  • Page 1 PT1710MX Touchscreen LCD Monitors USER’S GUIDE www.planar.com...
  • Page 3 Important Recycle Instructions: Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG.

  • Page 5: Table Of Contents

    Table of Contents Usage Notice Precautions ..................2 Introduction About Planar’s PT1710MX..............3 Touch Screen for PT1710MX……………………………………………..4 Package Overview ................5 Installation Product Overview ................6 VESA Mount for your Monitor…………………………………………….9 Start Your Installation…………………………………………………….10 Connecting the Display………………………………..…………………11 User Controls Front Panel Controls ................

  • Page 6: Usage Notice

    Usage Notice - To prevent the risk of fire or shock hazards, do not Warning expose this product to rain or moisture. - Please do not open or disassemble the product as Warning this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.

  • Page 7: Introduction

    Introduction About Planar’s PT1710MX The PT1710MX is a 17” flat panel screen with an active matrix, thin-film transistor (TFT) liquid crystal display (LCD). Features include: Direct Analog signal input Active matrix TFT LCD technology 1280x1024 SXGA resolution 17” viewable display area 31.5 ~ 80 kHz horizontal scan...

  • Page 8: Touch Screen For Pt1710Mx

    Touch Screen for PT1710MX Analog 5-wire resistive touch screen for finger and stylus input Surface: Anti-glare treatment Interface: Dual RS-232 Serial/USB controller Durability: 35 million touches at a single point Hardness of surface: 2H MIN (As provided in JIS K5400) Operating force: 0.10~1.96N(10g~200g when using a silicon tipped pen...

  • Page 9: Package Overview

    Package Overview LCD Display Power Adapter Power Cord VGA Signal Cable Audio-in Cable USB Cable RS-232 Cable Landing Strip Touchscreen Driver Installation CD-ROM User’s Guide...

  • Page 10: Installation

    Installation Product Overview Front View Back View...
  • Page 11 Connector Ports “A” RS-232 Audio input input Power-in input Connector Ports “B”...
  • Page 12 Kensington Security Slot The monitor can be secured to your desk or any other fixed object with Kensington lock security products. The Kensington lock is not included.

  • Page 13: Vesa Mount For Your Monitor

    VESA Mount Your Monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface Standard which defines a physical mounting interface for flat panel monitors, and corresponding standards for flat panel monitor mounting devices, such as wall and table arms. The VESA mounting interface is located on the back of your monitor.

  • Page 14: Start Your Installation

    Start Your Installation Remove the Back Cover Please follow these instructions to remove the cover on the back panel of the LCD so that you can connect the cables in “Connector Ports A.” 1. To remove the back cover, follow the arrows in Figure A and press with both your thumbs.

  • Page 15: Connecting The Display

    Connecting the Display (Figure 11.1) To setup this display, please refer to the following figure and procedures. 1. Be sure all equipment is turned off. 2. Connect the DC power cord to the power connector on the monitor; plug one end of the AC power cord into the power adapter, and the other end into an electrical outlet (11.1 ).
  • Page 16 Figure 11.1...

  • Page 17: User Controls

    User Controls Front Panel Controls Control Function No / Icon MENU Menu button Display the OSD menus Select – To select the adjustment items from OSD menus. SELECT/AUTO Select/Auto Auto – To activate the “Auto Adjustment” function to obtain an optimum image. 1.

  • Page 18: How To Use The Osd Menus

    How to Use the OSD Menus Press the "MENU" button to pop up the “on-screen menu” and to select among the four Main Menus. 2. Choose the adjustment items by pressing the “Select/Auto” button. 3. Adjust the value of the adjustment items by pressing the “ ”or “ “ button. 4.

  • Page 19: On-Screen Display Menus

    On-Screen Display Menus Main OSD Menu: MAIN MENU SUB MENU Function Description Remark Auto-Adjustment Choose this function to obtain an optimum No/Yes image. Contrast Adjust the contrast of the display image. Default 50 0-100 Brightness Adjusts the brightness of the image. Default 70 0-100 Horizontal Position...

