Glancetron 70-SM Operation Manual

Usb display 7" monitor
Hide thumbs

Advertisement

Table of Contents

USB Display
7" Monitor 70-SM

Operation Manual

Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70-SM and is the answer not in the manual?

Questions and answers

Related Manuals for Glancetron 70-SM

Summary of Contents for Glancetron 70-SM

  • Page 1: Operation Manual

    USB Display 7" Monitor 70-SM Operation Manual Version 1.0...
  • Page 2 CONTENTS 1. Safety Instructions................2. Connections and Installation............... 3. Accessories................... 4. Specifications ..................5. Troubleshooting..................

  • Page 3: Safety Instructions

    1. Power adapter: USB 0.75A/5V 2. Do not place 70-SM USB in a location exposed to moisture, dust, smoke, water, or in a car., this may result in electric shock or fire. 3. Clean the product using a soft cloth with a monitor cleaner only.

  • Page 4: Connections And Installation

    2.Connections and Installation 1.Installing monitor driver (Auto Run) Double click the icon 2.Click I Accept. DisplayLink Core software and DisplayLink Graphics installs. Note: The screen may flash or go black during the install...
  • Page 5 3.Connect your DisplayLink device via the USB cable to your PC Note: The power supply needs to be dual USB connector to the PC. you must complete this step before connecting the 70-CT USB Display USB port USB port 4.When the 70-CT USB Display driver installation is complete, the 70-CT USB Display setting icon appears on your system tray.
  • Page 6 3.Accessories Fixation Manual USB Cable Fixation screws Specifications LED backlight Life time 10,000 (Min) Power Supply USB 5V Power Consumption 0.75A Standby power consumption lower then 0.1A Active area 152.4 x 91.5 mm Response time 11ms Color 262,144 Contrast 400 : 1 Brightness 350 cd/m2 Viewing angle...

  • Page 7: Troubleshooting

    The deactivated USB information implies power off or disconnected USB Display status. To delete the deactivated monitor information, please uninstall ‘Displaylink Core software’ driver. Once the driver is uninstalled, you may not use 70-SM USB Display. To use 70-SM USB Display again please re-install the driver.
