WD7752C8(A/C/D/F/G/H/R/S/T/V/W/Z)

Washing Machine

user manual

imagine
the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/hk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD7752C8A and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WD7752C8A

Summary of Contents for Samsung WD7752C8A

  • Page 1: Washing Machine

    WD7752C8(A/C/D/F/G/H/R/S/T/V/W/Z) Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/hk...

  • Page 2: Air Wash

    • Not applicable : leather, silk, velvet, electric blankets, other dirty laundry • Silver Wash Samsung’s silver Nano feature uses silver nano particles to sanitize and disinfect your laundry and your machine’s drum. Delicates as well as smelly socks will get odor-free from human sweat at temperature as low as 30˚C.

  • Page 3: Safety Information

    Check the machine before the first use, and never plug it in if there’s obvious damage. Consult your local product service agent or Samsung dealer for any questions. Please frequently clean the dirt in the debris filter. Refer to “CLEANING THE DEBRIS FILTER”.

  • Page 4: Safety Instructions

    safety information SAFETY INSTRUCTIONS Before cleaning or carrying out maintenance, unplug the appliance from the electrical outlet or set the (Power ) button to Off. WARNING Make sure that the pockets of all clothing to be washed are empty. Hard, sharp objects, such as coins, safety pins, nails, screws, or stones can cause extensive damage to the appliance.

  • Page 5: Table Of Contents

    contents INSTALLING THE WASHING MACHINE Unpacking the Washing Machine Overview of the washing machine Selecting a location Adjusting the leveling feet Removing the shipping bolts Connecting the water supply hose Connecting the water supply hose (Option) Positioning the drain hose WASHING A LOAD OF LAUNDRY Washing for the first time Putting detergent in the washing machine...

  • Page 6: Installing The Washing Machine

    Unpack your washing machine and inspect it for shipping damage. Also make sure that you have received all of the items shown below. If the washing machine was damaged during shipping or you do not have all of the items, contact your Samsung dealer immediately. OVERVIEW OF THE WASHING MACHINE...

  • Page 7: Selecting A Location

    SELECTING A LOCATION Before you install the washing machine, select a location with the following characteristics: • A hard, level surface (if the surface is uneven, see “Adjusting the leveling feet,” below) • Away from direct sunlight. • Adequate ventilation •...

  • Page 8: Connecting The Water Supply Hose

    installing the washing machine CONNECTING THE WATER SUPPLY HOSE The water supply hose must be connected to the washing machine at one end and to the water faucet at the other. Do not stretch the water supply hose. If the hose is too short, replace the hose with a longer, high pressure hose.

  • Page 9: Connecting The Water Supply Hose (Option)

    The drain pipe branch must be above the sink siphon so that the end of the hose is at least 60 cm above the ground. ln a drain pipe Samsung recommends that you use a 65 cm high vertical pipe; it must be no shorter than 60 cm and no longer than 90 cm. Installing the washing machine _9...

  • Page 10: Washing A Load Of Laundry

    washing a load of laundry WASHING FOR THE FIRST TIME Before washing clothes for the first time, you must run a complete cycle without clothes. To do this: 1. Press the (Power) button. 2. Pour a little detergent into compartment ( ) in the detergent drawer.

  • Page 11: Overview Of The Control Panel

    OVERVIEW OF THE CONTROL PANEL part indicates the washing process: (Wash)- (Rinse)- (Spin)- (Dry) Digital graphic Displays the remaining wash cycle time, all of washing information and error display messages. Press the button repeatedly to cycle through the Deodorization and Sterilization functions.
  • Page 12 washing a load of laundry Temperature Press the button repeatedly to cycle through the available water temperature selection button options. (cold(0˚C), 30˚C, 40˚C, 60˚C and 95˚C) Rinse Times Press the rinse button to add rinse cycles. Maximum number of rinse cycles selection button is five.

  • Page 13: Washing Clothes Using Fuzzy Logic

    WASHING CLOTHES USING FUZZY LOGIC Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Logic” automatic control system. When you select a wash programme, the machine will set the correct temperature, washing time, and washing speed. To wash clothes using the Fuzzy Logic programs: 1.

  • Page 14: Washing Clothes Manually

    washing a load of laundry WASHING CLOTHES MANUALLY You can wash clothes manually without using the Fuzzy Logic feature. To do so: 1. Turn the water supply on. 2. Press the (Power) button on the washing machine. 3. Open the door. 4.

  • Page 15: Using Airwash Options

    USING AIRWASH OPTIONS The air system deodorises and sanitises your clothes and reduces wrinkles on them with smooth air washing. Conditions in which to use Airwash 1. A suit that’s starting to get a bit smelly 2. A woolen jumper that’s been sitting in the back of your closet since last winter and is now getting musty Advantages of Air wash 1.

  • Page 16: Intensive Dry/ Gentle Dry

    washing a load of laundry INTENSIVE DRY/ GENTLE DRY When you need to dry your clothes, you can choose program of Intensive Dry or Gentle Dry. To do this: 1. Press the (Power) button. 2. Open the door, load the articles to dry, and close the door. 3.

  • Page 17: Washing Tips And Hints

    WASHING TIPS AND HINTS Sorting your laundry: Sort your laundry according to the following characteristics: • Type of fabric care label symbol: Sort laundry into cottons, mixed fibres, synthetics, silks, wools and rayon. • Colour: Divide whites and colours. Wash new, coloured items separately. •...

