  • Page 1 R45of Re:control M 217 Wall Display Unit Dominating Entertainment. Revox of Switzerland...
  • Page 2 Walldisplay 217 Re:control...

  • Page 3: Table Of Contents

    Walldisplay 217 Re:control Contents Walldisplay 217 General & Insatllation advice Savety Guidelines Feller EDIZIOdue 4217.M Advice & Installing Connection plan 4217.M GIRA JUNG Merten M217 Advice & Installing Available Designs Connection plan M217 Installation Connection plan display/ keypad Configuration M217 IR receiver on/off Adressing 217 A/B operation Adress settings...

  • Page 4: Walldisplay 217

    Tuner, CD. The basic operations such as CD, Tuner, Track+-, Volume, etc. are carried out using a connected keypad or through a Revox IR Multiroom Planner remote control. The Timer menu organises timed complete addressing processes...
  • Page 5 Walldisplay 217 Re:control Safety Guidelines Installation An incorrect installation of this Installation of the wall display device in an environment with in combination with a low low voltage devices (230V) can voltage device (power cause serious health issues and/ connection) should only be or material damage.

  • Page 6: Feller Ediziodue 4217.M

    Multiroom system. All the colours switched on (IR on). from the EDIZIOdue series are available. Revox recommends the use of ITPlus® RJ45 sockets for the interface to theM51 main system and/ or the M219 additional room amplifier. Single socket = 1198- 118.XXX.ITS;...

  • Page 7: Installation Procedure

    Re:control Installation procedure should avoid applying any pressure to the display during or after installation. Connect the terminal block Install the mounting fixture with the print connector on (5) with the fixing plate (4) the back of the operator onto the recessed box or the panel (1).

  • Page 8: Connection Plan 4217.M

    Setup and operation Technical data Build-in depth 20 mm The wall display must be Protection IP20 in accordance connected to the M51 Revox with IEC529; source management or a Revox Dry installation M219 Additional room amplifier for setup. Temperatures Operation: -5°C to +45°C...

  • Page 9: Available Designs

    GIRA GIRA Event GIRA Esprit Colours: All colours Revox offers the M217 for the JUNG CD 500 / universal Central European market in JUNG CD plus different designs from the Gira, JUNG LS990 / LS plus Jung and Merten companies. You...
  • Page 10 M217 Re:control Installation procedure Locate the operator panel (1) Screw the mounting fixture with its frame (3) onto the (4) onto the recessed or mounting fixture (4), so that the surface mounted box. clip connectors (2) on the panel (1) line up with the cut-out (5) in Strip the insulation off the the mounting fixture (4).

  • Page 11: Connection Plan M217

    1: IR off in the Revox manuals. Your 2: AB operation off contact point for further questions 3: Address off is your nearest Revox dealer or 4: Address off Revox GmbH, tel: +49 (0)7721- 8704-0, www.revox.de.
  • Page 12 M217 Display unit Re:control Cabling the display to the wall-mounted keypad The cabling for the combination The connection is made of the 217 display and the 218 according to the Chapters A keypad should be done as and B in the Installation manual. shown in the drawing.

  • Page 13: A/B Operation

    M217 Display unit Re:control M217 Configuration Important The basic settings for the M217 The addressing of the M217 are made with the four DIL and the M219 must be setup switches on the back of the unit. correctly to ensure error free Use a small screwdriver or the operation.
  • Page 14 Re:control M217 Address setting Use the free-of-charge Multiroom Planner software from Revox for the addressing. You will find more about this on Page 1 or under www.revox.de. Connection to the M51 If the M217 is connected directly to the M51 the address setting is not significant.
  • Page 15 Re:control A/B Operation: 2 displays control one Additional room amplifier The Multiroom system from Revox allows one M219 to be controlled by two 217s, the so-called A/B operation. In this way, for example, an 217 could be installed on each side of the bed.
  • Page 16 M217 Display unit Re:control M217 Address setting 8 x M219 - 0 x M217 The following 7 layouts show the possible combinations of the M217 with the M219 Additional room amplifier in one zone. The combination can be different in each zone. The address and the correct DIL switch settings for that address are always shown next...
  • Page 17 M217 Display unit Re:control 7 x M219 - 1 x M217 6 x M219 - 2 x M217...
  • Page 18 M217 Display unit Re:control 5 x M219 - 3 x M217 4 x M219 - 4 x M217...
  • Page 19 M217 Display unit Re:control 4 x M219 - 2+2 x M217 4 x M219 - 2+1+1 x M217...

  • Page 20: M217 Menu Control

    Multiroom system. Setting the display contrast The contrast of the display is adjusted by Revox to an optimal reading angle. Depending upon installation position it can occur however that a stronger or weaker contrast attitude supplies the better reading off result.
  • Page 21 M217 Display unit Re:control Possible displays USIC MENU The Music menu shows you all Tuner with the important information in the display of 217 display in a clear way. the station The menu is controlled either name through a connected 218 wall- mounted remote control or through an IR remote.

