LENCO IPD-4100/2 Series User Manual

LENCO IPD-4100/2 Series User Manual

Ipod speaker dock with fm radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
IPD-4100/2 Series iPod Speaker Dock with FM radio
User Guide
For information and support,
www.lenco.eu
IMPORTANT: Please read all instructions carefully before use and keep for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPD-4100/2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LENCO IPD-4100/2 Series

Summary of Contents for LENCO IPD-4100/2 Series

  • Page 1 English IPD-4100/2 Series iPod Speaker Dock with FM radio User Guide For information and support, www.lenco.eu IMPORTANT: Please read all instructions carefully before use and keep for future reference...

  • Page 2: Safety Is Important

    Thank you for choosing this Lenco iPod Speaker Dock with FM Radio. Not only can it receive radio stations, but you can also listen to your favourite tracks on your iPod and charge it up. It’s really simple to use; you can fully operate your iPod from the control panel on the top or from the remote control, and even connect another auxiliary device to it.
  • Page 3 Power Adapter...
  • Page 4 POWER MEMORY CARD DOWN TUNE ARRO ARROW/RWD SLEEP/CLOCK ALARM MODE...
  • Page 5 MEMORY BATTERY SPEAKER Port Compartment IPD-4100/2 FM: 87.5MHz - 108MHz INPUT: DC 15V 2.0A IMPEDANCE: 4channel OUTPUT POWER:10W * 2+20W MAX. POWER CONSUMPTION: 40W PRODUCTION DATE: ,20 April 10 M A D E I N C H I N A MEMORY BATTERY DC IN AUX R...

  • Page 6: Using The Remote Control

    1.Setting up the iPod Speaker Dock Insert the Mains Plug into a suitable wall socket and turn the socket on. Press the STANDBY button to turn the Speaker Dock on. 2.Using the Remote Control The Remote Control can be used to operate the Speaker Dock. Before using the Remote Control, the Safety Tab should be removed.

  • Page 7: Ipod Docking

    desired buttons. DON’T FORGET! When replacing the battery make sure that you use the same size and type. 3. iPod Docking Any iPod can be connected to the Speaker Dock to allow all your songs to be played through the speakers. To connect an iPod to the Speaker Dock, select the compatible adaptor from one of the 7 iPod Adaptors supplied.

  • Page 8: Connecting To External Devices

    and then insert your iPod into the Adaptor. DON’T FORGET! Your iPod will charge while docked when the Speaker Dock is in Standby mode. Press the STANDBY button. Press the MODE button repeatedly until iPod is displayed on the LCD Display. To start playback, press the PLAY/PAUSE button.

  • Page 9: Memory Cards

    • Jazz • Pop • Rock • Classic • Bass 1.Press the EQ button to select the setting which sounds best. Modes The iPod Speaker Dock has three modes of operation. These are: • iPod • Tuner • Aux Brightness 1.Press the BRIGHTNESS button on the remote control repeatedly to cycle through the 4 display brightness settings.

  • Page 10: Menu Navigation

    Menu Navigation You can access the menu system of your iPod using the Remote Control. 1.To access the iPod menu system, press the MENU button. 2.Use the UP and DOWN ARROW buttons to highlight the menu options. 3.Use the OK button to select a menu option. Radio Tuning to a radio station 1.Press the STANDBY button.
  • Page 11 DON’T FORGET! You may need to reposition the Speaker Dock to get the best reception. Storing a radio station using the remote control 1.Tune to a radio station as described above. 2.Press the MEM button. MEM and a number will be shown on the LCD Display. 3.Press the UP or DOWN ARROW buttons to select the number you want to store the radio station against.
  • Page 12 Speaker Dock. 3.Insert a button cell (type CR2032), ensuring the correct polarity is observed. 4.Close the Memory Battery Compartment. Setting the clock 1.Make sure the Speaker Dock is powered on before setting the clock. 2.Press and hold the SLEEP/CLOCK button. SET will be shown in the LCD Display next to the clock time.
  • Page 13 The Speaker Dock can be reset to return to the factory default settings. 1.Switch off the Speaker Dock and remove the plug from the wall socket. 2.To reset the Speaker Dock, remove the Backup Battery from the Memory Battery Compartment as described in the previous sections.
  • Page 14 Problem Possible Cause What to do Radio sound distorted. 1.The station is not tuned in. 1.Fine tune the station. 2.There is a poor signal in the 2.Reposition Speaker area. Dock. No radio sound. 1.The Speaker Dock is not in 1.Press the MODE button until tuner mode.

  • Page 15: Sound Levels

    Sound levels Your hearing is very important to you and to us, so please take care when using this Speaker Dock. It is strongly recommended that you follow the listed guidelines in order to prevent possible damage or loss of hearing. Establish a safe sound level Over time your hearing will adapt to continuous loud sounds and will give the impression that the volume has in fact been reduced.

  • Page 16: Electrical Information

    Electrical Information This Speaker Dock is fitted with a BS1363/A 13 amp plug. If it is not suitable for your supply sockets it must be removed and replaced with an appropriate plug. If the plug becomes damaged and/or needs to be replaced please follow the wiring instructions below. The plug removed must be disposed of immediately.
  • Page 17 • The guarantee is in addition to, and does not diminish, your statutory or legal rights.
