4. Specifications
Model
DF-F1043b, DF-1044r & DF-1045s
314(h) x 257(v) x40(d)
Unit Size
211.2(h) x 158.4(v)
Display Area
Resolution
640x480
Colors
262,144
350cd/m
Brightness
300:1
Contrast angle
Viewing angle
70/70 (l/r),70/40(u/d)
AC100—240V(50HZ—60HZ)
I
t
lt
0 ---50
Operation Temperature
Net Weight
1.5kg
Media Supported
MPEG1/2/4, MP3/JPEG
Cards Supported
CF /MS/SD/MMC/SM/XD
Auto Start Mode
Auto Slide Show JPEG
1. Loop, Zoom In
2. Auto Slide Show
3. Slide Show with background MP3 music
4. File name, File size, Resolution, Date Display
Photo Playback Mode
5. Interval Time Setup
6. Transition Setup
7. Play/Stop/Pause
1. Play/Stop/Pause
2. Volume Adjust
Music Playback Mode
3. Repeat Model Setup
4. File Type, Total Time, Date, Display
1. Play/Stop/Pause
2. Volume Adjust
Video Playback Mode
3. Zoom in
4. File information, Time and Date Display
2
max.
1. Remote Control
2. AC Adapter
Accessories
3. Operation Manual
5. Control and Memory Card Slots
Display
Decorative Frame
Auto
Menu
Volume
Power
6. Setting up your DigiFrame
·Open the package and remove your DigiFrame from the protective
packaging.
·Plug the AC adapter into a power outlet. Plug the other end into the unit.
·Insert your memory card into the designated slot.
·Turn power to On position via the On/Off Button. The power button is on the
right hand side of the frame
Desktop Stand
AV Power
SM/XD
Arrow
MS/SD/MMC/CF
