  • Page 1: System Remote

    Re:control M208 System Remote Control Dominating Entertainment. Revox of Switzerland. Version 1...

  • Page 2: Table Of Contents

    M208 General Remote control MMC card M208 Link Synchronisation Operation M208 Base settings TUNER Synchronising tuner stations Operation SERVER Synchronising the music server Operation Music selection Repeat Shuffle M37 - Original G VIDEO AUDIO LIGHT SOUND Appendix Troubleshooting Technical data...

  • Page 3: Chapter Structure

    Chapter structure The M208 Operation manual is designed in a modular way in the same as the M51. New functions can be added to the M208 through the software update option. The new functions are described in the following chapters, which...
  • Page 4 M208 Batteries Because the M208 uses the latest processor technology with very low current requirements, you will not have to change the batteries very often. In the following chapters, you will find out how your settings affect the current consumption and therefore the working life of the batteries.

  • Page 5: Remote Control

    M208 Remote control Base settings Individual softkeys Device selection buttons Sound settings Volume control Mute Call menu Menu navigation Exit menu Play Stop Skip next / back Number pad for direct access Cover for USB / M-Link socket and MMC Memory card...
  • Page 6 MMC card by the M208. For this reason, the M208 only operates when the MMC card is inserted. If there is no MMC card in the M208 or if the card is incorrectly inserted, the following message appears on the display: Check the MMC card.

  • Page 7: M208 Link A

    M208 Link. Access to the M208 Link is underneath the hinged cover on the lower front end of the M208, in the form of a USB mini socket. The required USB cable is supplied with the M208.

  • Page 8: Usb Cable

    M51 through a cable to the M Link. Once the connection is established, select the source that is to be synchronised at the M208 and press the SETUP button. Switch on the M51 and confirm Synchronize setting with the OK button.

  • Page 9: Operation A

    M208 Operation Basic settings The Setup menu where you can make the basic settings appears automatically after you insert the batteries. In normal operation, you get to the Setup Menu with the Setup button. The most important settings are made in this menu. Each setting is...
  • Page 10 [Timeout] The M208 has an automatic switch-off feature that extends the working life of the batteries. The M208 is switched on using an integrated movement sensor, which recognises each movement of the remote control and returns it to the operating mode that was active before the automatic switch- off.
  • Page 11 M208 Font size [Font Size] The M208 gives you the option to modify the font size for the TUNER and the SERVER. The two displays below show the SERVER Menu in small and large font sizes.: Setting: Small Setting: Large The font size setting has no effect on any other devices.

  • Page 12: Information [Information]

    M208 Infrared power [IR-Power] The M208 can send the IR commands with two different power levels. This offers you particular advantages if you frequently want to control devices over longer distances or if you have a device that doesn’t react very sensitively to IR commands.

  • Page 13: Battery Display

    The IR symbol appears in the upper display fields each time the M208 sends an infrared command. Link If you connect the M208 to the M51 using the M208 Link interface to synchronise the Server database for example, the Link symbol appears.

  • Page 15: Btunerb

    SETUP button. Confirm the Synchronize setting with the OK button. Important advice Neither the M51 nor the M208 can be operated while the synchronisation is running. Synchronisation now starts and takes a few seconds. When the synchronisation is complete, the...

  • Page 16: Operation B

    M208 Operation Base settings Switch Tuner on Sound settings Volume control Mute Jump to start Previous page Jump to end Number pad for direct access SETUP TUNER SERVER VIDEO AUDIO LIGHT SOUND VOL + CH + MUTE- VOL - CH -...
  • Page 17 A and A A buttons or you can enter the station memory number directly through the numeric keypad. The M208 display is not updated. It continues to show the station that was selected last through the navigations compass.
  • Page 19 M208 Base settings Change soundtrack Subtitles Switch CD/DVD on Sound settings Volume control Mute Call the menu Menu navigation Exit menu Play Stop Skip next / back Number pad for direct access SETUP TUNER SERVER VIDEO AUDIO LIGHT SOUND VOL +...
  • Page 20 M208 Re:control M208 Re:source M51 DVD Softkeys Page 1 Change soundtrack Change viewing angle Select/ modify subtitles Call DVD Setup Menu...
  • Page 21 M208 Base settings Individual softkeys Sound settings Volume control Mute Call the menu Menu navigation Number pad for direct access SETUP TUNER SERVER VIDEO AUDIO LIGHT SOUND VOL + CH + MUTE- VOL - CH - MENU MORE EXIT ENTER...
  • Page 22 M208 M208 Re:ception plasma 42 HD Softkeys Switch off Plasma Select PC/DVI input Videotext on/off Function button 1 Function button 3 Programme list/ Videotext Freeze frame Auto zoom Time Page 1 Switch on with TV Select video source Select format...

