AUDIOACCESS
PX-612
MULTI-ROOM AMPLIFIER
PRELIMINARY SERVICE MANUAL
Harman Consumer Group
250 Crossways Park Dr.
Woodbury, New York 11797

Advertisement

loading
Need help?

Need help?

Do you have a question about the PX-612 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Audioaccess PX-612

  • Page 1 AUDIOACCESS PX-612 MULTI-ROOM AMPLIFIER PRELIMINARY SERVICE MANUAL Harman Consumer Group 250 Crossways Park Dr. Woodbury, New York 11797...
  • Page 7 Procedure: Connect AC Line to PX-612, and then turn on with the power switch on rear panel. Observe LED on the front panel. It should initially be Red, then change to Amber. Watch for about 1 minute to ensure it does not turn Green.
  • Page 13: Parts Cross-Reference

    LED, YEL 022-2079-0 MOV, 130V, 6500A, 1500pf 070-0520-0 POT, 500 OHM TRIM AA132-003-0 760-4600-003 PX-612 FRONT PANEL AA206-0005-C PX-612 INPUT BOARD (COMPLETE ASSY) AA145-0003-D PX-612 POWER BOARD (BLANK) AA145-0003-D PX-612 POWER BOARD (COMPLETE ASSY) AA132-001-0 760-4600-008 PX-612 TOP COVER 014-0066-0...
  • Page 14 014-1065-0 633-7912-002 PX-612 REGULATOR, LM7912, -12V, 1A 081-0009-0 RELAY, JW2EN, DC12V 050-1302-0 RES, CARBON FILM, 1.3K OHM, 1/8W, 5% 050-1001-0 RES, CARBON FILM, 100 OHM, 1/8W, 5% 050-1004-0 654-0040-100 RES, CARBON FILM, 100K OHM, 1/8W, 5% 050-1203-0 RES, CARBON FILM, 12K OHM, 1/8W, 5%...
  • Page 15 PX612 PARTS LIST AASWH/3 3M SPEAKER WIRE HARNESS 700-1000-256 48" SPEAKER WIRE HARNESS AA145-004-D POWER BOARD COMPLETE ASSEMBLY 800-3160-000-00 600/612/603 BOX 805-3000-007 600/612/603 FOAM SET B Stock Replacement Amp/ with trade 350206 5 AMP 250 VOLT SLO BLO FUSE...
