Page 1: Installation Instructions
Toledo XT Dual Fuel Range Users Guide Installation Instructions This book contains many important safety messages. Always read and obey all safety messages. Installer: Leave these instructions with the appliance. U109800-02 www.heartlandapp.com &... -
Page 2: What To Do If You Smell Gas
Warning The anti-tip device supplied with this range must be correctly fitted when the appliance is installed. This will reduce risk of tipping of the appliance from abnormal usage or by excessive loading of the oven door. -
Page 3: Table Of Contents
Contents General Safety Instructions Cooktop Burners The Ovens Storage Multi-function (Left hand) Oven cooking guide Cooking chart Cleaning your range Troubleshooting Service and spares Installation Using your Range The Left Hand Multi-function Oven The Right Hand Convection Oven The Clock... -
Page 4: Important Safety Information
NEVER leave any items on the range cooktop. The hot air from the oven or broiler vent may ignite flammable items and may increase pressure in closed containers, which may cause them to burst. -
Page 5: Wear Suitable Clothing
Do not allow children to climb or play around the range. The weight of a child on an open door may cause the range to tip, resulting in serious burns or other injury. -
Page 6: Important Safety Notice And Warning
Use dry oven gloves when applicable - using damp gloves might result in steam burns when you touch a hot surface. Never operate the range with wet hands. Important Safety Notice and Warning The California Safe Drinking Water and Toxic... -
Page 7: Placement Of Oven Racks
CAUTION Do not store items of interest to children in cabinets above a range or on the backguard of a range - children climbing on the range to reach items could be seriously injured. - Page 8 The specification of this range should not be altered. This appliance is heavy, take care when moving it. When the range is not in use ensure that the control knobs are in the off position.
-
Page 9: Cooktop Burners
Adjust the flame height to suit by turning the knob. On this range the low position is beyond high, not between high and off. The ‘LO’ marks the low position. Turn the knob towards it after the contents of a pan have boiled. -
Page 10: Igniting Cooktop Burners Without Electricity
3. Turn burner control knob to OFF position when finished. You can remove the burner cap and head for cleaning, see page 22. You should wipe the enamel top surface of the range around the cooktop burners as soon as possible after spills occur. Note: Use of aluminum pans may cause metallic marking of the grates. -
Page 11: The Ovens
The oven heating light will glow until the oven has reached the temperature you selected. It will then cycle on and off during cooking. Using your Range The Right Hand Convection Oven The fan in the right hand oven circulates hot air continuously, which means faster more even cooking. -
Page 12: The Clock
To stop the beeper when it sounds Turn the Adjusting knob counter clockwise Using your Range To stop automatically Use when you have started the oven manually. Turn the Setting knob to the ( Use the adjustment knob to set the time you need. - Page 13 This means that your child could select a cook program but the program will not be activated and ovens will not switch on. Using your Range To activate the key lock Turn and hold the Setting knob to the clock symbol ) for about 8 seconds.
-
Page 14: Both Ovens
Automatic cooking is not recommended for baked items that require a pre-heated oven such as cakes, cookies and breads. Using your Range Both ovens Before using for the first time, heat the ovens to 400°F for 30 minutes to expel manufacturing odors. -
Page 15: Multi-Function Oven
Multi-function oven The left hand oven of your range is Multi-function. It has many varied uses. We suggest you keep a careful eye on your cooking until you are familiar with each function. Remember - not all functions will be suitable for all food types. -
Page 16: Oven Light
‘steam burst’, when the oven door is opened. When opening the oven stand well back and allow any steam to disperse. Using your Range When the oven is on, don’t leave the door open for longer than necessary, otherwise the knobs may get very hot. -
Page 17: Deluxe Oven Tray
Flat rack Drop rack Using your Range The oven racks can be easily removed and refitted. Pull the rack forward until the back of the rack is stopped by the rack stop bumps in the oven sides. -
Page 18: Storage
The drawer can be removed completely for cleaning etc. To remove the drawer pull it right out. Using your Range Lift up the ends of the plastic clips (one each side) to release the catches holding the drawer to the side runners and at the same time pull the drawer forward and away from the side runners. -
Page 19: Multi-Function (Left Hand) Oven Cooking Guide
Multi-function (Left hand) Oven cooking guide Remember - not all modes will be suitable for all food types. The oven control settings and cooking times given are intended to be used only as a guide. Individual tastes may require the temperature to be altered to provide a preferred result. -
Page 20: Cooking Chart
Fruit Pie 375°F Tartlets 375°F Puff Pastry 425°F BREAD 425°F MERINGUES 230°F PUDDINGS Baked Egg Custard 325°F Baked sponge pudding 375°F Using your Range Convection Oven Rack Temp Position Temp 350°F 350°F 350°F 300°F 375°F 300°F 375°F 350°F 375°F 300°F 375°F... -
Page 21: Cleaning Your Range
Do not clean until the area is completely cooled down. Wipe up spills as soon as possible. Do not allow surplus water to seep into the range. Cooktop burners Some models have a separate trim ring, which fits on the burner head. -
Page 22: Control Panel And Doors
If necessary move the range forward to gain access to the sides of the doors (see the ‘Moving the range’ section of these instructions). The door front panel is held by four fixing screws, two... - Page 23 Using your Range Once the linings are removed, the oven enamel interior can be cleaned. When replacing the linings fit the side linings first.
