Garrett THD User Manual

Tactical hand-held metal detector
Hide thumbs Also See for THD:
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

See also: User Manual
U
U
SER
SER
M
M
ANUAL
ANUAL
THD
T
H
-H
ACTICAL
AND
ELD
M
D
ETAL
ETECTOR

Advertisement

Table of Contents
loading

Related Manuals for Garrett THD

Summary of Contents for Garrett THD

  • Page 1 ANUAL ANUAL ACTICAL ETAL ETECTOR...

  • Page 2: Safety Notice

    Safety precautions have been designed into Tactical Hand-Held Metal Detector. The Garrett the detector. Extensive research has found no THD is an active hand-held metal detector information that would indicate scanning has designed to detect metallic (ferrous, non-ferrous adverse effects on pregnancies or the operation...
  • Page 3 COMPONENTS Non-Skid Handle Grip Green Ready Light turns to Amber when Screw-On Battery Cover battery needs replacing Power Button (On/Off ) 3 1/2" Long, 360 º Plus Tip Detection Area LED Flashlight Button (Momentary Action) Red Light Alarm LED Flashlight Heavy-Duty Ballistic Weave Holster Velcro Strip (For Wall or Vehicle Mounting)

  • Page 4: Operating Instructions

    The LED flashlight turns off when steel metals will be detected. To scan feet and the flashlight button is released. ankles, "sweep" the Garrett THD perpendicularly and approximately one to two inches above the Vibrator—The quick acting, silent alert vibrator floor or ground.

  • Page 5: Specifications

    ACCESSORIES SPECIFICATIONS Model: #1165900 Rechargeable Battery Kit: Two (2) 7.2V Nickel Operating Frequency: 93kHz Metal Hydride (Ni-MH) batteries with double Dimensions: socket charger. Connects to conventional current. Length: 8 1/2" (21.6 cm) Width: 1 5/8" (3.8 cm) #1612000: 110V Weight: 6.4 oz. (199g) #1612100: 220V Battery: Standard 9V (included) Battery Life: Up to 70 hours of normal use...

  • Page 6: Service Information

    If a 9V battery is improperly installed, no circuitry damage will occur; however, the Garrett THD will not oper- ate. The battery cover will not close tightly if the battery is inserted improperly, therefore, never force the cover to close.
  • Page 7 360 º PLUS DETECTION FIELD 360 º Detection Area Tip Pinpointing...
  • Page 8 RECOMMENDED BODY SCANNING PROCEDURE Use all of these scanning techniques for each suspect. Note: Special attention should be given to the waist, underarm and ankle areas. Back Scanning Front Scanning Outline Scanning Foot Area Scanning...
  • Page 9 Garrett Metal Detectors Security Division 1881 W. State Street Garland, Texas 75042-6797 USA (800) 234-6151 (Inside USA) (972) 494-6151 (Outside USA) (972) 494-1881 (Fax) Email: security@garrett.com www.garrett.com ©2003 Garrett Electronics, Inc. 1531900 Rev: A...
