MAX-G85 MINI-Compact System MP3-CD/WMA-CD/CD-R/RW Playback user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register...
Safety Warnings This symbol indicates “dangerous voltage” inside CAUTION the product that presents a risk of electric shock RISK OF ELECTRIC SHOCK. DO NOT OPEN or personal injury. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER (or BACK). This symbol indicates important instructions NO USER SERVICEABLE PARTS INSIDE.
Thank you for buying this SAMSUNG mini-compact system. Please take time to read these instructions. Contents They will allow you to operate your system with ease and take full advantage of its features....................................2 AFETY ARNINGS NSTALLING OMPACT YSTEM Front Panel View ......................................
Front Panel View COMPACT DISC COMPARTMENT AUX IN 1 JACK MIC 1 JACK USB JACK MIC 2 JACK WINDOW DISPLAY HEADPHONE JACK Top Panel View 1. POWER BUTTON 2. OPEN/CLOSE BUTTON 3. FUNCTION BUTTON 4. SEARCH FUNCTION BUTTON(DOWN) 5. TUNING MODE OR STOP BUTTON 6.
Rear Panel View 5. Clamp-Wire Speaker Connector Terminals 2. Cooling Fan (Fasten the speaker wires.) AUX IN 2 FM Aerial Connector Terminal Remote Control 1. POWER/ECO 31. ECHO 2. TUNER 32. SLEEP 3. CD 33. USB 4. TIMER/CLOCK 34. AUX 5.
Where to Install Your Mini-Compact Inserting Remote Control Batteries System Insert or replace remote control batteries when you: To take full advantage of your new mini-compact system, follow Purchase the micro-compact system these installation instructions before connecting the unit. Find that the remote control is no longer operating correctly Install the system on a flat, stable surface.
Connecting Audio from External Connecting the FM Aerial Components AUX1 : Front Panel How to connect a COAXIAL TYPE aerial. Connect a 75Ω antenna to the FM antenna terminal. Plug the connector on the FM aerial supplied into the coaxial socket (75Ω) marked FM on the rear of the system.
DEMO/DIMMER function Setting the Clock All functions available on the system can be viewed on the Your system is equipped with a clock which allows you to turn your system on and off automatically. display and the display's brightness can be switched between "on"...
Selecting a Track To play the CD/MP3/WMA-CD You can select the track you wish to listen to when a disc is You can play 12 cm or 8 cm compact disc without an adapter. playing. You can play 12 cm or 8 cm compact discs without an adapter. To play the previous track This unit has been designed to playback the CDs: Audio CD, Press the...
What is WMA? Function to skip through 10 tracks at a time WMA means Windows Media Audio, the global standard for audio signal compression technology. Press the +10 button briefly while playing back a CD and MP3/WMA-CD . The track 10 tracks after the current one will then be played back.
Repeating One or All Tracks Programming the Order of CD Playback on the Compact Discs (This function is not available during playback of an MP3/WMA-CD.) You can repeat indefinitely: A specific track on a compact disc. You can decide: All tracks on the compact disc selected. The order of the track desired to listen The track not desired to listen You can program up to 24 tracks.
Checking or Changing Programmed CD Tracks You can check or change your selection of tracks at any time. Please be aware of the following before using USB. Some external USB storage device may not be compatible with this Press once if you have started listening to the selection. player.
To skip next 10 tracks To use high speed search Connect the external USB storage device to your player. Before you begin! Connect the external USB storage device to your player. Select USB function by using the USB button. Before you begin! Select USB function by using the USB button.
Searching for and Storing the Radio Stations You can store up to: 15 FM stations Switch the system on by pressing STANDBY/ON. Select the TUNER function by pressing TUNER. To search for a Press TUNING MODE button station... Preset Once or more times until PRESET is displayed.
Selecting a Stored Station Improving Radio Reception You can improve the quality of radio reception by: Rotating the FM aerial Testing the positions of the FM aerials before fixing them permanently You can listen to a stored radio station as follows: If reception from a specific FM radio station is poor, press MO/ST.
CD RIPPING Function You can rip a compact disc as a MP3 file on the USB This feature enables you to ripping with the start of the disc or track of your choice. Switch the system on by pressing STANDBY/ON. Connect the USB.
Timer Function The timer enables you to switch the system on or off at specific times. Example: You wish to wake up to music every morning. If you no longer want the system to be switched on or off automatically, you must cancel the timer. Before setting the timer, check that the current time is correct.
Mute Function Treble Level Function Treble Control function stresses high tones providing thudding soundeffects. You can turn the sound off temporarily on your system. Example: You wish to answer a telephone call. PressTREB/BASS button until TREB 00 is displayed. Press button to select from TREB -04 to TREB 04.
Power Bass Function Connecting Headphones You can connect a set of headphones to your mini-compact our mini-compact system has a bass amplification function system so that you can listen to music or radio programmers called SBS (Super Bass Sound). This function makes the sound without disturbing other people in the room.
Cleaning Your Mini-Compact Safety Precautions System The following diagrams illustrate the precautions to be taken To obtain the best possible results from your mini-compact when using or moving your mini-compact system. system, you must clean the following elements regularly: The outer casing The compact disc player The cassette players (heads, rollers and drive capstans) Always unplug the system from the wall outlet:...
If the above guidelines do not allow you to solve the problem, take a note of: The model and serial numbers, normally printed on the rear of the system Your warranty details A clear description of the problem Then contact your local dealer or SAMSUNG after-sales service. Problem Checks/Explanation The system does not work •...
Technical Specifications SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. RADIO Signal/noise ratio 62 dB Usable sensitivity 10 dB Total harmonic distortion 0.4 %...
Page 23
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region Country Customer Care Center Web Site...