  • Page 20: Appendix

    Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Check that all the I/O and power connectors are correctly and well connected as described in the “Installation”...

  • Page 21: Warning Signal

    LCD display cannot receive a clean signal from the computer graphics card. There may be two sources for this problem. Please check the cable connections or contact Planar for more information. No Signal This message means that the LCD Display has been powered on but it cannot receive any signal from the computer graphics card.

  • Page 22: Product Dimensions

    Product Dimensions...

  • Page 23: Compatibility Modes

    Compatibility Modes V. Frequency H. Frequency Mode Resolution (Hz) (kHz) IBM VGA 640 x 350 31.5 720 x 400 IBM VGA 31.5 640 x 480 IBM VGA 31.5 VESA VGA 640 x 480 37.9 VESA VGA 640 x 480 37.5 VESA SVGA 800 x 600 35.2...

  • Page 24: Touch Screen Driver Installation

    Touch Screen Driver Installation The PT1710MX is available with both RS-232 and USB connections. The PT1710MX is Microsoft® Windows® HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required for general operation of the touch screen. A calibration tool can be installed for improved touch position accuracy.
  • Page 25 PT1710MX Optional Resistive Calibration Tool Install: If you would like to use the Optional Resistive Calibration Tool, follow the instructions below: 1. Open the CD-Rom. 2. Select the Monitor Size and then Model Name 3. Click on the “Load Utility” button that appears to the right of the Model Name.
  • Page 26 ® If you are using a PC running Windows Vista, XP or 2000 operating system, follow the instructions below. Using the RS232 connection: 1. Be sure that RS232 cable is connected from the computer. 2. Power on the computer. 3. Load the touch screen driver CD. 4.

  • Page 27: Product Registration And Technical Support

    Product Registration and Technical Support Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefits of your Planar product and services, register your Planar product today. Visit our website at http://www.planar.com/support/product_registration.html. Cables, Replacement Lamps, Accessories...
  • Page 29 PT1710MX www.planar.com...
  • Page 30 Windows Microsoft, Inc. WWW.EIAE.ORG WWW.LAMPRECYCLE.ORG...
  • Page 31 使 用 须 知 使 用 须 知 使 用 须 知 使 用 须 知 ................2 介 绍 介 绍 介 绍 介 绍 Planar PT1710MX ............... 3 PT1710MX ..............4 ..................5 安 装 安 装 安 装 安 装...
  • Page 32 ..................18 ................. 19 ..............20 ..............23...
  • Page 33 使用须知 警 告 警 告 警 告 警 告 警 告 警 告 警 告 警 告 应 做 ： 应 做 ： 应 做 ： 应 做 ： 50/50 禁 止 禁 止 禁 止 禁 止 ： ： ： ：...

  • Page 35: Planar Pt1710Mx

    介绍 Planar PT1710MX PT1710MX 17” TFT LCD 1280x1024 SXGA 17” 31.5 80 kHz 56 75 Hz 0.264mm x 0.264mm VESA DPMS Kensington 100 mm VESA...
  • Page 36 RS-232 /USB –1W/...

  • Page 37: Pt1710Mx

    PT1710MX RS-232 /USB 3500 2H MIN JIS K5400 0.10 1.96N 3 mm 200g Windows® VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded, Linux, Apple® Mac OS...
  • Page 38 RS-232...
  • Page 39 安装...
  • Page 41 RS-232 输 入 输 入 电 源 输 入 输 入...
  • Page 42 防 盗 锁 槽 防 盗 锁 槽 防 盗 锁 槽 防 盗 锁 槽 Kensington Kensington Kensington 防 盗 锁 槽 防 盗 锁 槽 防 盗 锁 槽 防 盗 锁 槽 K e n K e n s i s i s i s i n g n g n g n g t t t t o n o n o n o n K e n K e n...

