Hako Robotic Focus CLASSIC Parts Manual And Owners Manual

Scrubber / polisher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Focus CLASSIC
SCRUBBER / POLISHER
Parts Manual and Owners Guide
Hako Australia Pty Limited
ABN 43 002 858 059
6 Pike Street, Rydalmere NSW 2116 Australia
PO Box 360 Rydalmere BC 1701
Telephone: +61 2 9684 2433 Fax: +61 2 9684 2278
Freecall within Australia: 1800 257 221
Email:
hksales@hakoaustralia.com.au
www.hakoaustralia.com.au
An ideal cleaning
solution from
Hako Rotobic.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Focus CLASSIC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hako Robotic Focus CLASSIC

Summary of Contents for Hako Robotic Focus CLASSIC

  • Page 1 Focus CLASSIC SCRUBBER / POLISHER Parts Manual and Owners Guide Hako Australia Pty Limited An ideal cleaning ABN 43 002 858 059 6 Pike Street, Rydalmere NSW 2116 Australia solution from PO Box 360 Rydalmere BC 1701 Hako Rotobic. Telephone: +61 2 9684 2433 Fax: +61 2 9684 2278...

  • Page 2: Handle Assembly

    PACKAGING  The Focus & Focus Hi-Torque Classic models Handle Handle Handle Upright Handle Handle Upright Upright Upright Upright Upright are despatched in two cartons. The cartons Handle contain the handle and chassis assembly. 5” Bolt 5” bolt 5” bolt 5”...

  • Page 3: Handle Adjustment

    TANK CONNECTION (FOCUS SUDS models)  Lay handle to a horizontal position, and attach U Bolt and Keeper to tank ends as shown in Pic 5.  Add the screw thread protectors to U Bolt threads after tightening.  Attach Hose between Solenoid Valve as shown in Pic 6 and Tank Fitting refer to Pic 7.
  • Page 4 User Adjustment Not User Adjustment Not Required On This Joint Required On This Joint Pic 9 Factory Set Joint on Focus and Pic 10 Factory Set Joint on Focus Suds Focus Hi-Torque Classic Models Classic Models PAD AND BRUSH SIZE ...

  • Page 5: Motor Controls

    MOTOR CONTROLS SAFE USE  Ensure that this Manual has been read and Manual Reset Thermal understood by the operator. Over Load Switch.  This appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance.
  • Page 6 CONTROL  The machine is controlled by balance rather than strength. Tilt handle slightly upwards and the machine moves to the RIGHT, tilt the handle Tilt Up for slightly down the machine moves to the left. When RIGHT the handle is in the intermediate position the Movement machine remains stationary refer to Pic 18 and Pic 19.

  • Page 7: Power Cord Maintenance

    TRANSPORTATION  For transporting the machine on level surfaces adjust the handle in an upright position, and transport the machine on the back wheels refer to Pic 21.  When transporting the machine and stairs are encountered mechanical lifting aids should be used.
  • Page 8 HAZARD PRECAUTIONS Unplug electrical plug from the power point before conducting repair, service, maintenance or equipment cleaning. Electrical  Do not handle electrical plug or machine with wet hands and power connected.  Do not store machine outdoors or expose to rain. ...

  • Page 9: Specifications

    SPECIFICATIONS Main Motor Type: Induction 4 Pole CSCR Voltage and Frequency: 220 – 240 Volts a.c. / 50 – 60 Hz Power Output: 1500 watts @ 8.3 amps ® Transmission Type: double reduction timing belt. Output speed: Standard 430 rpm / Hi-Torque 215 rpm Noise Noise: 68dB...
  • Page 10 ELECTRICAL CIRCUIT DIAGRAM FOCUS SUDS MODELS...
  • Page 11 FOCUS Classic Chassis Assembly Parts List Part Name Part No. Part Name Part No. Chassis Focus Classic Assy 13227020 Belt 600-8m-21HP 13210003 Chassis Focus Hi-Torque Classic Assy 13227030 Screw M5 x 90 Socket Head Cap 13380046 Chassis Focus Suds Classic Assy...
  • Page 12 FOCUS Classic Chassis Assembly Diagram 1 19 Additional Components for FOCUS SUDS Model...
  • Page 13 FOCUS ndustrial & ommercial Handle Adjustment Bar Focus Suds Model Only Part Name Part No. Part Name Part No. Focus IC Handle 13277020 Bar Adjustment Focus Suds Classic 13210008 Focus Suds IC Handle 13277040 Bush Strain Relief Utilux H2097B 13210001 Handle Grip 13270005 Cord Handle Focus IC Assy...
  • Page 14 Hako Australia Pty Ltd Warranty Policy Effective July 1, 2008 Hako Australia Made Simple Limited Warrantly Policy Hako Australia Pty Ltd warrants to the original purchaser/user that the product is free from defects in workmanship and materials under normal use. Hako Australia Pty Ltd will, oblige under this warranty to repair or replace at our factory or authorised dealer service outlet, parts that fail under normal use and service when operated and maintained in accordance with the Parts Manual and Owners Guide, after examination discloses it to have been defective.
