Sears C970-5526 Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Sears Manuals
  4. Ranges
  5. C970-5526
  6. Factory parts catalog

Sears C970-5526 Factory Parts Catalog

30-inch freestanding electric range
Hide thumbs

Advertisement

Quick Links

Download this manual
ELEMENT ON
ELEMENT ON
O
O
O
O
Cook Time
LO
HI
LO
HI
Temps de
Bake
Broil
LO
HI
LO
HI
Cuisson
Cuire
Griller
1
9
1
9
1
9
1
9
Oven
2
2
Four
2
2
8
8
Timer
Delay Start
Preheat
8
8
Minuterie
Départ
Préchauffage
STOP
Warm &
Hold
3
7
3
7
On/Off
Différé
ARRÊT
Garder
Chaud
3
7
3
7
4
6
4
6
Controls Lock
4
6
4
6
5
5
3
Verrou Contrôles
5
5
"
C970-5524.eps CC970-552621.eps BC970-552622.eps TC970-512121.eps DC970-
552221.eps
318046767-1.eps 318046767-2.eps
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4
Product No.
C970-552622
307053A5D7112
Series
30" f/s elec
Color
white
Market
Canada
Wiring Diagram 318046767
Owner's Guide 318200444
Timer Guide
318200182
STANDING ELECTRIC
Publication No.
5995512810
08/04/29
(EN/SERVICE/ECL)
377
Copyright
SEARS CANADA
30-INCH FREE-
RANGE
Model No.
C970-5526
©
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the C970-5526 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sears C970-5526

Summary of Contents for Sears C970-5526

  • Page 1 SEARS CANADA ELEMENT ON ELEMENT ON Cook Time Temps de Bake Broil Cuisson Cuire Griller Oven Four Timer Delay Start Preheat Minuterie Départ Préchauffage STOP Warm & Hold On/Off Différé ARRÊT Garder Chaud Controls Lock Verrou Contrôles ” Product No.
  • Page 2 Publication No: 5995512810 C970-552622 BACKGUARD 04/08...
  • Page 3 C970-552622 Publication No: 5995512810 BACKGUARD POS. NO PART NO. DESCRIPTION 318314100 Panel, cover, upper 318288215 Shield, inner 5304448825 Lamp, fluorescent, backguard 318323401 Receptacle, lamp, RH/LH 318288000 Housing, light 5304448826 Starter, lamp 318110400 Receptacle, starter 10 # 318122805 Ballast, lamp 316022500 Light/Lamp, indicator, 125 V 318287902 End Cap, backsplash, white, RH...
  • Page 4 Publication No: 5995512810 C970-552622 BODY 04/08...
  • Page 5 C970-552622 Publication No: 5995512810 BODY POS. NO PART NO. DESCRIPTION 318259220 Back, main 318299801 Panel, body side, white, (2) 318313101 Cover, insualtion 318175503 Screw, leveling 318262504 Rack, oven 318262001 Cover, element 318318600 Bracket, element, hidden bake 316081900 Pan, broilerOPTIONAL ACCESS0RY 316082000 Insert, broiler panOPTIONAL ACCESS0RY 318224000...
  • Page 6 Publication No: 5995512810 C970-552622 TOP/DRAWER 04/08...
  • Page 7 C970-552622 Publication No: 5995512810 TOP/DRAWER POS. NO PART NO. DESCRIPTION 318107105 Drawer 318303024 Panel, drawer, white, front 318332200 Roller, nylon 318311502 Bracket, Drawer Panel, (2) 318018100 Channel, drawer, RH 318018101 Channel, drawer, LH 15 # 318372206 Element, surface, 8", large 15A# 318372201 Element, surface, 6", small...
  • Page 8 Publication No: 5995512810 C970-552622 DOOR 04/08...
  • Page 9 C970-552622 Publication No: 5995512810 DOOR POS. NO PART NO. DESCRIPTION 318301401 Trim, oven door, white 318304104 Door Assembly, glass, white, w/trim 316117500 Glass, oven door, heat barrier 318259603 Liner, door, lower 5304453593 Screw, handle mtg. 318053325 Seal, door, lower oven 318300513 Bracket, glass 318300611...

  • Page 10: Wiring Diagram

    Publication No: 5995512810 C970-552622 WIRING DIAGRAM 04/08...
  • Page 11 C970-552622 Publication No: 5995512810 WIRING DIAGRAM 04/08 # Functional Parts * Non-Illustrated Parts...

This manual is also suitable for:

C970-552622
