Page 1: User Guide
5PORT/8PORT NWAY SWITCH User Guide... -
Page 2: Fcc Statement
5PORT/8PORT NWAY SWITCH FCC STATEMENT Every 10/100 Switch has been tested and complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 3 5PORT/8PORT NWAY SWITCH Chapter 1: Introduction This newly redesigned 5Port and 8Port 10/100 Switch can significantly increase your network traffic speed. A switch serves the same function as a hub in a network design tying your network equipment together. But unlike a simple-minded hub which divides the network’s bandwidth among all the attached devices, a switch delivers full network speeds at each port.
- Page 4 5PORT/8PORT NWAY SWITCH 5/8 ports 10/100Mbps TX Auto-Negotiation Ethernet Switch Full/Half-Duplex capability on every TX port Supports TP interface Auto MDIX function for auto TX/RX swap Automatic Source MAC Address Learning and Aging Supports Store & Forward architecture and performs forwarding and filtering Broadcast Storming Filter function IEEE802.3x flow control for Full-duplex Back Pressure function for Half-duplex operation...
- Page 5 5PORT/8PORT NWAY SWITCH Dimension: 131mm(L) x 71mm(W) x 28mm(H) Temperature: ℃ ℃ Storage– -20 ℃ ℃ Operating – 0 to 50 to 70 Humidity: Operating – 10% to 90% RH Storage – 5% to 90% RH Input Power Requirement: 120VAC, 60Hz Registrations: FCC Part 15 Class A, CE Chapter 2: Hardware Description...
- Page 6 5PORT/8PORT NWAY SWITCH Rear Panel The rear panel of the 5/8 Port Switch indicates 5/8 RJ-45 PORT. Figure of 5/8 Port Smart Switch rear panel Side Panel The side panel of the 5/8Port Switch indicates a DC inlet, which accepts 100-240V 50-60Hz Power adapter.
- Page 7 5PORT/8PORT NWAY SWITCH Chapter 3: Hardware Installation Place the Switch on a smooth surface Connect the output of power cord to the DC-inlet of the Switch. Connect other IEEE802.3 compatible network device (Hub, Switch, PC) to one port of the Switch using Category 3/4/5 UTP/STP cabling.
- Page 8 5PORT/8PORT NWAY SWITCH Chapter 4: Hardware Troubleshooting This chapter contains information to help you solve problems. If the Switch is not functioning properly, make sure the Switch was set up according to instructions in this manual. 1. The Power LED is not lit Solution: a.
- Page 9 5PORT/8PORT NWAY SWITCH Ethernet Switching. If the Ethernet Switching is set to full duplex and the partner is set to half duplex, then the performance will be poor. b. Make sure the cable between the switch and other IEEE802.3 compatible network device is Category 5 UTP at 100Mbps operation.
