American Standard Florwell 7741.000 Specification Sheet

FLORWELL™ SERVICE SINK
• Enameled cast iron
• 3" outlet
• Corner model
❏ 7741.000 Fixture only - Less rim guard
❏ 7745.811 Removable vinyl rim guard
Nominal Dimensions:
711 x 711 x 330mm
(28" x 28" x 13")
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ASME A112.19.1 for Cast Iron Plumbing Fixtures
To Be Specified:
❏ Faucet: 8344.112 faucet with top brace,
stops, and vacuum breaker
❏ Alternative Faucet:
❏ Drain: 7721.038 flat grid drain
❏ Removable vinyl-coated rim guard:
7745.811 (black)
© 2008 AS America Inc.
13
(330mm)
13
(330mm)
3/4
(19mm)
FINISHED WALL
28
(711mm)
PLAN VIEW
(1219mm)
NOTES:
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
IMPORTANT: Dimensions of fixtures are nominal and may vary within
the range of tolerances established by ANSI Standard A112.19.2. These
measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
M34
FLORWELL™
SERVICE SINK
ENAMELED CAST IRON
3/4
(19mm)
FINISHED WALL
28
(711mm)
NOTE: SUPPLY FITTING CAN BE
PLACE ON EITHER WALL
C/L OF
SPOUT BRACE
8
(229mm)
(203mm)
1/2 NPT
SUPPLIES
FINISHED WALL
48
12-1/4
(311mm)
5
(127mm)
13
(330mm)
8
(203mm)
ROUGH
2
FLOOR
(51mm)
3 N.P.T. INSIDE THDS
Revised 8/05
9
3/4
(19mm)
1 x 3
(25 x 76mm)
SUPPORTING
CLEAT ON
BOTH WALLS
1/4 (6mm)