  • Page 43: Vesa

    VESA VESA VESA 插 槽 警 告 警 告 警 告 警 告 ！ ！ ！ ！...
  • Page 44 8 mm 8 mm M4...
  • Page 45 “ A” 11.1 理 线 槽...
  • Page 47 1 1.1 连 接 显 示 器 连 接 显 示 器 （ （ （ （ 图 图 图 图 连 接 显 示 器 连 接 显 示 器 ） ） ） ） 11.1 (11.1 ) (11.1 ) 1280 x 1024 “...
  • Page 48 11.1 音 频 输 入 线 U S B V G A R S - 2 2...
  • Page 49 用户控制 编 号 编 号 编 号 编 号 图 标 图 标 图 标 图 标 控 制 控 制 控 制 控 制 功 能 功 能 功 能 功 能 MENU — SELECT/AUTO “ — ”...

  • Page 51: Osd

    MENU on-screen menu Select/Auto 请 注 意 请 注 意 请 注 意 请 注 意 ： ： ： ： “-” “Menu” OSD Locked 请 注 意 请 注 意 ： ： ： ： 请 注 意 请 注 意 “-”...
  • Page 52 屏幕显示菜单 屏幕显示菜单 屏幕显示菜单 屏幕显示菜单 O SD 主 主 主 主 菜 单 ： 菜 单 ： 菜 单 ： 菜 单 ： 主 菜 单 主 菜 单 子 菜 单 子 菜 单 M ENU 功 能 说 明 功...
  • Page 53 Color Setting 9300K/ 6500K/ Color adjustment-Red 0-100 Color adjustment-Green 0-100 Color Adjustment-Blue 0-100...
  • Page 54 附录 如 果 液 晶 显 示 器 出 现 故 障 ， 请 查 阅 以 下 内 容 。 如 果 问 题 仍 未 解 决 ， 请 联 系 当 地 经 销 商 或 我 们 的 服 务 中 心 。 问...

  • Page 55: Clock Phase

    问 题 问 题 问 题 问 题 ： ： ： ： 图 像 图 像 图 像 图 像 （ （ （ （ 字 符 和 图 形 字 符 和 图 形 字 符 和 图 形 ） ） ） ） 不 清 楚 字...
  • Page 56 Planar No Signal （ 无 信 号 ） （ 无 信 号 ） （ 无 信 号 ） （ 无 信 号 ） Out of Range （ 超 出 范 围 ） （ 超 出 范 围 ） （ 超 出 范 围 ）...
  • Page 58 垂 直 频 率 垂 直 频 率 垂 直 频 率 垂 直 频 率 水 平 频 率 水 平 频 率 水 平 频 率 水 平 频 率 模 式 模 式 模 式 模 式 分...
  • Page 59 PT1710MX RS-232 USB PT1710MX Microsoft Windows HID Windows® VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded, Linux, Apple® Mac OS RS232 USB 驱 动 程 序 安 装 过 程 ： 驱 动 程 序 安 装 过 程 ：...
  • Page 60 ” Finish...
  • Page 61 ®...
  • Page 62 ® ®...
  • Page 63 立即注册您的 立即注册您的 立即注册您的 立即注册您的 Planar 产品 产品 产品 产品 Planar Planar Planar http://www.planar.com/support/product_registration.html. 缆线、备用灯及其他附件 缆线、备用灯及其他附件 缆线、备用灯及其他附件 缆线、备用灯及其他附件 Planar Planar www.PlanarOnline.com http://www.planar.com/howtobuy Planar 技术支持 技术支持 技术支持 技术支持 Planar http://www.planar.com/support Planar 12am Planar Planar : 1-866-PLANAR1 (866-752-6271) +1 503-748-5799 24 7...
  • Page 64 产 产 产 产 品中有毒有害物 品中有毒有害物质 质 质 质 或元素的名称及含量 或元素的名称及含量 品中有毒有害物 品中有毒有害物 或元素的名称及含量 或元素的名称及含量 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) SJ/T 11363-2006 SJ/T 11363-2006 (EPUP) EPUP...
  • Page 66 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2009 Planar Systems, Inc. 4/09 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners.
