-1xT Serial Server Module Quick Start Guide CD with User Manual, Quick Start Guide and firmware...

  • Page 9: Link Led

    SERIAL PORT LEDS ESERV-11T serial servers feature one serial port. ESER-12T serial servers feature two serial ports. Each serial port has an associated LED. Serial Port LEDs blink (green) when data is being transmitted or received on the serial port.

  • Page 10: Ethernet Connector

    PORT CONNECTORS ESERV-1xT Serial Servers use three serial port connector configurations, depending on the model: ESERV-11T serial servers feature one serial port and use a DB-9M connector for RS-232 and a five-position removable terminal block for RS-422 and RS-485 connections.

  • Page 11: Power Connector

    Hardware ESERV-1xT Serial Servers Figure 6. DB-9 Female Serial Port Connector with Pinout Figure 7. Five-Position Pluggable Terminal Blocks Note: Refer to Appendix D for connection pin-outs. POWER CONNECTOR The power connector is a 5.08 mm 2-position pluggable terminal block. Figure 8.

  • Page 12: Mounting Hardware

    Hardware ESERV-1xT Serial Servers MOUNTING HARDWARE ESERV-1xT Serial Server modules can be DIN rail mounted. The DIN mounting clip and spring is included on each module. Figure 9. DIN Clip on a Serial Server Model ESERV-1xT (Rev. 1210)

  • Page 13: Serial Server Setup And Connections

    Setup and Connections ESERV-1xT Serial Servers SERIAL SERVER SETUP AND CONNECTIONS This section describes how to setup and connect ESERV-1xT Serial Servers. Note: In this section devices to be connected to the serial server’s serial connection are simply referred to as the “serial device”. CONNECTING THE POWER SUPPLY Connect a DC power supply to the power terminals on the top of the serial server.

  • Page 14: Connecting The Eserv-11T

    If you select RS-232 mode when you configure the serial server, you must connect the serial device to the serial server via a serial cable. The ESERV-11T is a DTE. If the serial device is a DTE, use a null modem (cross-over) cable.

  • Page 15: Connecting The Eserv-12T

    Setup and Connections ESERV-1xT Serial Servers CONNECTING THE ESERV-12T The ESERV-12T has two serial connections that support RS-232, RS-422 and RS-485 (2- and 4-wire). The unit has two connectors, both of which are 5-position terminal blocks. Make the appropriate connections to the terminal blocks to match the serial connection mode you select when configuring the serial server.
  • Page 16 Setup and Connections ESERV-1xT Serial Servers CONFIGURING WITH N-TRON'S ETHERNET SERIAL SERVER MANAGER ESERV-1xT Serial Servers can be configured over the network using N-TRON's Ethernet Serial Server Manager software running on a PC. To open the software: 1. From the Desktop, click StartProgramsN-TRON Ethernet Serial Server Manager...

  • Page 17: Configuring The Eserv-1Xt Serial Server Via The Serial Port (Console Mode)

    4. The serial server is in Console Mode when: a. On the ESERV-11T: Port 1 LED is On and the Ready LED is Off. b. On ESERV-12T models: Port 1 LED is On and the Port 2 LED is Off.

  • Page 18: Eserv-1Xt Serial Server Operational Connections

    Setup and Connections ESERV-1xT Serial Servers To configure the serial server, open the Ethernet Serial Server Manager software and set up the serial server's parameters as required. Note: For more information on configuration options refer to Section 4: Description of Serial Server Properties.

  • Page 19: Using Eserv-1Xt Serial Servers In Virtual Com Port Mode

    Setup and Connections ESERV-1xT Serial Servers 2. Configure the serial server with the appropriate network settings (using the Ethernet Serial Server Manager or the web interface). Direct IP/UDP 3. Configure your software application with the appropriate IP address and port number to communicate with the serial device(s).

  • Page 20: Using Eserv-1Xt Serial Servers In Paired Mode

    Setup and Connections ESERV-1xT Serial Servers calls are able to interface to virtual COM ports. When a program on the PC opens the new COM port, it communic ates directly with the remote serial device connected to the serial server. To set up a Virtual COM Port Mode connection: 1.

  • Page 21: Initiating A Hardware Reset On The Serial Server

    1. The Ready LED blinks three times per second while the button is being pressed. 2. The serial server is in Reset Mode when: On the ESERV-11T: Port 1 LED is On and the Ready LED is Off. ESERV-1xT (Rev. 1210)

  • Page 22: Reloading Factory Defaults

    1. The Ready LED blinks three times per second while the button is being pressed. 2. The serial server is in Factory Default Mode when: On the ESERV-11T: Port 1 LED and the Ready LED are both On. On the ESERV-12T: Port 1 LED and the Port 2 LED are both On.

  • Page 23: Description Of Serial Server Properties

    Server Properties ESERV-1xT Serial Servers DESCRIPTION OF SERIAL SERVER PROPERTIES The following serial server properties are ordered alphabetically to assist you in finding the information you need. BAUD RATE Baud Rate is the communication speed of the link between the serial server and the device attached to its serial port. Both these devices must be configured to operate at the same baud rate.

