INSTALLATION

ENVIRONMENT

Leave some space
If the washer is placed on an uneven or weak
surface, noise or vibration may be occured.
(Allowable is 2°)
Never install the washer near water.
Do not place the washer in steamy rooms or
where the washer is directly exposed to rain.
Moisture may destroy the electrical insulation
and cause an electrical shock hazard.
Avoid direct sunlight or heating devices.
As plastic and electrical components are
affected by direct heat, never place the
washer near heaters, boilers,etc.
Do not place under direct sunlight.

CHANGING THE POSITION OF THE DRAIN HOSE

Before attempting to change the position of the
drain hose, disconnect the plug from the outlet.
1. Route the drain hose inside the machine.
2. Take out the drain hose from the opposite hole and
insert the drain hose into the hose holder.

CLEANING THE MACHINE

CLEANING THE LINT FILTER
CLEANING THE WASH TUB
Wipe off strains on the cabinet and operation panel with soft cloth. Do not use benzene, thinners,
cleanser, or wax, nor scrub the washer with a brush.Painted surfaces or plastic parts will be damaged.

HOW TO CLEAN THE FILTER

3. Remove dirts and rotate
locks in position.
Remark : Should be cleaned
Filter at least 1 time a week.

CONNECTING THE DRAIN HOSE

Insert the drain hose(a) and push it tighly to be
connected as arrow direction.
Install the drain hose(A) about 70~80cm above the
ground for pump model.
CLEANING THE COVER WINDOW SPIN
Remark : Should be cleaned the cover window spin
at least 1 time a month.
3
(In case drain pump)
(WITHOUT PUMP)
