LED Indicators
G
P
IGABIT
ORTS
The FriendlyNET GX4-224 features two Gigabit Ethernet ports (1000BaseT).
LED
Color
Indicator
1G LNK
Green
ACT
Green
FDX/HDX
Green
10/100 P
ORTS
The FriendlyNET GX4-224 has 24 10/100 Fast Ethernet ports (10BaseT/100BaseTX).
LED
Color
Indicator
LNK/SPD
Green
Ambe
r
DPX/ACT
Green
Ambe
r
Gigabit Ethernet Network Connections
For best results, Asanté recommends:
Release Note: FriendlyNET GX4-224
Description
ON with a valid 1000 Mbps link
OFF when there is no connection
BLINKING if there is a possible data error; see Troubleshooting section of
User's Manual
BLINKING during normal network activity (transmission or reception)
ON for normal operation (full duplex)
Description
ON with a valid 100 Mbps link
OFF when there is no connection
ON with a valid 10 Mbps link
OFF when there is no connection
ON in full duplex mode; blinking during normal network activity
BLINKING in half duplex mode with normal network activity
FriendlyNET GX4-224
Release Note
06-00588-00 Rev A