  • Page 23: Eservere

    M208 SERVER Operation through the M51 Base settings Sound settings Volume control Mute Menu navigation Play Stop Skip next / back Number pad for direct access SETUP TUNER SERVER VIDEO AUDIO LIGHT SOUND VOL + CH + MUTE- VOL -...
  • Page 24 SERVER at the M208 and press the SETUP button. Confirm Synchronize setting with the OK button. Important advice Neither the M51 nor the M208 can be operated while the synchronisation is running. Data exchange now starts and depending on the number of albums stored, can last anything from a few seconds to 10 minutes.

  • Page 25: Operation

    M208 Operation Using the M208, you can operate your music server in the same way that you are used to do with the M51, or with the Revox Multiroom System wall display. Four options are available to you as selection criteria: Album…...
  • Page 26 M208 Artist… Select the Artist… option with the navigation compass and confirm your selection with the OK button. All artists, groups, solo singers, etc. on the music server are now listed in alphabetical order. You can now use the vertical...
  • Page 27 M208 Genre… Select the Genre… option with the navigation compass and confirm your selection with the OK button. All genre classifications on the music server are now listed in alphabetical order: Select the desired Genre with the navigation compass and confirm your selection with the OK button.

  • Page 28: Repeat E

    M208 Repeat Using the Repeat On/ Repeat Off selections, you can decide whether the album you are listening to should be repeated or not. The default setting is without repetition. Using the remote control, you can now trigger the repetition of the...
  • Page 29 M208 Server Original M37 Remote control Base settings Individual softkeys Sound settings Volume control Mute Call menu Menu navigation Play Stop Skip next / back Number pad for direct access SETUP TUNER SERVER VIDEO AUDIO LIGHT SOUND VOL + CH +...
  • Page 30 M208 M208 Softkeys Original M37 Remote control Mute Select audio output Information /Edit text Select album Select genre Once only repeat Playlist: A compilation of different albums and artists Page 1 Server on/off Cancel Back to Main Menu MORE Page 2...

  • Page 31: Sat

    M208 Operation through the M51 Base settings TV operation SAT operation on Sound settings Volume control Mute Channel up / down Number pad for direct access SETUP TUNER SERVER VIDEO AUDIO LIGHT SOUND VOL + CH + MUTE- VOL -...
  • Page 32 M208 Re:control...
  • Page 33 M208 Original Topfield Remote control Type : 5000-PVR series Base settings Individual softkeys Switch M51-SAT on Sound settings Volume control Mute Call menu Menu navigation Exit menu Play Stop Skip forward / back Number pad for direct access SETUP TUNER...
  • Page 34 M208 M208 Softkeys Topfield 5000-PVR Series Switch between TV / Radio Sound operating mode Subtitles Show favourites list Show film archive Programme information UHF Modulator setting List for PIP sub-picture EPG: Electronic Programme Guide – Online programm listings PIP: Picture-in-picture function...

  • Page 35: G Videog

    M208 G VIDEO You can access the selection menu that offers you 4 video sources through the A button. You can select one of the M51 sources through the softkeys and following that, you can use the button with the grey border.
  • Page 36 M208 Re:control...

  • Page 37: Haudioh

    M208 AUDIO You can access the selection menu that offers you 6 audio sources through the AAUDIOA button. You can select one of the M51 sources through the softkeys and following that, you can use the button with the grey border.
  • Page 38 M208 Re:control M208 AUDIO Softkeys Page 1 Analogue source Aux 1 Analogue source Aux 2 Analogue source Aux 3 Analogue source Rec-In Local source - MR Analogue source TV MORE...

  • Page 39: Ilighti

    M208 Re:control LIGHT...
  • Page 40 M208 Re:control...

  • Page 41: Jsoundj

    M208 Sound Using the A A button, you SOUND can make the sound settings for the M51 as well as for the Multiroom amplifier. The buttons with the grey border are active while defining the sound settings through the softkeys. All other buttons have no functions.
  • Page 42 M208 M208 Sound Softkeys M51 Sound settings Center Speaker volume Rear Speaker volume Subwoofer volume Multiroom amplifier sound settings MR amplifier “Balance” MR amplifier “Treble” MR amplifier “Bass” M51 + MR amplifier sound settings Toggle M51 room sound mode MR: Multiroom...

  • Page 43: K Appendix

    MMC memory card is not installed correctly or it is missing. See Chapter MMC Card. You are not using an original MMC card from Revox. The connection through the M208 Link interface is faulty. See Chapter Synchronisation. The M51 does not have the software that is needed to carry out a synchronisation.

  • Page 44: Technical Data

    If he can't give you the help you need, send the remote control carriage free and without any accessories to your national Sales Office. Please supply a complete description of the fault together with your address. Scope of delivery M208 Remote control M208 Link Interface USB cable M Link cable...
