Battery
Operated
The ionization type alarms are generally more effective at detecting fast,
flaming fires which consume combustible materials rapidly and spread
quickly. Sources of these fires may include paper burning in a waste
container or a grease fire in the kitchen. The photoelectric type alarms are
generally more effective at detecting slow, smoldering fires which smolder
for hours before bursting into flame. Sources of these fires may include
cigarettes burning in couches or bedding.
!WARNING: D
O NOT USE THIS SMOKE ALARM WITH ANY EXTERNAL BUG SCREENS OR
SMOKE ALARM GUARDS
SMOKE ALARM RESPONSE TIME
IMPORTANT INFORMATION ABOUT
YOUR SMOKE ALARM
• Before installing your smoke alarm, you must read this entire
Owner's Manual.
• Install a smoke alarm in each room and area of your home. See
• Smoke alarms cannot give you an early warning of fire or smoke
unless you install, use and maintain them by following these
instructions.
• You must hear the alarm's warning sound and quickly respond to it to
reduce the risk of damage, injury or death that may result from a fire.
• Your smoke alarm is packaged with an inactive battery which will be
activated during the installation process.
• The smoke alarm must be tested upon installation and every week
after that.
• A smoke alarm that beeps about once per minute has a battery
which is weak, and the entire unit must be discarded according to
procedure. This unit contains a sealed lithium battery which cannot
be replaced by the end user. See HOW TO REMOVE AND DISCARD
YOUR SMOKE ALARM.
• A smoke alarm should never be used, in any case, for more than 10
years.
WHAT SMOKE ALARMS CAN DO
Smoke alarms can only HELP protect your home and family against loss
from a fire. The best protection is obtained by installing smoke alarms in
each room, and each other area of the home, making sure the people in
the home will be able to hear and respond to the alarm sound.
Your smoke alarm meets or exceeds the requirements for audibility, or
loudness, set by Underwriters' Laboratories, Inc.
!WARNING: S
MOKE ALARMS MAY GIVE YOU A WARNING OF FIRE AND SMOKE
,
IF YOU INSTALL
USE AND MAINTAIN THEM IN ACCORDANCE WITH THESE INSTRUCTIONS
WHAT SMOKE ALARMS WILL NOT DO
A SMOKE ALARM WILL NOT WORK WITHOUT POWER. Your smoke alarm
needs a good battery that is installed correctly to work. A smoke alarm will
not work if its battery is missing, dead or put in wrong.
A SMOKE ALARM WILL NOT SENSE A FIRE WHEN THE SMOKE CANNOT
REACH THE ALARM. If a fire starts in a chimney, wall, roof, the other side
of a closed door, or any other isolated area, the smoke alarm may not
sense the smoke and will not give a warning. If you do not have an alarm in
the bedroom, and sleep with the door closed, a fire inside the bedroom
may not sound the alarm located in another room. Therefore, a smoke
alarm must be placed both inside and outside all bedrooms. A SMOKE
ALARM WILL NOT PROMPTLY SENSE A FIRE EXCEPT IN THE AREA OR
ROOM IN WHICH THE SMOKE ALARM IS LOCATED.
Smoke Alarm
. U
SE OF THESE TYPES OF DEVICES MAY REDUCE
.
1
MODEL TPCI
TAMPER PROOF
IONIZATION TYPE
PLEASE READ AND SAVE THIS MANUAL
Installer: Please leave this manual with
the product.
©2002 Maple Chase Company
110-1009D
,
BUT ONLY
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Firex TPCI
Summary of Contents for Firex TPCI
- Page 1 ©2002 Maple Chase Company Battery Operated Smoke Alarm 110-1009D MODEL TPCI TAMPER PROOF IONIZATION TYPE PLEASE READ AND SAVE THIS MANUAL Installer: Please leave this manual with the product. The ionization type alarms are generally more effective at detecting fast, flaming fires which consume combustible materials rapidly and spread quickly.
- Page 2 FOR EXAMPLE: A. A SMOKE ALARM MAY NOT SENSE A FIRE ON ANOTHER LEVEL OF A RESIDENCE OR BUILDING. A second-floor smoke alarm may not detect a fire on the first floor or in the basement of a building. Therefore, smoke alarms must be installed on every floor or level of your home or building.
- Page 3 IF YOUR HOUSEHOLD OR RESIDENCE HAS SEVERAL FLOORS, THERE MUST BE AN ALARM ON EVERY FLOOR, INCLUDING IN THE BASEMENT. See Figure 3. • Do install a smoke alarm in every bedroom where a smoker sleeps. • Do install a smoke alarm in every room and bedroom where electrical appliances (such as portable heaters, humidifiers or electric blankets) may be...
-
Page 4: How To Install Your Smoke Alarm
1,500 feet for #18 AWG or 4,000 feet for #14 AWG (20 OHMS loop resistance). To provide greater protection the model TPCI smoke alarms can be interconnected so that multiple units will alert you to a dangerous situation. - Page 5 BATTERY ACTIVATION Push Down Switch to Activate 4. Activate battery before mounting. Turn the unit over and push in the battery activation switch until it is flush with the base. See Figure 6B. UNIT MAY CHIRP OR ALARM TEMPORARILY WHEN ACTIVATED. FIGURE 6B 5.
-
Page 6: Important Information
WHERE TO SEND YOUR SMOKE ALARM FOR SERVICE. 4. Firex smoke alarms sold with long-life lithium batteries require replacement approximately every ten (10) years. Replace units approximately every ten (10) years or when the low battery signal sounds. - Page 7 OTHER THINGS YOU CAN DO TO MAKE YOUR FAMILY AND HOME SAFER FROM FIRES Installing, testing and taking care of smoke alarms is just one step in helping to protect your family and home from fires. You must also reduce the chance that fire will start in your home and increase your chances of escaping if one does start.
-
Page 8: Warranty Information
WARRANTY INFORMATION 10-YEAR LIMITED SMOKE ALARM WARRANTY Maple Chase Company warrants to the original consumer purchaser each new smoke alarm to be free from defects in material and workmanship under normal use and service for a period of ten (10) years from the date of purchase.
