NOTE: Please read all instructions carefully before using this product APEX MULTI PURPOSE Table of Contents FID BENCH Safety Notice Hardware Identifier SB 681 Assembly Instruction Parts List Warranty Ordering Parts Model SB 681 Retain This Manual for Reference 03-22-05 IMPEX INC.
TABLE OF CONTENTS BEFORE YOU BEGIN..................IMPORTANT SAFETY NOTICES..............HARDWARE PACK………..…............... ASSEMBLY INSTRUCTIONS................EXPLODED DIAGRAM.................………. PARTS LIST…………………………………………………………………………. WARRANTY....................… ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the APEX Multi Purpose Bench SB681 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine.
IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Main Frame (#1) to the Front Stabilizer (#2). Secure it with two M10 x 2 ¾” Carriage Bolts (#21), one Bracket (#15), two ¾”...
Page 6
STEP 2 (See Diagram 2) A.) Slide the Sliding Block (#5) onto the Incline Adjustment Bar (#4). B.) Attach both ends of Incline Adjustment Bar to the open brackets on the Main Frame (#1). Secure each end with one M10 x 2 ½” Carriage Bolt (#22), Ø ¾” Washer (#27), and M10 Aircraft Nut (#28).
Page 7
STEP 3 (See Diagram 3) A.) Attach the lower holes on the Backrest Supports (#7) to the pivot on the Sliding Block (#5). Secure them with one M12 x 5 ¾” Allen Bolt (#19), two 1” Washers (#25), and one M12 Aircraft Nut (#26). B.) Attach the Seat Support Frame (#6) to the hole on the Backrest Support (#7).
Page 8
STEP 4 (See Diagram 4) A.) Insert the Foam Tube (#10) halfway through the hole on the Main Frame (#1). Push two Foam Rolls (#12) onto the Foam Tube from both ends. Plug the Foam Roll End Caps (#11) into the ends. B.) Place the Seat (#8) onto the Seat Support Frames (#6).
PARTS LIST KEY NO. DESCRIPTION Q’ty Main Frame Front Stabilizer Rear Stabilizer Incline Adjustment Bar Sliding Block Seat Support Frame Backrest Support Seat Backrest Board Foam Tube Foam Roll End Cap Foam Roll Sliding Block Sleeve 2 ¾” x 2” End Cap Bracket Lock Knob 1 5/8”...
IMPEX INC. LIMITED WARRANTY IMPEX Inc. ("IMPEX") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
