HP Compaq LE19f Specification page 2

HP Compaq LE19f 19-inch WLED Backlit LCD Monitor
VV081AA
Part number
Panel type 48.14 cm (19-inch) diagonal Wide-Aspect Active Matrix TFT (thin film transistor)
Viewable image area 48.14 cm (19 in) widescreen (WXGA+); diagonally measured
Viewing angle Up to 160° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness** 250 nits (cd/m
Contrast ratio** 1000:1
Response rate** 5 ms (on/off)
Frequency Horizontal: 24 to 83 kHz; Vertical: 50 to 76 Hz
Native resolution 1440 x 900 @ 60 Hz
Resolutions supported 1440 x 900 @ 60 Hz, 1280 x 1024 @ 60 Hz, 1280 x 960 @ 60 Hz, 1024 x 768 @ 60 Hz, 800 x 600 @ 60 Hz,
640 x 480 @ 60 Hz
Input signal VGA, DVI-D (w/HDCP support)
User controls (on-screen Brightness, contrast, positioning, color temperature (6500k, 9300k, custom), individual color control, serial number,
display) display, clock, clock phase, monitor management, factory reset, zoom
Input power Auto-Sensing, (90 to 265 VAC)+/-10%, 45 +/-3 Hz to 63 +/-3 Hz
Power consumption Maximum: 20 watts; Typical: 18.4 watts ; Power saving: <1 watts standby; <.05 watts off
Dimensions (h × w × d) Unpacked w/stand: 37.0 x 44.6 x 20.6 cm (14.6 to 17.6 x 8.1in)
Unpacked w/o stand (head only): 30.1 x 44.6 x 5.9 cm (11.9x 17.6 x 2.3 in)
Weight Head Only: 8.8 lb (4.0 kg); Unpacked: 10.1lb (4.6 kg)
Base features Tilt range: -5° to + 25° vertical
Environmental Temperature-Operating: 41° to 95° F (5° to 35° C); Temperature-Non-operating: -4° to 140° F (-20° to 60° C)
Options (each sold HP LCD Speaker Bar Optional; powered directly by the connected PC, seamlessly attaches to the monitor's bezel to bring full
multimedia support to select HP LCD monitors; features dual speakers with full sound range and two external jacks for
separately)
headphones. Part number NQ576AA. For more information, refer to the product's Quick Specs.
HP Quick Release Optional; easy-to-use, VESA-compliant, LCD monitor mounting solution that allows quick and secure attachment
of an LCD monitor to a variety of stands, brackets, arms or wall mounts. Part number EM870AA. For more information, refer to
the product's QuickSpecs.
HP Integrated Work Center Stand Optional; Allows mounting of a 17-, 19-, or 22-inch diagonal HP LCD monitor and an HP
Compaq dc7800 or dc7900 Ultra-slim Desktop PC or HP t5000 series Thin Client on a single stand for the convenience of an
"all-in-one" form factor. Sold separately. For more information, refer to this product's QuickSpecs document. Part number
GN783AA.
HP USB Graphics Adapter Optional; enables connection of up to six simultaneous displays. Use one Adapter to bridge between a
notebook or desktop PC and second monitor or use multiple Adapters to connect several displays to each other. Part number
NL571AA.
HP Business PC Security Lock Kit Optional; Attaches to the rear of the PC with a six-foot steel cable that can be used to secure a
PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them against unauthorized removal by
physically connecting the system to an anchor point. Part number PV606AA.
Certification and TCO 5.0 Displays, ISO 9241-307, CISPR Requirements, VCCI Approvals, KC and KCC (Korean) Requirements, CSA
compliance 60950-1, UL 60950-1, EN55022 Class B, CNS 13438 Class B, IEC 60950-1, China Energy Label (CEL), China MEPS,
Korea MEPS (pending, Energy Boy), SmartWay – NA only - Energy logistics, EUP Lot 6 Tier 1 AS/NZS 3548 Class B
Approval, "GS" Mark, TUV Approvals, GEEA, CE Marking, FCC Part 15 class B Approval, ENERGY STAR
EN55024 Class B, EN60950 -1, CUL, CCIB, CCEE, IT ECO (EDS), EPEAT™
Limited warranty**** Protected by HP, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3) standard limited warranty.
Certain restrictions and exclusions apply.
*HP Compaq LE19f Widescreen LCD Monitor is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free); meeting the evolving definition of 'BFR/PVC-free' as set forth in the
"iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics (BFR/CFR/PVC-Free)". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and <
1000 ppm (0.1%) of chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. All printed circuit board (PCB) and substrate laminates contain bromine/chlorine total < 1500 ppm
(.15%) with maximum chlorine of 900 ppm (.09%) and maximum bromine being 900 ppm (.09%). Service parts after purchase may not be BFR/PVC-free. The power cord is not BFR/PVC
free in China and Korea. **All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or
lower. ***EPEAT Gold where HP registers commercial display products. See www.epeat.net for registration status in your country. ****HP Care Pack Services extend service contracts
beyond the standard warranties. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts from date of hardware purchase. To
choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is
available at www.hp.com/hps/carepack.
© 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in
the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein. Microsoft®, Windows® and Vista® are trademarks of the Microsoft® group of companies. ENERGY STAR
the US government. To learn more, visit www.hp.com
April 2010
