Table of Contents Pages 1. Introduction 2. Precautions 3. Compatibility Notes 4. Dipswitch Settings 5. Installation 6. iPod Operation 7. HD Radio Operation (if equipped) 8. Selecting AUX Input 9. Selecting Factory Satellite (if equipped) 10. Troubleshooting 11. Warranty Info...
Page 3
Media Gateway & Optional Add-ons Factory Radio Not Included Media Gateway Harness iPod Part #: PGHHD2C Not Included Media Gateway Part #: PXAMG Harness Connection Dip Switches Port 1 Port 2 (See Manual) 11Ft. iPod Cable 3Ft. HD Radio Cable (sold with HDRT) HD Radio Tuner...
1. Introduction ® Thank you for purchasing the iSimple Media Gateway. The Media Gateway is designed to provide endless hours of listening pleasure from your factory radio. To ensure that your iPod performs correctly with your radio, we recommend that you read this entire manual before attempting installation of the Media Gateway.
3. Compatibility Your vehicle MUST be equipped with XM Satellite Radio that has the XM Nav- Traffic feature. Please visit www.isimplesolutions.com for the most up to date application information and to verify your vehicle’s compatibility. 4. Dipswitch Settings Dipswitch 2 MUST be set in the ON (down) position for proper operation. ALL VEHICLES...
5. Installation 1. When making electrical connections it is always recommended that the vehicle’s battery be disconnected from the electrical system before performing the installation. 2. Carefully remove the trim panels in the passenger side of the trunk to access the XM Satellite Radio tuner.
6. iPod Operation Entering Mode Select Menu Press the “AM-FM” button then press the “XM or “AUX” button. Turn the rotary TUNE KNOB or press “TUNE ▲” until “IPOD” is displayed. The PXAMG will auto select the mode after 6 seconds of inactivity. Next Track Turn the rotary TUNE KNOB clockwise or press the “TUNE ▲”...
7. HD Radio Operation Entering Mode Select Menu Press the “AM-FM” button then press the “XM or “AUX” button. Turn the rotary TUNE KNOB or press “TUNE ▲” until “HD-FM” is displayed. The PXAMG will auto select the mode after seconds of inactivity. Tune Up Turn the rotary TUNE KNOB clockwise or press the “TUNE ▲”...
9. Selecting Factory Installed Sat (if equipped) Entering Mode Select Menu Press the “AM-FM” button then press the “XM or “AUX” button. Turn the rotary TUNE KNOB or press “TUNE ▲” until “SAT” is displayed. The PXAMG will auto select the mode after 6 seconds of inactivity.
10. Troubleshooting Symptom Cause Remedy Radio shows iPod iPod cable is not Verify the docking cable is connected not connected connected to iPod or to the Media Gateway, and the iPod Gateway. The iPod firmware Update iPod firmware for free at http:// I can not correctly www.apple.com/ipod/download control the iPod...
Within the first 12 months from date of purchase, subject to the conditions above, ® iSimple will repair or replace the product at their discretion, if it is defective in material ® or workmanship providing it is returned to an Authorized iSimple dealer, with PROOF OF PURCHASE from an authorized iSimple ® dealer.
Page 12
www.isimplesolutions.com For Best Performance Have It Professionally Installed.
