Q-See QSPMIC User Manual

MODEL: QSPMIC
POWERED MICROPHONE
CCTV SYSTEM
www.q-see.com
：

C. MAIN COMPONENTS

④
③
② ①
1、DC CONNECTER
2、VIDEO OUTPUT CONNECTER
T o prevent fire or shock hazard do not expose the insides of
WARNING
the unit to rain or moisture.
T his symbol alerts the user to the presence of important operating and
maintenance issues according to the manual.
!
SA 1966
T his symbol alerts the user to the presence of uninsulated dangerous
voltage within the product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock .
SA 1965
CAUTION:
CAUTION:
RISK OF ELECTRIC SHOCK
To prevent electric shocks and
DO NOT OPEN
!
risk of fire hazards, only use the power
supply specifled for unit.
CA UT I ON: T O RE DUCE T HE RI S K OF E LE CT RI C S HOCK DO NOT
RE MOV E COV E R (OR B A CK ) NO US E R-S E RV I C E A B LE P A R TS
I NS I DE RE F E R S E RV I CI NG T O QUA LF I E D S E RV I C E
P E RS ONI NE L
Warning- T his equipment has been tested and found to comply with the limits for a
Class A digital device.These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates,uses,and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Any changes o r modifications in construction of this device which are not
Caution
expressly app ro ved b y the part y responsible for compliance could void
the users' authority to operate the equipment.
：

D. SPECIFICATIONS

Audio output
1.0Vp-p
amplitude
Connected cable 60FT LONG CABLE WITH AUDIO
Power adapter DC12V 500mA
Operation
-20℃～+50℃
Temperature
Storage
-40℃～+60℃
temperature
Dimensions 0.98 * 0.39 in (25 * 10) mm
Weight 0.81 oz ( 23 g )
：

A. PRECAUTIONS

（ a） When using power adapter in the package or user other
power adapter, please care about the power supply
polarity . Wrong connection will Damage the product.
（ b） Indoor use only, can not be waterproof.
：

E. DIMENSIONS

：

B. FEATURES

In remote audio detection, have high sensitivity
Wide supply voltage range, Can work
Standard RCA Conecter. Can be connected co
With Velcro, can be combined convenient
MONITOR