  • Page 18: Maintaining The Washing Machine

    maintaining the washing machine DRAINING THE WASHING MACHINE IN AN EMERGENCY 1. Unplug the washing machine from the power supply. 2. Open the filter-cover by using a coin or a key. 3. Unscrew the emergency drain cap by turning left. Grip the cap on the end of the emergency drain tube and slowly pull it out about 15 cm.

  • Page 19: Cleaning The Detergent Drawer And Recess

    maintaining the washing machine CLEANING THE DETERGENT DRAWER AND RECESS 1. Press the release lever on the inside of the detergent drawer and pull it out. 2. Remove the cap from compartment ( ). 3. Wash all of the parts under running water. 4.

  • Page 20: Cleaning The Water Hose Mesh Filter

    maintaining the washing machine CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh filter at least one time per year, or when you see the following error message on the display: To do this: 1. Turn off the water source to the washing machine. 2.

  • Page 21: Troubleshooting

    troubleshooting PROBLEMS AND SOLUTIONS PROBLEM SOLUTION The washing machine • Make sure the door is firmly closed. will not start • Make sure the washing machine is plugged in. • Make sure the water source faucet is turned on. • Make sure to press the Start/Pause button.
  • Page 22 programme chart PROGRAMME CHART user option)  Detergent and Max load (kg) Spin Speed(Max) rpm Temp Delay Silver Additives Programme (˚C) start Wash WD7752C8 Wash Softener WD7752C8 Standard 1200    1200 Super Quick    1200 Child ...
  • Page 23 programme chart user option)  Detergent and Max load (kg) Spin Speed(Max) rpm Temp Delay Silver Additives Programme (˚C) start Wash WD7752C8 Wash Softener WD7752C8 Intensive 1200     Single Wash 1200    Single Rinse 1200 ...

  • Page 24: Appendix

    appendix FABRIC CARE CHART Resistant material Can be ironed at 100˚C max Delicate fabric Do not iron Can be dry cleaned using any Item can be washed at 95˚C max solvent Dry clean with perchloride, lighter Item can be washed at 60˚C max fuel, pure alcohol or R113 only Dry clean with aviation fuel, pure Item can be washed at 40°C max...

  • Page 25: Declaration Of Conformity

    appendix DECLARATION OF CONFORMITY This appliance complies with European safety standards, EC directive 93/68 and EN Standard 60335. SPECIFICATION TYPE FRONT LOADING WASHER WD7752C8 DIMENSION W598mm X D634mm X H840mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME 90 ℓ WEIGHT 80 kg MODEL...
  • Page 26 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT HONG KONG 3698-4698 www.samsung.com/hk Code No. DC68-02413K_EN...
  • Page 27 WD7752C8(A/C/D/F/G/H/R/S/T/V/W/Z) 您 您 夠 您 www.samsung.com/hk...
  • Page 28 • 殺 殺 蟎 殺 殺 • 殺 • 耍 啓 您 • 啓 您 • 您 •...
  • Page 29 您 夠 泵 泵 您 擕...
  • Page 30 查 查 燙 耍 • 苯 烯 • 氯 • •...
  • Page 31 腳 殺 殺...
  • Page 32 查 查 控制面板 腳 擋 扳...
  • Page 33 • 腳 • • ˚C。 碳 • 灶 擋 腳 腳 腳 墊 腳 扳 擰 扳 擰 寬...
  • Page 34 扯 擰 擰 您 擰 擰 擰...
  • Page 35 擰 嗒 墊 您...
  • Page 36 • 您 您...
  • Page 37 殺 您 殺 殺 蟎 殺 您 殺 殺 您 您 值 您...
  • Page 38              啓...
  • Page 39 啓 您 啓 啓...
  • Page 40 您 啓 您 ˚ ˚ ˚ ˚ ˚ 您 您 您 您...
  • Page 41 殺 殺 燙 墊 • 啓 殺 您 • 啓 殺 • • • 墊 • • • 髒 • 殺 • • • • 您 您...
  • Page 42 殺 殺 啓 您 • 殺 • 殺 您 • 您 您 您 您 • 您 • 您 • 您 您 您 • 您 • • 您 您 夠 您...
  • Page 43 您 您 夠 • • • 查 • 您 髒 您 骯髒 骯髒 查...
  • Page 44 擋 擋 您 您 查...
  • Page 45 您 擋 3. 擰 污 泵 擋...
  • Page 46 2. 擰...
  • Page 47 • 啓 • • • • • • • • • • 腳 • • • 勻 • • • • 擋 • • 查 • • 查 • 查 • • • 勻 褲 • 查 查 • 查...
  • Page 48 ，√ ● 脫 ˚ WD7752C8 WD7752C8 √ √ 1200   ● √ √ 1200   ● √ √ 1200   ● √ √  － ● √  － － ● √ √ 1200  － － 髒...
  • Page 49 ，√ ● 脫 ˚ WD7752C8 WD7752C8 √ 1200    ● √ 1200    － 1200    － ● 1200   － － － 污 髒 桌 褲...
  • Page 50 氯 晾 晾 晾 氯 您 • • 踩 • 拖 • • • 污 • •...
  • Page 51 寬 泵...
  • Page 52 DC68-02413K...
