Vector AirPro VEC255 Owner's Manual & Warranty

Vector AirPro VEC255 Owner's Manual & Warranty

Corded/cordless, rechargeable compressor and inflator combo
Hide thumbs
Table of Contents

Advertisement

Quick Links

VEC255
CORDED, CORDLESS,
RECHARGEABLE COMPRESSOR
AND INFLATOR COMBO
OWNER'S MANUAL
& WARRANTY INFORMATION
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING
SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT.
BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS,
INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
4140 SW 28TH WAY, FT. LAUDERDALE, FL 33312
TEL 954-584-4446 • TOLL FREE: 866-584-5504 • FAX 954-584-5556
www.vectormfg.com
1

Advertisement

Table of Contents
loading

Related Manuals for Vector AirPro VEC255

Summary of Contents for Vector AirPro VEC255

  • Page 1 VEC255 CORDED, CORDLESS, RECHARGEABLE COMPRESSOR AND INFLATOR COMBO OWNER’S MANUAL & WARRANTY INFORMATION THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD RESULT IN INJURY AND/OR PROPERTY DAMAGE.

  • Page 2: Important Safety Information

    4. Keep out of reach of children. These appliances are not toys! 5. Replace worn or defective parts immediately - contact Vector® Customer Service Department at (954)584-4446 or toll free at 866-584-5504.

  • Page 3: Table Of Contents

    internal battery. For immediate use, attach the DC adapter and operate the appliances from an external 12 volt DC source. 4. To avoid over-inflation, carefully follow instructions on articles to be inflated. 5. Never leave appliances unattended while in use. Allow appliance to cool for five minutes after 10 minutes of continuous operation.

  • Page 4: Introduction

    A customer can purchase extra snap-on battery packs if completely cordless operation is required (Part VEC194). Operating these appliances with the snap-on DC Power Adapters is ideal for use with Vector 12 volt DC cordless, portable, rechargeable DC Power supplies if extended operating time in the field is required.

  • Page 5: Additional Key Features

    The Compressor On/Off Switch controls operation of the compressor. It conveniently is depressed and released to control inflation. An exact pres- sure is obtained by observing the gauge and releasing the trigger when the correct pressure is achieved. For longer inflation operations, the Trigger Lock can be moved laterally to lock the trigger in the ON position.

  • Page 6: Attaching The Compressor's Air Hose

    ATTACHING THE COMPRESSOR’S AIR HOSE The Air Hose is supplied as a separate item from the compressor body. The hose has a ribbed brass fitting at one end and a standard tire chuck at the other end. To use the hose it must first be connected to the compressor outlet. Loosen the Hose retaining ring (counterclockwise), insert the hose fitting into the short, rubber sealing sleeve.

  • Page 7: Charging/Recharging The Battery Pack

    Therefore, these types of batteries need periodic charging to replace energy lost through self-discharge. When the Battery Pack is not in use Vector recommends that the battery is recharged at least every 60 days.

  • Page 8: Compressor/Tire Inflator

    CONTACTS RECHARGE PORT FIGURE 4 RECHARGE LED RELEASE BUTTON 110 VOLT AC WALL ADAPTOR WITH CORD To remove the battery pack from the appliance body for charging: Make sure the trigger switch is OFF. Press both battery pack release buttons at the same time.

  • Page 9: Inflate Other Articles (Without Valve Stem)

    5. Observe pressure with the pressure gauge. 6. When desired pressure is reached, open thumb latch and remove connector from valve stem. 7. Turn OFF Compressor Power Switch IMPORTANT: Always leave the tire chuck thumb latch in the open position when storing unit. 6.2 INFLATE OTHER ARTICLES (WITHOUT VALVE STEM) Inflation of other than tires requires use of one of the nozzles (adapters).

  • Page 10: Low Pressure Inflator

    LOW PRESSURE INFLATOR/DEFLATOR Congratulations on your purchase of the Vector Inflator/Deflator -The ultimate inflator for all high volume, low-pressure recreational inflatables. The VEC255 Combo Inflator/Deflator is supplied with three different sized nozzles. Each nozzle will fit either the inflation port or the deflation port.The nozzles are supplied on a cord attached to the inflator’s body.

  • Page 11: Inflator

    Contact Vector Technical Support and ask for part VEC194. This battery pack is also used with other Vector products that include portable inflators and spotlights. For more details, please contact our Sales or Technical...

  • Page 12: Battery Disposal

    BATTERY DISPOSAL Contains a maintenance-free, sealed, non-spillable, lead acid batter y, which must be disposed of properly. Most states require recycling-contact your local municipal authority for information. Non-spillable sealed lead-acid battery, must be recycled or disposed of properly. Recycling is required -contact your local authority for information. DISPOSAL QUESTIONS FOR USA CALL toll-free 877-288-7722.

  • Page 13: Warranties

    Date of purchase ___________ Store where purchased __________ UPC Number from package (12 digits) ________________________ All Vector Manufacturing, Ltd. products must be registered within (10) days of purchase to activate this warranty. Mail the completed registration form, along with a copy of the original sales receipt to: ATTN.: CUSTOMER SERVICE / VECTOR MANUFACTURING, Ltd.
  • Page 14 30 days of the date of purchase will be replaced free of charge. If such a product is returned more than 30 days but less than three years from the purchase date, Vector Manufacturing will repair the unit or, at its option, replace it free of charge.
  • Page 16 © 2003 VECTOR MANUFACTURING, Ltd. FT. LAUDERDALE, FL 33312 MADE IN CHINA...