  • Page 24: Delimiter 1, Delimiter 2 And Delimiter Removal

    Server Properties ESERV-1xT Serial Servers DELIMITER 1, DELIMIT ER 2 AND DELIMITER REMOVAL Delimiters and Delimiter Removal enable you to control how characters received on a serial port are sent across the network. Delimiters are ASCII characters specified by the user when configuring the serial server. The serial server takes action when it recognizes the specified character(s) on its serial port.

  • Page 25: Dhcp

    Server Properties ESERV-1xT Serial Servers DHCP DHCP (Dynamic Host Configuration Protocol) is a protocol used on special servers that supply IP addresses to network nodes on request. When DHCP is enabled on the serial server, on power up it sends a DHCP request to the DHCP server, which assigns a dynamic IP address, subnet mask, and default gateway to the serial server.

  • Page 26: Ip Address

    Server Properties ESERV-1xT Serial Servers receive characters. Smaller values may increase the number of network packets, but decrease the amount of time to receive characters. The range is 1 through 65535. IP ADDRESS Software or hardware attempting to access the serial server via the network must know the IP Address of the server. In DHCP mode (factory default), the serial server requests and receives a dynamic IP address from a DHCP server when it first connects to the network.
  • Page 27 Server Properties ESERV-1xT Serial Servers Open Hyper Terminal or similar serial emulation software and connect to the COM port used in the step above. Ensure the port is configured to 115,200 baud, 8 data bits, and 1 stop bit. Enter Console Mode. Press and hold the serial server’s RESET SWITCH for 2 to 10 seconds.

  • Page 28: Link Status

    Server Properties ESERV-1xT Serial Servers LINK STATUS Link Status of the currently selected serial server is shown on the Login page of the Ethernet Serial Server Manager. Link status indicates the type of Ethernet connection between the computer and serial server. It will either display 10BaseT or 100BaseTX in full duplex or half duplex.

  • Page 29: Serial Interface Modes

    It must not consist of all numeric values. SERVER SERIAL PORT NUMBER The Server Serial Port Number of the currently selected port is shown in this field. ESERV-11T serial servers feature one serial port. ESERV-12T serial servers feature two serial ports. Serial Watchdog Serial Watchdog controls the duration of serial inactivity when the serial port is determined idle and causes all connections for that serial port to be forced closed.

  • Page 30: Tcp (Transmission Control Protocol)

    Server Properties ESERV-1xT Serial Servers For a Class D network (IP addresses 224.0.0.0 through 239.255.255.255) and Class E Networks (IP addresses 240.0.0.0 through 255.255.255.255) the subnet mask is ignored. ESERV-1xTserial servers come from the factory with a default subnet mask value of: 255.255.255.0 TCP (TRANSMISSION CONTROL PROTOCOL) TCP (Transmission Control Protocol) provides reliable connection-oriented network communication with error checking.

  • Page 31: Upgrading The Serial Server Firmware

    Firmware Upgrades ESERV-1xT Serial Servers UPGRADING THE SERIAL SERVER FIRMWARE Occasionally, updated firmware may become available for your serial server. The firmware can be upgraded using the Ethernet Serial Server Manager software. The following procedure describes the firmware updating process: 1.

  • Page 32: Diagnostics

    Diagnostics ESERV-1xT Serial Servers DIAGNOSTICS Clicking the Diagnostics icon opens the Diagnostics dialog box and enables you to check the operation of connected serial servers and VCOM ports on the local computer. The Computer Information box displays information about the type of network connections, the IP addresses, Subnet Masks and Default Gateways in use.

  • Page 33: Testing A Virtual Com Port

    Diagnostics ESERV-1xT Serial Servers Information about the progress of the pinging process is displayed in the Test Progress box. Figure 17. Testing a Serial Server Connection REPLACE IMAGE TESTING A VIRTUAL COM PORT To run diagnostics on a virtual COM port: 1.
  • Page 34 Diagnostics ESERV-1xT Serial Servers 4. Click the Start button. Information about the progress of the pinging process is displayed in the Test Progress box. Figure 18. Testing a VCOM Port ESERV-1xT (Rev. 1210)

  • Page 35: Appendix A: Default Server Settings

    Default Server Settings Appendix A APPENDIX A: DEFAULT SERVER SETTINGS Setting Default Value Server Name MODEL NUMBER printed on side of unit Serial Number Password password field is blank from factory Enable DHCP IP Address BASED ON DHCP SERVER If a DHCP assignment is not available, the device will default to 169.254.102.39 255.255.255.0...
  • Page 36 Default Server Settings Appendix A Stop bits Flow Control None Protocol Serial timeout 0 seconds 0 minutes TCP alive timeout Connection Mode Server Delimiter HEX 1 Delimiter HEX 2 Remove delimiters Disable 0 ms Force transmit Inter-character timer 0 ms Character count Port 1 = 4000, Port 2 = 4001 TCP/UDP port...