  • Page 22: Timer Menu

    M217 Display unit Re:control Timer programming IMER MENU The concept of the timer The Timer is the control centre programming is as follows: of the Multiroom system. Using the Timer, you can set a Firstly, you select one of the wakeup alarm for specific days four Timers and then assign it or lull yourself off to sleep with...
  • Page 23 M217 Display unit Re:control Timer selection The Select options Timer Select The properties of the individual Timers can be set with the Select softkey: Switching time Weekday Volume Select timer source Timer 1 has been selected in (Select tuner station) the above example.
  • Page 24 M217 Display unit Re:control Switching times Only switch on or off Select Sometimes, it is useful just to switch the music equipment on Once you have selected a at a specific time and switch it Timer, you can define the off manually, or vice-versa.
  • Page 25 M217 Display unit Re:control Weekday Select Once you have defined the switch-on and switch-off timepoints, by pressing the Select key again, you can reach the next stage where you define the weekdays when the timer is to be activated MTWTF MTWTFS MTWTFSS As well as the individual days...
  • Page 26 M217 Display unit Re:control Select timer source Volume Select Select After selecting the weekday(s), The Multiroom module timer the next time you press Select, offers your three sources that you will be prompted to set the can be activated when the timer volume level that should be kicks in.
  • Page 27 M217 Display unit Re:control Select Tuner station Select Assuming that you have selected Tuner as your source, a further press of Select will bring you to the point where you can select the station you want to listen to. If you have selected DVD/CD or Aux/Server on the other hand, you will return to the Switching times selection level...
  • Page 28 M217 Display unit Re:control Activate Timer Timer status & time display As default, the individual If one or more Timers are Timers are deactivated. activated, two bell symbols are As soon as the switching times displayed when the M217 is in of a Timer are modified, the standby mode.

  • Page 29: 18-C

    M217 Display unit Re:control Nested events Sleep function Sleep Through the Timer Using the Sleep function, you programming, you can create can define a length of time after nested events. Nested events which the M51 or the M219 will occur when two different events automatically switch off.
  • Page 30 M217 Display unit Re:control Server-Menu USIK ERVER You can make your own Select a new music program personal music selections from with the Menu softkey on the each Additional room with the 217. 217. The following display appears: Menu call Make your music selection using the following criteria:...

  • Page 31: 20-C

    M217 Display unit Re:control ABC... Album Albums or artists are shown in The Album selection allows you alphabetical order with the to choose a specific album from ABC… selection. the Music server database. This function is especially useful if you have several hundred In opposite to selection ABC…...
  • Page 32 M217 Display unit Re:control Artist Using the two ▼▲ softkeys, Using the menu point Artist, you can now scroll through the you can carry out a search of alphabetical listing of the artists. the database for a specific Once you have chosen an artist’s name, which includes artist, using the Shuffle key, the names of all singers, bands,...
  • Page 33 M217 Display unit Re:control Genre Using the two ▼▲ softkeys, As well as storing the CDs in you can now scroll through the the database by the name of alphabetical listing of the the artists and the name of the genres, as shown below: albums, they are also grouped together under different types of...
  • Page 34 M217 Display unit Re:control Playlist Selecting a Playlist Once Playlist has been With the Playlist selection, you selected, all the defined can choose tracks that you Playlists are shown in have already put together alphabetical order, e.g.: yourself into so called Playlists. The advantage of Playlists is that you can create your own music collections to suit a...
  • Page 35 M217 Display unit Re:control [Track] Singe track shift Jump to track With the two softkeys you can As well as the 4 selection shift to the previous or the next criteria shown on the 217 menu track, while the music is playing. page, there is also the function Track, which allows you to jump to a specific track within the...

  • Page 36: Repeat

    M217 Display unit Re:control [Repeat] [Shuffle] Using the Shuffle softkey, you If you want to keep repeating a can start a random-ordered selected album, you should replay of tracks. press the Repeat softkey. If the Shuffle function is If the Repeat function is activated, (S) appears in the top activated, (R) appears in the top line of the display.

  • Page 37: Care

    Disposal Revox products should be disposed of or recycled in compliance with local regulations governing the disposal and/ or recycling of...

  • Page 38: Technical Data

    M217 Display unit Re:control Technical data Connections VCC: + 8 to 20 V A: Bus-communication B: Bus-communication GND: Ground / screening Max. cable lengths: 100m (M217 - M51 and/or M219 ) 30 m (M217 - M218 Wall-mounted remote control) Power consumption: at the M51: 30 - 50 mA (off –max. brightness) at the M219: 50 - 100 mA (off –max.
