dbx iEQ 31 Specifications

iEQ 31
Dual 31-Band Digital Graphic Equalizer/Limiter with TYPE V™ NR and AFS™
TM
With an EQ heritage that has produced countless industry-standard patents and
dates back more than 30 years, the dbx iEQ-31 easily lives up to the dbx
cy of uncompromised sonic integrity. In addition to unsurpassed equalization
specs, the iEQ-31 also offers the built-in necessities which include AFS™ feed-
back Suppression, Type V™ noise reduction and PeakStopPlus
Besides including two 31-band channels of 1/3-octave equalization, the iEQ-31
also offers +12 dB input gain range; switchable +6 or +15 dB boost/cut range,
40mm faders, XLR, 1/4'' and Euroblock inputs and outputs, nonconductive
nylon sliders; and an intuitive user interface with comprehensive output and
gain reduction metering. As always, the inevitable result of our meticulous
attention to detail and top-quality componentry is exceptional sound, perfor-
mance, and reliability.
The iEQ series represents a major step forward in the performance of graphic
equalizers. The iEQ series is now able to offer state-of-the-art digital EQ per-
formance and specs with an analog look and feel. From its amazing 10Hz to
22kHz frequency response, to its 113dB dynamic range and Advanced Feedback
Suppression (AFS™), dbx proprietary Type V™ noise reduction and
PeakStopPlus
down-to-earth price point. Sure to find a home in the studio, on tour and with
installed sound venues, the iEQ-31 is destined to take its rightful place in the
lineage of great dbx
nal processing. With such pristine design and quality, the iEQ-31 offers the max-
imum sonic flexibility in a straight forward interface and rock-solid construction.
For more information please visit us at: www.dbxpro.com.
• Advanced Feedback
Suppression (AFS™)
• Type V™ Noise Reduction
• PeakStopPlus
• 1/3-octave Constant Q
frequency bands
• Switchable boost/cut ranges
of ±6 or ±15 dB
• 18 dB per octave 40Hz low-
cut filter
• ±12 dB input gain range
• XLR, TRS and Euroblock
limiting, the iEQ-31 offers out of this world specifications with a
®
® signal processors that are the professional's choice in sig-
® Limiting
Inputs and Outputs
• Internal Toroidal
Transformer
• Dynamic range of greater
than 113dB
• User Power Up Features
• Relay Bypass for Power
Failure System Protection
A Harman International Company
®
lega-
®
limiting.
®
8760 S. Sandy Pkwy.
Sandy, Utah 84070
Phone (801) 568-7660
Fax (801) 568-7662
Int'l Fax (801) 568-7583
customer@dbxpro.com
http://www.dbxpro.com
18-0295 -A 3/03