  • Page 37: Appendix B: Product Specifications

    Product Specifications Appendix B APPENDIX B: PRODUCT SPECIFICATIONS General Specifications Device Serial Server Hardware and included accessories CD with the Ethernet Serial Server Manager software for Windows 2000, 2003 Server/XP/Vista Cable 232NM9 Null Modem Crossover Cable for Optional Accessories DTE to DTE connection Rail ERS35 one-meter length of steel 35mm DIN Rail...
  • Page 38 Product Specifications Appendix B EN61000-6-1 Generic Standards for Residential, Commercial & Light Industrial EN61000-4-2 to 11 ESD, RFI, EFT, Surge, and Enclosure Rating IP30 Mounting DIN rail mount (35 mm) Dimensions (ESERV-1xT) 1.2 x 3.3 x 4.7 in (3.1 x 8.4 x 11.9 cm) Power Supply Voltage Requirements 10 to 58 VDC...

  • Page 39: Controls, Indicators And Connector Specifications

    Off = System NOT OK 10BaseT /100BaseTX Single RJ-45F (8 pin) Connectors Ethernet ST Fiber ST Connector Serial ESERV-11T: one DB-9M connector ESERV-12T-x: Two pluggable lockable 5.08 mm terminal blocks DC Power 5.08mm 2-position pluggable, lockable terminal block ESERV-1xT (Rev. 1210)

  • Page 40: Serial Interface Specifications

    Product Specifications Appendix B Serial Interface Specifications Serial Mode Selection RS-232/422/485 software selectable Interfaces RS-232 lines TXD, RXD, RTS, CTS, DTR, DSR, DCD, GND RS-422 lines TXDA(-), TXDB(+), RXDA(-), RXDB(+), GND RS-485 lines (2 Data A(-), Data B(+), GND wire) RS-485 lines (4 TXDA(-), TXDB(+), RXDA(-), RXDB(+), GND wire)

  • Page 41: Fiber Interface Specifications

    Product Specifications Appendix B Fiber Interface Specifications Fiber Fiber Mode Multimode Interface Range Cable 62.5/125μm Connector TX Power Min -19 dBm RX Sensitivity -32 dBm Wavelength 1310 nm ESERV-1xT (Rev. 1210)

  • Page 42: Network Specifications

    Product Specifications Appendix B Network Specifications Memory Serial 8 KB per port Memory Network 4 KB Memory I/P Port Addresses 5300 Heartbeat & Configuration setting in TCP Mode (i.e. Pair Mode) 8888 ESERV-1xT update Network 10/100 Mbps Auto-detecting 10BaseT Communications or 100BaseTX Network Physical Layer Ethernet...
  • Page 43 Product Specifications Appendix B Via serial, Ethernet or auto web search Firmware Upgrade Character count 0 to 65535 Hex 1 00 to FF (send serial data if delimiter Delimiters hex 1 only is set and received) Hex 2 00 to FF (send serial data if delimiter hex 1 and 2 are set and received) Inter- 0 to 65535 ms...

  • Page 44: Appendix C: Dimensional Diagrams

    Dimensional Diagrams Appendix C APPENDIX C: DIMENSIONAL DIAGRAMS Figure 19. Dimensional Diagram of a ESERV-11T Serial Server ESERV-1xT (Rev. 1210)
  • Page 45 Dimensional Diagrams Appendix C Figure 20. Dimensional Diagram of a ESERV-12T Serial Server ESERV-1xT (Rev. 1210)

  • Page 46: Appendix D: Connector Pinouts

    Connector Pinouts Appendix D APPENDIX D: CONNECTOR PINOUTS ESERV-11T Serial Port Pinouts DB-9M Pin RS-232 ESERV-1xT (Rev. 1210)
  • Page 47 Connector Pinouts Appendix D RS-422/485 4- RS-485 2- Terminal Wire Wire TXA(-) DATA A(-) TXB(+) DATA B(+) RXA(-) RXB(+) ESERV-1xT (Rev. 1210)

  • Page 48: Eserv-12T Serial Port Pinouts

    Connector Pinouts Appendix D ESERV-12T Serial Port Pinouts RS-422/RS-485 Terminal RS-232 RS-485 2-Wire 4-Wire RTS (Output) TXA(-) DATA A(-) TD (Output) TXB(+) DATA B(+) CTS (Input) RXA(-) RD (Input) RXB(+) In the RS-422 mode, TX lines are outputs and RX lines are inputs. Connect the serial server TXB(+) line to the RXB(+) line of the serial device, and the serial server TXA(-) to the RXA(-) of the serial device.

  • Page 49: Standard Ethernet Cable Rj-45 Pin-Out

    Connector Pinouts Appendix D Standard Ethernet Cable RJ-45 Pin-out RJ-45 Pin Signal Wire Color RJ-45 Pin White-Green Green White-Orange Not used Blue Not used White-Blue Orange Not used White-Brown Not used Brown ESERV-1xT (Rev. 1210)