-
Page 24: Cleaning Chart
All Parts listed here can be cleaned using hot soapy water (dishwashing liquid detergent) and a soft cloth. For more difficult cleaning, follow the appropriate instruction. Check cleaner manufacturers guidelines for compatibility with the material of your range. Part Burner Grates & Burner... -
Page 25: Troubleshooting
A dish of water when placed on the rack should be the same depth all over. (For example, if it is deeper at the back, then the back of the range should be raised up or the front lowered). If the range is not level arrange for your supplier to level it for you. -
Page 26: Service And Spares
You may be required to produce the receipt to validate a warranty field visit. Fuel Type: Dual Fuel Name of Appliance & Color* Heartland Toledo XT Appliance Serial Number * Retailers Name & Address Date of Purchase Installers Name & Address Date of Installation * This information is on the appliance data badge. -
Page 27: Out Of Warranty
Service work should only be carried out by technically competent and suitably qualified personnel. Spare Parts To maintain optimum and safe performance, only use genuine spare parts. Do not use re-conditioned or unauthorized gas controls. Contact your retailer. Using your Range... -
Page 28: Installation
Anti-Tip Device Gas Connection Electrical Connection Assemble the range Range operational checks How To Remove the Range for Servicing Conversion to Propane Technical Data Schematic diagram of the Range This book contains many important safety messages. Always read and obey all safety messages. -
Page 29: For Your Safety
• Flare union adapter for connection to gas supply • Flare union adapter for connection to pressure • To protect any floor covering under the range a the range on a stone or concrete floor) with Teflon* that resists action of natural and LP gases. -
Page 30: Installation Safety Instructions
Caution Items of interest to children should not be stored above a range - children climbing on the range to reach items could be seriously injured. Converting to LP Gas This appliance is supplied set for Natural gas. -
Page 31: Positioning The Range
Canada 44-5/16” (112.5cm)) between units to allow for moving the range. If a flush fit is required (USA only), fit the range up to the unit at one side then fit the unit the other side. A clearance of 5” (13cm) is required if the range is near a corner of the kitchen to allow the oven doors to open. -
Page 32: Moving The Range
The range should be installed on a sheet of plywood (or similar material). When the floor covering ends at the front of the range, the area that the range will rest on should be built up with plywood to the same level or higher than the floor covering. -
Page 33: Checking The Parts
Remove all tape and packaging. Make sure the burners are properly seated and level. Take the accessory pack out of the oven. Check to be sure that no range parts have come loose during shipping. Installation Instructions Save these instructions for future reference. -
Page 34: Gas Supply Requirements
When you are satisfied with the height and level raise the front of the range by one turn of the front roller adjuster. Screw down the front feet to meet the floor. Screw the front roller adjuster counter clockwise to... -
Page 35: Connect The Range To The Gas Supply
Make sure you are supplying your range with the correct type of gas. If the range is to be used on LP gas, a qualified LP installer must convert it. We recommend that the range be converted before installation. This must be done before the range can be used on LP gas. -
Page 36: Electrical Power Supply Requirements
(not existing) utilize a 4-conductor connection to an electric range. Connecting using the supplied cord and plug Your range is shipped with a 4-prong plug to be used in a NEMA 14-50R receptacle. Recommended Electrical Outlet Locations Locate the electric supply as illustrated. - Page 37 The range is shipped with reducer plates to give a 1 1/8’’ diameter opening for conduit connection. Find the reducer plates in the conversion kit and fit them to the mounting bracket.
- Page 38 The range is shipped with reducer plates to give a 1 1/8’’ diameter opening for conduit connection. Find the reducer plates in the conversion kit and fit them to the mounting bracket.
-
Page 39: Installing The Flue Grille
Seal the Openings Seal any openings in the wall behind the range and in the floor under the range when hookups are completed. When all Connections are Completed MAKE SURE THE FLOW OF COMBUSTION AND VENTILATION AIR TO THE RANGE IS UNOBSTRUCTED. -
Page 40: Oven Check
Check Ignition of Cooktop Burners Operation of all cooktop burners should be checked after the range and gas supply lines have been carefully checked for leaks. Check each burner in turn. There is a flame safety device that stops the flow of gas to the burner if the flame goes out. -
Page 41: Customer Care
Please complete your details in the inside cover of this Guide. Then replace this Installation Guide back in the Customer Care Pack in the correct position. Please inform the user how to operate the range and hand over the Customer Care Pack Thank you. -
Page 42: Valve Adjustment
If your range is removed for any reason, make sure the anti-tip device is re-engaged properly when the range is replaced. Failure to take this precaution could result in tipping of the range and cause injury. -
Page 43: Gas Regulator
Disconnect from electricity and gas before servicing. Check ap pli ance is safe when you have finished. Lower control panel clear. Unscrew the tap bypass screw. A valve bypass screw Using a pair of long nose pliers carefully remove the bypass screw and fi... -
Page 44: Pressure Testing
Check the appliance is gas sound. When all connections have been re-made, make sure all range controls are in the off position and turn on the main gas supply valve. Use a liquid leak detector at all joints and connections to check for leaks in the system. - Page 45 Read all instructions before installing or using this appliance. Orifices A Wok burner B Large Burner C Medium Burners D Small Burner Ratings Cooktop Wok burner Large Burner Medium Burners Small Burner Gas burner inputs based on Gross Calorific Value Ovens Fan element Top element...
-
Page 46: Schematic Diagram Of The Range
SERVICING - WARNING Disconnect from electricity and gas before servicing. Check ap pli ance is safe when you have finished 46 46... - Page 48 Heartland Appliances Inc 1050 Fountain Street North, Cambridge, Ontario, Canada N3H 4R7 Technical Support: 1-800-361-1517 www.heartlandapp.com U109800-01...
