- Page 1 Glancetron GT19-Wide USER’s GUIDE Touch Screen LCD Monitors Rev.A www.glancetron.com...
-
Page 2: Important Recycle Instructions
The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission. -
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions..........................1 Introduction About Glancetron GT-19Wide ....................2 Touch Screen for Glancetron GT-19Wide ..............2 Package Overview ...................... 3 Installation Product Overview ......................4 Front View ......................4 Bottom View (Without Stand) ................. 4 Kensington Security Slot ....................5 VESA Mount Your Monitor ................... -
Page 4: Usage Notice
Usage Notice Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About Glancetron GT-19Wide The Glancetron GT-19Wide is a 47cm (18.5”) fl at panel screen with an active matrix, thin-fi lm transistor (TFT) liquid crystal display (LCD). Features include: • Direct analog signal input • Active matrix TFT LCD technology •... -
Page 6: Package Overview
Package Overview LCD Display VGA Signal Cable Power Cord USB Cable ( A to B) DC Power Supply RS-232 Cable Quick Start Guide Audio-in Cable Touch Driver CD Screw... -
Page 7: Installation
Installation Product Overview • Front View • Bottom View (Without Stand) RS-232 DC IN POWER SWITCH... -
Page 8: Kensington Security Slot
Kensington Security Slot The monitor can be secured to your desk or any other fi xed object with Kensington lock security products. The Kensington lock is not included. -
Page 9: Vesa Mount Your Monitor
VESA Mount Your Monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface standard which defi nes a physical mounting interface for fl at panel monitors, and corresponding with the standards of fl at panel monitor mounting devices, such as wall and table arms. The VESA mounting interface is located on the back of your monitor. -
Page 10: Start Your Installation
Start Your Installation Please follow these instructions so that you can hookup the cables to associated connector. 1. Lay the LCD fl at on an even surface. 2. Move the stand into position as seen in the step 2 diagram. 3. -
Page 11: Remove The Deskstand
Remove the Deskstand Remove 4 screws and then remove hinge. -
Page 12: Connecting The Display (Figure 10.1)
Connecting the Display (Figure 10.1) To setup this display, please refer to the following fi gure and procedures. 1. Be sure all equipment is turned off. 2. Connect the DC adapter to the power connector on the monitor and the other end into an electrical outlet (10.1). -
Page 13: (Figure 10.1)
(Figure 10.1) -
Page 14: User Controls
User Controls Front Panel Controls Icon key Name Menu Down Enter Power Menu off status Menu on status Menu appear Menu disappear / return to main item Brightness Main item select up / Adjust up Mute Main item select down / Adjust down Enter / Select sub-item function Power On / Off... -
Page 15: How To Use The Osd Menus
How to Use the OSD Menus Icon key Name Menu Down Enter Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the six functions in the main menus. 2. -
Page 16: On-Screen Display Menus
On-Screen Display Menus Main OSD Menu: ITEM CONTENT The monitor luminance level control. Contrast The monitor backlight level control. Brightness Fine-tune the image to full screen automatically. Auto Adjust Moving screen image horizontal position to left or right. Left/Right Moving screen image vertical position to up or down. Up/Down The screen image horizontal dot clock adjustment. -
Page 17: Appendix Troubleshooting
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected described in the "Installation"... -
Page 18: Warning Signal
Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. There may be three sources for this problem. Please check the cable connections or contact your local dealer or our service center for more information. -
Page 19: Product Dimensions
Product Dimensions 457.80 Front View 67.50 60.00 Side View 214.81 Top View... -
Page 20: Compatibility Modes
Compatibility Modes Mode Resolution H-Frequency (KHz) V-Frequency (Hz) IBM VGA 720X400 31.47 IBM VGA 640X480 31.47 Apple Mac 640X480 35.00 VESA VGA 640X480 37.86 VESA VGA 640X480 37.50 VESA VGA 800X600 35.16 VESA VGA 800X600 37.88 VESA VGA 800X600 48.08 VESA VGA 800X600 46.88... -
Page 21: Touch Screen Driver Installation
Touch Screen Driver Installation The Glancetron GT-19Wide is available with both RS232 and USB connections. The touch ® driver is located on the enclosed CD-ROM for these operating systems: Windows 7, VISTA ® 64/32 bits, XP, 2000, ME, 98, NT4.0, CE, XP Embedded, Linux, Apple Mac OS. -
Page 22: Glancetron Gt-19Wide Install Instructions
Glancetron GT-19Wide Install Instructions: ® If you are using a PC running Windows 7, VISTA, XP, 2000, ME, 98, NT4.0, follow the instructions below: 1. Power on the PC. 2. Be sure the USB or the RS-232 Serial cable is connected from the PC to the LCD display. - Page 23 ® If you are using a PC running Windows CE, follow the instructions below: 1. Power on the computer. 2. Make sure that the RS232 or USB cable is connected to the computer. 3. Using Platform Builder, build an image fi le by following the step-by-step instructions found in the folder fi...
