Heath Zenith 598-1283-00 Owner's Manual

Motion Sensing Coach
Light with D
Bulb Saver Technologies
Features
• Light comes on when motion is detected
• Automatically turns light off
• D B 2-level lighting
®
ual rite
• Bulb Saver technology
• Multiple operating modes
• Photocell keeps the light off during daylight
hours
This package includes:
• Lantern
• Easy to use Universal Mounting Bracket
• Mounting Hardware
• Wire Connectors
Requirements
• The Light Control requires 120 volts AC.
• If you want to use Manual Mode, the control
must be wired through a switch.
• Some codes require installation by a
qualified electrician.
Before installation, record the model number
from back of fixture below. Attach receipt in
case of possible warranty issues.
© 2007 DESA Specialty Products™
B and
®
ual rite
OPERATION
Mode: On-Time:
Test
5 Sec
Normal
1, 5, 10 min.
Manual
Until Dawn*
Accent 3, 6 Hr, to Dawn
* resets to Auto Mode at dawn.
Set the ON-TIME switch on
the bottom of the cover plate
to TEST and the D
ual
switch OFF.
AUTO
Set ON-TIME switch to
1, 5, or 10 minutes.
MANUAL MODE
Manual mode only works at
night because daylight re-
turns the sensor to AUTO.
Flip the light switch off for
one second then back on to
toggle between AUTO and
MANUAL MODE.
Manual mode works only
with the ON-TIME switch in
the 1, 5, or 10 position.
Works: Day Night
x
TEST
ON-TIME
B
®
rite
TEST 1 5 10 MIN
ON-TIME
TEST 1 5 10 MIN
1 Second
OFF then...
... back on.
598-1283-00
x
x
x
x
