- Page 1 OWNER´S INSTRUCTIONS AW12FCDBC AW24FCDBC Window-type Room Air Conditioner (Cool) DB 98-23704A (2)
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when installing and using your air conditioner. The air conditioner must be plugged into its own specific power source, which must be installed in compliance with national wiring, earthing and safety regulations. Depending on national regulations and your specific installation, you may need to install: A circuit breaker For further information on electrical requirements, contact a professional electrician. -
Page 3: Table Of Contents
Contents REPARING ONDITIONER Safety Precautions ..................Air Conditioning Unit - Main Parts, Buttons and Display ....... Remote Control Buttons ................. Getting Started ....................Inserting the Remote Control Batteries ............PERATING ONDITIONER Cooling Your Room ..................Airing Your Room ................... Adjusting the Air Flow Direction Vertically ............10 ROGRAMMING ONDITIONER Setting the On Timer .................. -
Page 4: Air Conditioning Unit - Main Parts, Buttons And Display
Air Conditioning Unit - Main Parts, Buttons and Display The design and shape are subject to change according to the model. .If a power failure occurs when the air conditioner is operating, the unit is switched off Then the power returns, the air conditioner starts up again automatically. Inner air flow blades (right/left orientation) Air outlet... -
Page 5: Remote Control Buttons
Remote Control - Buttons Timer setting button Temperature adjustment buttons Operating mode selection buttons Fan speed adjustment buttons On/Off button... -
Page 6: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contain valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s functions. This Owner’s Instructions is just for using your air conditioner correctly. -
Page 7: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when: You purchase the air conditioner The remote control does not work correctly Use two AAA, LR03 1.5V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 8: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to lower the temperature in your room. You can also set the fan speed. Remote Control Control Panel If necessary, press the (On/Off) button. Result : The operating mode indicator (COOL or FAN) on the unit comes on. -
Page 9: Airing Your Room
Airing Your Room If you wish to provide ventilation, you can use the Fan feature. Remote Control Control Panel If necessary, press the (On/Off) button. Result: The air conditioner starts up in the mode selected when the unit was last used. The unit beeps twice. -
Page 10: Adjusting The Air Flow Direction Vertically
Adjusting the Air Flow Direction Vertically Again depending on the position of the unit in your room, you can adjust the orientation of the outer air flow blades on the right-hand side of the unit. RECOMMENDATION When... Adjust the blades to face... Cooling Upwards. -
Page 11: Setting The On Timer
Setting the On timer The On Timer enables you to switch on the air conditioner automatically after a given period time. You can select the On timer only when the air conditioner is off. Remote Control Control Panel Check that the air conditioner has been switched off; if necessary, press the (On/Off) button. -
Page 12: Setting The Off Timer
Setting the Off Timer The Off Timer enables you to switch off the air conditioner automatically after a given period of time. You can set the period of time from 1 hour to 12 hours. Remote Control Control Panel You can select the Off timer only when the air conditioner is on. Check that the air conditioner has been switched on;... -
Page 13: Recommendations
Operating Recommendations Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation Power failure If a power failure occurs when the air conditioner is operating, the unit is switched off. When the power returns, the air conditioner starts up again automatically. -
Page 14: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner Be sure to clean the air filter périodically to maintain the air conditioner in the best condition for a long period of time. de tiempo. When cleaning the air conditioner, turn it off and pull out IMPORTANT the power plug. -
Page 15: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary service call. Problem Explanation/Solution The air conditioner does not Check that the circuit breaker used for the air conditioner has not operate at all been triggered. -
Page 16: Technical Specifications
Technical Specifications Design and specifications are subject to change without notice Model Power Supply /BA/BB/BC 220V~, 60Hz... - Page 17 Installation (for 60Hz) Electrical Requirements For personal safety: This appliance must be properly grounded. Do not, under any circumstances, cut or remove the third grounding prong from the power cord. We recommend that you do not use an extension cord or an adapter plug with this appliance.
-
Page 18: Installation
Installation Before installation, be sure to check the installation area or the air conditioner, and drain hose. Checkpoints prior to installation Check the cabinet and front grille of the unit for any harmful defects such as scratches. Be sure to check the power supply. - Refer to the specifications on the label attached to the unit. - Page 19 Installation of the Drain Tube Rear Fix the drain tube as shown in the figure. Rubber cap Gasket Drain Tube Screws(2EA) Installation of the Drain Pan The procedure for installing the drain pan should be determined by the condition of the installing area. In the case of an area where the drain pan can not be directly installed on the rear side of the unit after installing the air conditioner.
- Page 20 THIS AIR CONDITIONER IS MANUFACTURED BY:: ELECTRONICS Printed in Mexico...
