USER MANUAL

S1500/S1504/S2000
PROFESSIONAL POWER AMPLIFIER
Chevin Research, Kreuzbichlstraße 29 A-6112 Wattens, Austria
Tel/Fax: +43 (0)5224 51398
chevin.martin @aon.at
,
sales@chevin-research.com
www.chevin-research.com
1
Contents
Important Safety Instructions .................
Introduction ............................................
Front Panel ............................................
Rear Panel .............................................
Clip-Limiter ............................................
Subsonic Filter .......................................
Caution: To reduce the risk of electric shock do not remove the
cover. No user-servicable parts inside. Refer servicing to qualified service personnel.
Warning: To prevent fire or electric shock do not expose this equipment to rain or moisture.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and servicing instructions in the literature accompanying
the product.
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulted "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
WARNING - When using electric products basic precautions should always be followed,
including the following:
-
Read all these instructions before using the product.
Do not use the product near water e.g. near swimming pool, kitchen sink, bathtub, or
-
in a wet basement, etc.
-
This product, either alone or in combination with other sound equipments, is capable
of producing sound levels that can cause permanent hearing loss. Do not operate
the product for a long time at high volume level.
The product should be located away from heat sources such as direct sunlight or
-
other sources of heat.
-
The product should be connected to a power supply only of the type marked on the
rear panel of the product.
-
The power supply cord of the product should be unplugged from the mains socket
when left unused.
2
GND Ground ..........................................
3
Stereo Mode ..........................................
3
Mono Mode ............................................
4
Bridge Mono Mode .................................
4
Installation and Dimensions .................
5
Technical Specifications ........................
2
5
5
6
7
8
11
