Henny Penny CMC/CMR-103 Operation Manual

Henny Penny
3-1.

INTRODUCTION

3-2.

OPERATING CONTROLS

Fig. Item
No. No.
3-1 1
3-1 2
3-1 3
3-1 4
3-1 5
3-1

SECTION 3. OPERATION

This section provides explanations of all controls, along
with operating procedures and daily maintenance. Read the
Introduction, Installation and Opeation Sections before
operating the unit.
Wait at least 4 hours before plugging the unit into an
electrical supply. The gases and oils in the refrigeration
system needs to settle before operating the compressor, or
damage to the compressor could result.
Refer to figure 3-1.
Description
Power Switch
Digital Display
Model CMC/CMR-103,104,105,106,107
Function
Turns electrical power off and on to the unit; located on the
bottom of the control panel
Shows the temperatures and the information in the Technical
Mode
Used to increase setpoint values, as well as programming
values; also, automatic defrost cycles are programmed in
the controls, but to manually start a defrost cycle, press and
hold for 3 seconds to start a manual defrost cycle;
"DEF/SET' shows in display
Used to decrease setpoint values, as well as programming
values
Press to view the setpoint temperature, or hold it for it for 4
seconds to enter the program mode; once in the Program
Mode, press to view other parameter setpoints;
Press , along with
parameters
and to change the
303
